- Page 1 Website http://biz.lgservice.com VACUUM CLEANER SERVICE MANUAL MODEL : V-C4380STS VC4380T V-C4380STR CAUTION BEFORE SERVICING THE UNIT, READ THE "SAFETY PRECAUTIONS" IN THIS MANUAL. June, 2008 P/NO : 3828Fi5877A Printed in Korea...
-
Page 2: Table Of Contents
CONTENTS SAFETY PRECAUTIONS..........................3 CAUTIONS ..............................3 DESCRIPTION..............................4 SPECIFICATIONS ............................4 DISASSEMBLY ............................5~6 TROUBLE SHOOTING GUIDE........................7~9 SCHEMATIC DIAGRAM..........................10 PRINTED CIRCUIT BOARD ........................10 EXPLODED VIEW ..........................11~13 REPLACEMENT PARTS LIST......................14 ~19... -
Page 3: Safety Precautions
SAFETY PRECAUTIONS BEFORE OPERATING THIS VACUUM CLEANER, READ THIS SERVICE MANUAL THOROUGHLY, AND OBSERVE EACH POINT CAREFULLY. 1. Filter 5. Attachments 1) The filter is composed of a motor safety filter, a 1) Nozzle : for cleaning wooden floor, the room floor exhaust filter and a paper bag or a cloth bag. -
Page 4: Description
DESCRIPTION Flexible Hose ASS'Y Cord Reel Button Power Cord Pipe Assembly, Telescopic Switch Button (ON/OFF) Wheel Filter cover Dust Indicator Nozzle Assembly,Floor CANISTER ATTACHMENTS Brush Assembly,Dust Nozzle Assembly,Upholstery Filter Assembly,Paper SPECIFICATIONS 1. MODEL : REFER TO THE COVER PAGE 11. ATTACHMENTS 2. -
Page 5: Disassembly
DISASSEMBLY NOTE : Before attempting to service or adjust any part of the vacuum cleaner,disconnect the electrical power supply cord from the wall outlet. • Almost all the parts of this vacuum cleaner can be 3) Lift body cover in the direction of the arrow. assembled with a screw driver and each connecting component easily fits each other. - Page 6 3. Push Switch Assembly Replacement 5. Motor Assembly Replacement 1) Lift the motor assembly in direction of the arrow after 1) Push the s/w button hook in the direction of the stripping off the lead wires. arrow. 2) Push the push switch down grasping the wings of push switch by long nose.
-
Page 7: Trouble Shooting Guide
TROUBLE SHOOTING GUIDE 1. SWITCH ON BUT MOTOR DOSE NOT TURN. CHECKING CAUSE SOLUTION Abnormal Check the power The fuse is melt down in the Exchange the fuse source coverknife switch Poor plug insertion Insert again Power cord cut Repair or exchange Interior lead wire cut Exchange the lead wire Normal... - Page 8 3. SWITCH OFF BUT MOTOR TURNS Poor connection Repair Poor switch Exchange the switch 4. WEAK SUCTION POWER Carbon brush defaced Exchange the motor Motor armature cut Exchange the motor Low rotation speed Foreign matters attached to Remove the foreign the impeller matters Inquire to the Power utility...
- Page 9 5. VIBRATION NOISES Loose parts Secure firmly Unbalanced motor assembly Exchange or repair the motor Foreign matters are attached Remove the foreign matters to the impeller Poor rectification of carbon Exchange the motor brush Armature is cut or foreign Exchange motor matters attachedattached Remove foreign matters 6.
-
Page 10: Schematic Diagram
SCHEMATIC DIAGRAM PRINTED CIRCUIT BOARD -10-... -
Page 11: Exploded View
#EV# EXPLODED VIEW BASE ASSEMBLY, BODY V-C4380STS(V-C4380ST.ALSQLGD) V-C4380STR(V-C4380ST.AYRQLGD) V-C4380T(V-C4380ST.ALSQLUK) MCQBM1 EAUBA1 MDSBA1 MDSBA2 MCQBA1 ADQBH1 ACQBM1 MEGBB1 MEGBC1 AHDBR1 MHYBA1 MEGBC2 MCKBH1 MDJBM1 AJWBA1 MAMBB1 EBRBM1 AHJBA1 -11-... - Page 12 #EV# COVER ASSEMBLY, BODY MEYCC1 MCKCE1 MCKCC1 ADQCE1 EBRCM1 MBGCR1 MCKCG1 MBGCC1 AGBCN1 MHYCC1 AESCA1 MCKCB1 MCKCF1 EBFCP1 MDSCA1 MFGCA1 ABCCB1 MGZCG1 MGZCR1 -12-...
- Page 13 #EV# ACCESSORIES AEMAF1 AGRPT1 AGBN21 -13-...
-
Page 14: Replacement Parts List
REPLACEMENT PARTS LIST V-C4380STS(V-C4380ST.ALSQLGD) LOC. NO. PART NO. DESCRIPTION REMARK ABCCB1 5203FI2068A Brush Assembly,Dust ACQBM1 3551FI2418A Cover Assembly,Motor ADQCE1 5231FI3775B Filter Assembly,Exhaust ADQBH1 5231FI2471A Filter Assembly,Paper AEMAF1 5215FI1306A Hose Assembly,Flexible AESCA1 3520FI3475E Indicator Assembly AGBN21 5249FI1399B Nozzle Assembly,Floor AGBCN1 5248FI2259C... - Page 15 LOC. NO. PART NO. DESCRIPTION REMARK MGZCR1 4350FI2001A Ring,Connector MHYBA1 4970FI4519B Spring MHYCC1 4970FI4511L Spring,Coil R : SERVICE PARTS -15-...
- Page 16 REPLACEMENT PARTS LIST V-C4380T(V-C4380ST.ALSQLUK) LOC. NO. PART NO. DESCRIPTION REMARK ABCCB1 5203FI2068A Brush Assembly,Dust ACQBM1 3551FI2418A Cover Assembly,Motor ADQCE1 5231FI3775B Filter Assembly,Exhaust ADQBH1 5231FI2471A Filter Assembly,Paper AEMAF1 5215FI1336P Hose Assembly,Flexible AESCA1 3520FI3475E Indicator Assembly AGBN21 5249FI1399B Nozzle Assembly,Floor AGBCN1 5248FI2259C Nozzle Assembly,Upholstery AGRPT1 5201FI2487L...
- Page 17 LOC. NO. PART NO. DESCRIPTION REMARK MGZCG1 4350FI3777A Ring,Guide MGZCR1 4350FI2001A Ring,Connector MHYBA1 4970FI4519B Spring MHYCC1 4970FI4511L Spring,Coil R : SERVICE PARTS -17-...
- Page 18 REPLACEMENT PARTS LIST V-C4380STR(V-C4380ST.AYRQLGD) LOC. NO. PART NO. DESCRIPTION REMARK ABCCB1 5203FI2068A Brush Assembly,Dust ACQBM1 3551FI2418A Cover Assembly,Motor ADQCE1 5231FI3775B Filter Assembly,Exhaust ADQBH1 5231FI2471A Filter Assembly,Paper AEMAF1 5215FI1306A Hose Assembly,Flexible AESCA1 3520FI3475E Indicator Assembly AGBN21 5249FI1399B Nozzle Assembly,Floor AGBCN1 5248FI2259C Nozzle Assembly,Upholstery AGRPT1 5201FI2463A...
- Page 19 LOC. NO. PART NO. DESCRIPTION REMARK MGZCR1 4350FI2001H Ring,Connector MHYBA1 4970FI4519B Spring MHYCC1 4970FI4511L Spring,Coil R : SERVICE PARTS -19-...
