Lorex L15LD400 Instruction Manual

L15ld400 series lorex client 2.0 remote agent software
Hide thumbs Also See for L15LD400:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Instruction Manual
LOREX CLIENT 2.0
Remote Agent Software
Instruction Manual
English Version 1.0
MODEL:
L15LD400 Series
www.lorexcctv.com
©
Copyright
2007 LOREX Technology Inc.

Advertisement

Table of Contents
loading

Related Manuals for Lorex L15LD400

Summary of Contents for Lorex L15LD400

  • Page 1 LOREX CLIENT 2.0 Remote Agent Software Instruction Manual English Version 1.0 MODEL: L15LD400 Series www.lorexcctv.com © Copyright 2007 LOREX Technology Inc.

  • Page 2: Table Of Contents

    LorexPlayer 2.0 Backup Player Software - Main Screen ... 33 - 37 About the Lorex Client 2.0 The Lorex Client 2.0 software package allows you to access your Observation System from a remote location to view live and previously recorded video.

  • Page 3: System Requirements

    Please check with your Internet Provider for your current upload and download speeds. Please refer to the Lorex Client 2.0 Software User Guide included with your Observation System Visit the Lorex support website at http://www.lorexcctv.com for information on Windows Vista...

  • Page 4: Lorex Client 2.0 Software Installation

    Lorex Client 2.0 Software Installation Lorex Client 2.0 Software Installation Place the Lorex Client 2.0 Installation CD in the CD-ROM Drive of your Computer. The Software Install Wizard for the Lorex Client 2.0 Software will begin. 1. Click the NEXT button on all dialogue windows to continue the Installation: 2.

  • Page 5: Lorex Client 2.0 Software Installation

    3. The installation process will continue. Once the install is complete, press the Finish button. NOTE: Make sure to close all open programs and save any open files before rebooting the system. Program Shortcuts • Start Menu - Programs - Lorex Client Lorex Client 2.0 Lorex Player 2.0 • Desktop Shortcuts for: Lorex Client 2.0...

  • Page 6: Lorex Client 2.0 Software - Main Screen

    Lorex Client 2.0 Software - Main Screen Lorex Client 2.0 Software - Main Screen The Lorex Client allows you to remotely connect to your system, and view live images. NOTE: Remote viewing or playback is dependant on your connection speed, internet traffic and other network factors - the speed is normally 1~2 FPS (frames per second).

  • Page 7: Lorex Client 2.0 Software - Main Screen

    Menu). 8. DISCONNECT - Disconnects from the Observation System. 9. PLAYBACK - Accesses previously recorded data for playback on the Lorex Client 2.0 Software. This option is only available when you are remotely connected to the system. 10. SETUP - Enters the Setup Menu for remote connection to the Observation System.

  • Page 8: Setup & Configuration Menu

    Setup & Configuration Menu Setup & Configuration Menu The Setup Menu contains the information to allow the user to remotely connect to the Observation System. IP/PORT Tab 1. NAME - Enter a name for the Observation System Connection (i.e. System, Office, etc.) 2.
  • Page 9 4. ADDRESS LIST - Provides a listing of all previously configured Observation Systems. 5. MANUAL / DDNS - Changes the connection type between using a Manual Setup or using a DDNS setup for connection. See Remote Access with the DDNS Service section for DDNS configuration and use.

  • Page 10: Dns Tab

    Setup & Configuration Menu DDNS Tab NOTE: This tab only becomes active if the DDNS Button is selected on the IP/PORT Tab. 1. USER NAME - Enter the name used during the DDNS Setup process. See Remote Access with the DDNS Service section for DDNS configuration and use. 2.
  • Page 11 5. IP ADDRESS - Displays the IP Address and Port Number of the current Observation System configuration. 6. USER ID - Enter the User ID ‘ADMIN’ 7. PASSWORD - Enter the Admin password for the Observation System (blank by default). 8.

