Lexmark Optra T620 Quick Reference

Quick Reference
Lexmark T Family Laser Printer
Operator panel
Ready
1 2 3 4
Menu Select Return
5 6
Go Stop
Press Menu to:
• Enter the menus from the ready state
• Scroll through menus or values
•
Increase or decrease a numerical value
•
Display the Job Menu or the Supplies Menu while
the printer is busy
Press Select to:
• Select the item on the second line of the display
•
Save the selection as a new default setting
Press Return to:
• Return to the previous menu level
Press Go to:
• Exit printer menus and return to the Ready state
• Clear messages
Press Stop to:
• Temporarily stop all print activity without losing
data
Loading a paper tray
Pull here
Length
guide
Length guide
lever Width
guide
Paper size
indicators
Complete these instructions to load print materials into any of the standard or
optional trays. All paper trays are loaded the same way.
1
Remove the paper tray.
2
Pull the width guide tab and slide the width guide to the far right side of
the tray.
3 Squeeze the length guide lever and slide the length guide to the correct
position for the size paper you are loading.
4 Place the paper into the paper tray with the recommended print side face
down for single-sided printing and face up for double-sided printing. Do
not fill paper above the paper capacity mark (fill line).
Pull the width guide tab and slide the width guide to the left until it lightly rests
against the edge of the paper stack.
Loading the multipurpose feeder
1
Push the lower release latch.
2 Pull the metal bar out far enough to support your paper size.
3 Slide the paper width guide to the far right.
Paper and transparencies Envelopes
Supported print material sizes and types
Types
Plain Paper Labels Preprinted Envelope
Card Stock Bond Colored Paper
Transparency Letterhead Custom
Type <x>
Sizes :
Letter A4 B4 Folio* 9 Envelope
Legal A5 JIS-B5 Statement* DL Envelope
Executive B5 Envelope
C5 Envelope
7 3/4 Envelope
10 Envelope
Other Envelope
*This size is not available until Size Sensing is turned off. For more information, refer to
the online information.
Loading letterhead
Letterhead must be loaded differently depending on what options you have
installed on your printer.
In the multipurpose
In a paper tray feeder
Without finisher,
single-sided printing
Without finisher,
double-sided
printing
With finisher,
single-sided printing
With finisher,
double-sided
printing
