FCC Caution The device complies with Part 15 of the FCC rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation. FCC RF Radiation Exposure Statement: The equipment complies with FCC RF radiation exposure limits set forth for an uncontrolled environment.
Page 3
Important Safety Precautions Always read and follow these basic safety precautions carefully when handling any piece of electronic component. Keep this User’s Guide for future reference. Keep this equipment away from humidity. Lay this equipment on a reliable flat surface before setting it up. The openings on the enclosure are for air convection hence protects the equipment from overheating.
MIS staff for help. Technical Support Visit the MSI website for FAQ, technical guide, driver and software updates, and other information: http://www.msi.com.tw/. Contact our technical staff at: support@msi.com.tw.
Internet over your existing wireless network easily, without disassem- bling your computer. The UB11B has a data rate up to 11Mbps, and can auto-negoti- ate to 5.5, 2, 1Mbps to be compatible with any IEEE 802.11b device.
>>> 1.2 How UB11B Works Ad-hoc Mode : An Ad-hoc network is a local area network or other small network, especially one with wireless or temporary plug-in connections, in which some of the network devices are part of the network only for the duration of a communications session.
Page 8
Infrastructure Mode : The difference between Infrastructure network and Ad-hoc network is that the former one includes an Access Point. In an Infrastructure network, the Access Point can manage the bandwidth to maximize bandwidth utilization. Addi- tionally, the Access Point enables users on a wireless LAN to access an existing wired network, allowing wireless users to take advantage of the wired networks resources, such as Internet, email, file transfer, and printer sharing.
>>> 1.3 Specifications Form Factor Operation voltage Standard Frequency Range Data Rate Network Protocol Support TCP/IP, NetBEUI, IPX/SPX Operating Channels Media Access Protocol Media Access Protocol Security / Encryption Range Operating system USB 1.1 5VDC (±0.5V) IEEE 802.11b 2.4GHz to 2.497GHz 1, 2, 5.5, and 11Mbps - USA/Canada: 11 channels - Europe: 13 channels...
>>> 1.4 System Requirements Before installing the UB11B, your PC should meet the following items: - One desktop/notebook PC with an available USB port. - Windows 98SE/ME/2000/XP operating system. ® - Minimum 5MB free disk space for installing the driver and utilities.
>>> 1.6 Product View USB Connector Cover Power/Link LED - Steady BLUE indicates that the UB11B is connected and powered on. - Flashing BLUE indicates that the UB11B is receiving/transmitting data.
Hardware Installation The following diagrams provide you with a basic installation for the UB11B, including how to install and remove the USB adapter. >>> 2.1 Connecting the UB11B The hardware installation for the UB11B is simply plugging it into an available USB port on your desktop/notebook computer.
>>> 2.2 Removing the UB11B The UB11B supports hot-plug function, so that you can remove it under Windows operating system without shutting down the system. DO NOT remove the UB11B while transferring data (the LED is flashing). Please close the communication programs or stop the task before removing it.
Setup CD to copy files during the installation. Please NOTE that the UB11B should be installed into your computer before installing the driver and utility. Then, the operating system will detect a new device and start to configure the new device.
Page 17
Step 1. Insert the software CD into your CD-ROM drive, and the Setup program should launch automatically. If the Autorun program doesn’ t launch automatically, click Start at the taskbar and select Run... Type your CD-drive) in the Open box and click OK to launch the Setup program manually.
Page 18
Windows Setup CD during the installation. Please insert the Setup CD by the on-screen instruction to continue the installation. Click Finish when the installation is completed. The MSI Wire- Step 4. less LAN icon* will appear in the status area.
Wireless Network Utility After installing the driver, MSI UB11B provides a convenient and powerful utility that allows you to set up, configure, and know your networking status easily and clearly. >>> 4.1 Introduction 4.1.1 The MSI Wireless LAN icon - Not connected to the network.