  • Page 12: Save Tab

    Setup & Configuration Menu SAVE Tab 1. SET PATH - Choose a directory to save video onto the local PC. If no path is set, the program will save the files to the C:\PrograM Files\Remote_J2K directory. 2. RUN IN FULL SCREEN MODE - Sets the interface to load to the size of the entire screen. 3.

  • Page 13: Remote Playback Interface

    Remote Playback Interface The Remote Playback interface allows the software to playback previously recorded video from the Observation System. NOTE: You must have an active connection to the Observation System before the Remote Playback will function. Remote playback is dependant on your connection speed, internet traffic and other network factors - the speed is normally 1~2 FPS (frames per second).
  • Page 14 • RECORD - Save the current onscreen video as a AVI file to the local PC. • PRINT - Prints the current onscreen image (when playback is paused). • EVENT - Displays the Event List from the DVR. Event items can be selected for playback. 9. EXIT- Closes the Lorex Client 2.0 software.

  • Page 15: Remote Access With The Ddns Service

    The L15LD400 Series Observation System can be remotely controlled using your existing network and the Lorex Client 2.0 software. Recording times may vary - please use the Recording Calcula- tor provided with the CD to find an aproximate recording time calculation.

  • Page 16: Ip & Mac Address

    Remote Access with the DDNS Service IP & MAC Address 1. Access the Main Menu Setup screens, and navigate to the SYSTEM MENU - EXTERNAL DEVICE - TCP/IP SETUP - IP SETUP option. 2. Record the MAC Address of your system. This information is NECESSARY for the DDNS Setup process.

  • Page 17: Router Port Forwarding

    Router Port Forwarding You will need to enable port forwarding on your Router to allow for external communications with your Observation System for port: • PORT 50000 Computers, Observation Systems, and other devices inside your network can only communicate directly with each other within the internal network. Computers and systems outside your network cannot directly communicate with these devices.

  • Page 18: Setting Up Your Ddns Account

    Setting Up Your DDNS Account Lorex offers a free DDNS service for use with your System. A DDNS account allows you to set up a web site address that points back to your Local Network. The following outlines how to set up your free DNS account.
  • Page 19 4. Once the account has been created, you will need to login using your credentials (as set in step 3). Once the Username and Password have been entered, press the LOG IN button to access the Configuration Menu. 5. Select the ADD DVR link from the top of the page: The DVR Setup screen will appear: •...

  • Page 20: Ddns Setup

    DDNS SETUP Once the DDNS settings have been configured online, the information must be entered on the Observation System to allow for remote connection via the Lorex Client 2.0 Software (or through Internet Explorer): 1. Access the Main Menu Setup screens, and...

  • Page 21: My Connection Information

    2. Set the DDNS ENABLE to ON. 3. The following will automatically complete after clicking the Register option: • DNS SERVER - Confirm that the IP address is set to 202.133.244.128. • INTERVAL - Set an interval for the DVR to auto-update its IP address to DDNS server (D- days / H- hours / M- minutes).

  • Page 22: Lorex Client 2.0 Remote Access Setup

    Remote Access with the DDNS Service Lorex Client 2.0 Remote Access Setup The remote connection information needs to be added to the Lorex Client software to allow for a remote connection (using DDNS). 1. Load the Lorex Client 2.0 Software. Click on SETUP to add the configuration.

  • Page 23: Remote Viewing With Internet Explorer

    Remote Viewing with Internet Explorer Remote Viewing with Internet Explorer Video from the Observation System van be viewed using the Internet Explorer interface (for remote viewing and backup). All Remote functionality through the Internet Explorer interface is provided at http://www.lorexddns.com. Log in using the User Name and Password configured during the DDNS setup.Select the Web link option to load the Internet Explorer interface.

