Included
P P o o w w e e r r L L i i n n e e
PLEBR10 PowerLine EtherFast
10/100 Bridge
® ®
E E t t h h e e r r F F a a s s t t
1 1 0 0 / / 1 1 0 0 0 0
• Instant PowerLine PowerLine
B B r r i i d d g g e e
EtherFast 10/100 Bridge (1)
• One Power Cord (2)
• One Setup Utility CD-ROM (3)
• One User Guide (4)
• Quick Installation (this document)
and Registration Card (not shown
System Requirements
• Existing Ethernet/Fast Ethernet
Note: A Windows 95 workstation
Network
or
an
Existing
cannot be used to set up the
Ethernet/Fast Ethernet Network
PowerLine
Adapter and Network Cable
Bridge.
• TCP/IP Protocol
• CD-ROM Drive
• Windows 98, 2000, ME, NT, or XP
for Initial Setup
Installation Process
For more detailed instructions, please refer to the User Guide.
with
the
Linksys
®
Installing the PowerLine
EtherFast 10/100 Bridge
)
A. Insert the Setup Utility CD-ROM
into the computer's CD-ROM
drive. The Setup Utility CD-ROM
should run automatically. If it does
not, click the
Start
choose Run. In the box that
appears, enter
D:\setup.exe
is the letter of your CD-ROM
drive).
EtherFast
10/100
button and
(if "D"
B. To install the PowerLine EtherFast
10/100 Bridge software, click Next.
C. Enter your
User Name
and
Organization
Name. Select
Anyone
who uses this computer (all users)
to install a shortcut to the Security
Configuration Utility on every
user's desktop (This selection is
not available for Windows 98 and
ME users). Then click the
Next
button.
D. Click the
Install
button to begin
installation
of
the
Security
Configuration Utility.
Windows 2000 users: Windows will
inform you that there was no digi-
tal signature found. Click the
Yes
button to proceed with the installa-
tion.
Windows XP users: Windows will notify you that the driver has not
passed Windows Logo testing. Click the
Continue Anyway
button.
