- Page 1 Website http://biz.lgservice.com VACUUM CLEANER SERVICE MANUAL MODEL : V-CB361NTB CAUTION BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS" IN THIS MANUAL. November, 2006 Printed in Korea P/NO : 3828Fi5886R...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS .......................3 CAUTIONS ............................3 DESCRIPTION ..........................4 SPECIFICATIONS...........................4 DISASSEMBLY ...........................5~6 TROUBLE SHOOTING GUIDE....................7~9 SCHEMATIC DIAGRAM ......................10 CIRCUIT DIAGRAM ........................10 EXPLODED VIEW ........................11~13 REPLACEMENT PARTS LIST....................14~15... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS BEFORE OPERATING THIS VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND OBSERVE EACH POINT CAREFULLY. 1. Motor filter(Air Cleaner) 3. Avoid suction such materials as : 1) This filter is reusable. 1) Liquid or wet dust : Clogs the ventilation holes, reduces the suction 2) Never use the vacuum cleaner without filter. -
Page 4: Description
DESCRIPTION Flexible Hose Assembly Power Cord Telesscopic Pipe Assembly Cord Reel Button Dust Tank CANISTER ATTACHMENTS DUSTING BRUSH CREVICE TOOL UPHOLSTERY NOZZLE ACCESSORY HOLDER SPECIFICATIONS • MODEL : REFER TO THE COVER PAGE • CORD LENGTH : 5 m • POWER SOURCE : ON RATING PLATE •... -
Page 5: Disassembly
DISASSEMBLY NOTE: Before attempting to service or adjust any part of the vacuum cleaner, disconnect the electrical power supply cord from the wall outlet. • Almost all of the parts of this vacuum cleaner can be 3) Disassemble the body cover, raising the body cover. disassembled with a screw driver and each connecting component easily fits each other. - Page 6 2) Pull out the motor and disconnect the lead wires from it. 4. Disassembly of Motor Housing 1) Remove the two screws fastening the motor housing. Motor Ass'y 3. Cord Reel Assembly Replacement 1) Lift the cord reel assembly from the body base. Cord Reel Ass'y...
-
Page 7: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE 1. SWITCH ON BUT MOTOR DOSE NOT TURN. CHECKING CAUSE SOLUTION The fuse is melt down in the CHECK THE POWER Exchange the fuse. coverknife switch. SOURCE Poor plug insertion Insert again. Power cord cut Repair or exchange. Interior lead wire cut Exchange the lead wire. - Page 8 3. SWITCH OFF BUT MOTOR TURNS Repair the slide volume of hose Poor connection or triac of PWB assembly Poor switch Exchange the switch. (NT/NE) 4. WEAK SUCTION POWER Exchange the carbon brush Carbon brush defaced or the motor. Motor armature cut Exchange the motor.
- Page 9 5. VIBRATION NOISES Loose parts Secure firmly. Unbalanced motor assembly Exchange or repair the motor. Foreign matters are attached Remove the foreign matters. to the impeller. Poor carbon brush rectification Exchange the motor. Armature is cut or foreign Exchange the motor matters attached.
-
Page 10: Schematic Diagram
SCHEMATIC DIAGRAM POWER S/W MAIN PWB ASSEMBLY CIRCUIT DIAGRAM MAIN S/W 1,1/2W 1N4007 0.22uF 250V IONIZER 5.6V 470uF 0.47uF PRESSURE 250V LED2 LED1 -10-... -
Page 11: Exploded View
#EV# EXPLODED VIEW BASE ASSEMBLY, BODY V-CB361NTB(V-CB361NT.ATLQLFS) 135504 139204 239402 139202 146811 249011 140361 166012 146871 235504 252311 235505 135506 145103 168711 368771 146611 149702 146611 130401 144411 -11-... - Page 12 #EV# COVER ASSEMBLY, BODY 136501 748395 335504 335510 450201 152313 252313 266011 268712 132102 340261 139203 452002 748382 349701 235501 533001 166311 -12-...
- Page 13 #EV# ACCESSORY 652012 452151 552491 652481 149309 652031 650581 -13-...
-
Page 14: Replacement Parts List
REPLACEMENT PARTS LIST LOC. NO. PART NO. DESCRIPTION REMARK 130401 3040FI1517A Base,Body 132102 32118I2001A Frame Assembly,Filter 135504 3550FI1728A Cover,Motor 135506 3550FI1727B Cover,Motor Housing 136501 3650FI2418A Handle,Carrier 139202 3920FI3863A Damper,Motor Mount 139203 3920FI3852A Gasket,Sealing 139204 3920FI3763A Gasket,Sealing 140361 3920FI3838A Gasket,Sealing 144411 4441FI3605V Roller Assembly 145103... - Page 15 LOC. NO. PART NO. DESCRIPTION REMARK 650581 5058FI3462A Nozzle,Crevice 652012 5201FI2487L Pipe Assembly,Telescopic 652031 5202FI3474A Brush Assembly,Dust 652481 5248FI2259A Nozzle,Upholstery 748382 4838FI1407A Tank,Dust 748395 4839FI1023K Tank Assembly,Dust R : SERVICE PARTS -15-...
