Avidyne 700-00182-XXX and 700-00179-XXX

7.5 Tray Removal

1. Remove IFD from Tray, See Section 7.1
2. Remove fasteners from Tray and Connectors
3. Remove tray from instrument panel

7.6 Tray Installation

1. Re-install fasteners in connectors and tray
2. Re-install IFD, see Section 7.2
3. Verify the tray is bonded to the airframe. The bond between the tray
and the airframe must measure ≤ 2.5 milliohm
4. Perform post-installation verification per Section 7.7.

7.7 System Setup and Checkout

After any maintenance activity involving the IFD System, the post-
installation checkout should be performed. Verify the following functions
of the IFD5XX/IFD4XX is operating correctly, reference the
IFD5XX/IFD4XX Installation Manual and Pilot Guide as need.
The installation manual, Avidyne Document 600-00299-000 Rev. 10 (or
later FAA approved revision), contains detail setup and testing
information if needed.
7.7.1 VHF Communication Checkout
Tune the VHF Communication Transceiver to an unused frequency, verify
the IFD5XX/IFD4XX can receive and transmit on that frequency.
7.7.2 Navigation Checkout
Verify the IFD5XX/IFD4XX GPS Navigation and VHF Navigation (if
installed) is operating correctly including navigation source selection. If
installed, verify the following is operating correctly: navigation displayed
on a CDI/HSI, external annunciation, and audio output.
7.7.3 External Sensor Checkout
The IFD5XX/IFD4XX can be connected to several different external
sensors. Verify each sensor is operating correctly per the manufacturer's
maintenance information.
Confidential property of Avidyne Corporation
Not to be disclosed without permission
Instructions for Continued Airworthiness
Page 18 of 18
AVIFD-315
Revision: 08, Date: 01/18/17