  • Page 24: Web Player Interface Screen

    Remote Viewing with Internet Explorer Web Player Interface Screen 1. MAIN SCREEN - Displays live Camera images (delays in images are due to Network speed and connectivity strength). 2. SYSTEM INFO - Displays the IP Address, Port Number, User Name and Password for remote connection to the System.

  • Page 25: Data Backup With Internet Explorer

    Data Backup with Internet Explorer Data Backup with Internet Explorer Video from the Observation System can be backed up to the local PC using the Internet Explorer interface. All Remote functionality through the Internet Explorer interface is provided at http:// www.lorexddns.com.

  • Page 26: Web Backup Interface Screen

    Data Backup with Internet Explorer Web Backup Interface Screen 1. BACKUP INFORMATION - Sets the backup criteria for: • IP ADDRESS & PORT - Provide the network information for connection to the System. • USER ID & PASSWORD - Provide the User ID (admin) and Password (blank) for the System. •...

  • Page 27: Backup Procedure

    3. BACKUP DATE CRITERIA - Displays the date of the first and last records on the System. Press the Update button to retrieve the most current information. 4. BACKUP STATUS - Displays information about the backup process: • MESSAGE - Displays the backup status •...
  • Page 28 Data Backup with Internet Explorer Play Backup Files with Internet Explorer Log in using the User Name and Password configured during the DDNS setup. Select the Backup Player link to load the Internet Explorer interface. The System Backup Player loads to the following screen: 1.

  • Page 29: Play Backup Files With Internet Explorer

    5. CAMERA SELECTION BUTTONS - Press buttons 1~4 to select a Camera Number to display. 6. AUDIO OPTIONS - Not supported with this System 7. SPEED - Adjust the speed of the Fast Forward playback. 8. DELAY - Adjust the speed of the Fast Rewind playback. 9.

  • Page 30: Lorexplayer 2.0 Backup Player Installation

    • Double Click the CD-ROM DRIVE (Drive Letter will vary depending on the number of drives in your computer) • Double Click the LOREXPLAYER.EXE file (may appear as LOREX PLAYER with no file extension, depending on your system settings. The Installation Process will begin.
  • Page 31 3. The installation process will continue. Once the install is complete, press the Finish button. NOTE: Make sure to close all open programs and save any open files before rebooting the system. Program Shortcuts • Start Menu - Programs - Lorex Client Lorex Client 2.0 Lorex Player 2.0 • Desktop Shortcuts for: Lorex Client 2.0...

  • Page 32: Lorexplayer 2.0 Backup Player Software - Main Screen

    LorexPlayer 2.0 Backup Player Software - Main Screen LorexPlayer 2.0 Backup Player Software - Main Screen 1. MAIN SCREEN - Displays the backup Video (Camera images). 2. TIME - Displays the time on the Local PC 3. DATE / TIME - Displays the Date and Time for the Start and End of the backup video on CD. 4.
  • Page 33 7. PLAYBACK CONTROLS - Play controls for the backup video: • Restart playback at the beginning of the record. • Fast Rewind. • Rewind (1x speed). • Pause the playback. • Forward Play (1x speed). • Fast Forward Play. • Move video playback to the end of the record. 8.
  • Page 34 LorexPlayer 2.0 Backup Player Software - Main Screen Saving a JPG File 1. To save a still image during video playback (when in FULL SCREEN MODE), click EDIT. 2. Select SAVE to save the picture as JPG file, or select PRINT to print the image.
  • Page 35 LOREX neither assumes nor authorizes any person to assume for it any other obligation or liability in correction with the sale or service of the Product. In no event shall LOREX be liable for any special or consequential damages arising from the use of the Product or arising from the malfunctioning or non-functioning of the Product, or for any delay in the performance of this warranty due to any cause beyond its control.
  • Page 36 It’s all on the web Product Information User Manuals Quick Start Guides VISIT www.lorexcctv.com LOREX Technology Inc. Specification Sheets Software Upgrades Firmware Upgrades wwwlorexcctv.com...