Page 21
If your MSI wireless LAN adapter supports Software AP function, you can see this item in the sub-menu, and which allows you to use your MSI wireless adapter as a virtual access point. For details, refer to the MSI Software AP/ Gateway User’s Guide.
4.1.2 Changing the Control Setting (for Windows XP only) If you use Windows XP, the wireless LAN is controlled by the operating system (default). To take full advantage of your MSI wireless adapter, it is recommended to use the MSI Wireless Network Utility to control your wireless LAN.
Page 23
Click Advanced, and the Properties window will appear as below. Uncheck this option Uncheck the Use Windows to configure my wireless network settings option. Then, click Now, you can use MSI Wireless Network Utility to configure your network. Click...
>>> 4.2 Networking Since the UB11B is installed in your computer, you have to configure the settings for communication to start working in your network environment. 4.2.1 Infrastructure Mode Infrastructure mode allows your computer to communicate with the other computers in the network through an Access Point.
Page 25
If you want to configure the network settings: Only the network administrator can change the SSID and WEP settings in the Association window; if you have problem of accessing the network, please ask the administrator for help. WEP settings Click Advanced in the Wireless Network Connection window.
Page 26
Click OK. The selected network will appear in the Preferred Networks field. If it contains two or more networks in the list, you can use Move up/Move down to set the priority. Click Click OK to complete the configuration, and an icon indicating connected to the network will appear in the status area.
All the computers connected should be set to Ad- hoc mode. The computers have the same SSID (network name) setting. To configure the settings: Click the MSI Wireless LAN icon to bring up the Wireless Network Connection window. Then, click Advanced. Click Click...
Page 28
You can build up the Ad-hoc network by clicking Add... in the Preferred Networks field. Click Set up the Network Name (SSID) and Network Key (if needed) for the network. Then, check the This is a computer-to-computer [ad hoc] network; wireless access points are not used option and click OK to enable the Ad-hoc mode.
Page 29
The computer set up with this Ad-hoc network in step 3 is the designated administrator of the network. Any computer can access the network by selecting Connect in the Wireless Network Connection window. Click OK to complete the configuration, and an icon indicating connected to the network appears in the status area.
>>> 4.3 Encryption To setup the Network Key, check Encryption option first, then cancel The key is provided for me automati- cally option. In the wireless network environment, the administrator can set up password (Network Key) to protect the network from being attacked or unauthorized access.
>>> 4.4 Status In the Status tab, you can configure more network settings. Signal Strength: shows the received signal strength level. Link Quality: shows the measured signal level and connection status. Click Advance, and you can get more information about the LAN traffic status and more detailed settings.
It is not recommended to change these settings if you are not familiar with the advanced configuration. Fragmentation Threshold You may set the length of the fragment in this field. Please note that each fragment should not be larger than the Frag- mentation Threshold.
Networking Basics This chapter describes how to prepare for connection to net- work and some basic outline of networking basics, including shar- ing files, printing from a computer on the network, or accessing the Internet on multiple computers with one connection. >>>...
Page 35
Under Windows 2000/XP Check the required elements from this field. Click Start and choose Control Panel to open the Control Panel window. Double-click the Network Connection icon to open the Network Connection window. Right-click the Wireless Network Connection icon and click Properties from the shortcut menu. The Wireless Network Connection Properties window appears to show the current network settings of the system.
>>> 5.2 Computer Identification Please verify that each computer has a unique name and common workgroup name, if you had previously given your Windows 98SE/ME/2000/XP computers names. Under Windows 98SE/ME Enter a name for your computer (less than 15 characters without space. Your computer will belong to this workgroup.
Page 37
Under Windows 2000/XP Right-click Enter some information for reference. Your computer’ s name. Your computer will belong to this workgroup. Right-click My Computer icon on your Windows desktop, and click Properties from the shortcut menu. The System Properties window appears; choose Computer Name tab.
Page 38
To rename the computer and join a workgroup/ domain, click Change. The Computer Name Changes window appears as below. Enter a Computer Name, select Workgroup and enter the name of your workgroup. Please NOTE that each computer’ s name must be unique on a particular network to avoid confusion.
>>> 5.3 Configuring a Dynamic/Fixed IP Address When the drivers are installed, the default setting here is set to obtain IP dynamically through a DHCP server. If you want to change the settings, please follow the steps below: Under Windows 98SE/ME Go to Start ->...
Page 40
Check this 4.a Configuring a dynamic IP address Enter a fixed IP address and Subnet Mask Check this 4.b Configuring a fixed IP address Click OK. Then, click Yes when prompted to reboot the computer.
Page 41
Under Windows 2000/XP Click Start and choose Control Panel to open the Control Panel window. Double-click the Network Connection icon to open the Network Connection window. Right-click the CardBus Wireless Network Adapter icon and click Properties from the shortcut menu. When the Wireless Network Connection Proper- ties window appears, choose General tab and select Internet Protocol [TCP/IP], and click Properties to...
Page 42
Check this 5.a Configuring a dynamic IP address Check this Enter a fixed IP address and Subnet Mask 5.b Configuring a fixed IP address Click OK to complete the configuration.
>>> 5.4 Checking TCP/IP Address Under Windows 98SE/ME Type winipcfg here. Check the configuration of IP Address, Subnet Mask, and Default Gateway are correct. Go to Start -> Run... in the Open box and click OK. Type winipcfg The IP Configuration screen will appear, click More Info to bring up a screen containing detail information of your wireless network adapter.
Page 44
Under Windows 2000/XP Go to Start -> Run... Type Type here. A DOS prompt window appears. Type and press [Enter] to display IP information. in the Open box and click OK. Your Wireless LAN adapter model Check the configuration of IP Address, Subnet Mask, and Default Gateway are correct.
>>> 5.5 Checking Connection by Pinging Go to Start -> Run... Type (Windows 2000/XP) in the Open box and click OK. A DOS prompt window appears. Type 59.147.160 address of the Gateway in this case, and press [Enter]. You will get reply if the pinging is successful.
>>> 5.6 Sharing Files You may now open and save files on other computers once your computers are connected together on a network. You will also be able to specify particular folders or disk drives to share and even password to protect them. Please verify that each computer has a unique name and common workgroup name, if you had previ- ously given your Windows names.
Page 47
Select the I want to be able to give others access to my files option, and click OK. Check this Click OK in the Network dialog box. Provide the Windows Setup CD or direct the path to the proper location of the installation files if prompted.
Page 48
Select the Share As option to set the parameters for sharing this particular disk drive or folder. Share Name This is used to identify the disk drive or folder you are sharing to other computers in the network, which can be helpful as more resources in your network for others.
Page 49
Password This option allows you to apply a level of security to your shared disk drive and folder. Any other computer (user) will be asked to enter the password you set here before accessing the disk drive or folder. Two passwords are used to give two levels of security (or access) to others in the network using the Depends on Password setting.
Index Access Point 1, 19 Ad-hoc mode 2, 22 ASCII 25 Available Networks 20 CCK 4 Channel 4, 26 Command 40 Computer Identification 31 Country 27 DBPSK 4 DOS 39 DQPSK 4 DSSS 4 Dynamic IP Address 34 Encryption 4, 25 File and Print Sharing 41 Fixed IP Address 34 Fragmentation Threshold 27...
Page 51
InstallShield Wizard 11 Internet 1, 29 Key index 25 Key length 25 LAN 26 Link Quality 26 Local Area Network 2 MSI Wireless LAN icon 15 Network key 20, 25 Power save 27 Preamble Type 27 priority 21 Protocol 4...
Page 52
Radio 26 Range 22 RTS/CTS Threshold 4 Service Set Identifier 26 Signal Strength 26 Speed 26 SSID 26 Status tab 26 Subnet Mask 34 TCP/IP 29, 34 WEP 4, 20 winipcfg 38 Wireless Network Connection 17 Wireless Network Connection Properties 30...
