- Page 1 FC-2000 Technical Manual 406 Introduction Section Technical Bulletin Issue Date 0794 FC-2000 Introduction Introduction Page Description Optional Modules Components Fire Alarm System Limitations © 1994 Johnson Controls, Inc. Order No. 406-010...
- Page 2 2 Introduction—FC-2000 Introduction...
- Page 3 Underwriters Laboratories, Inc., Standard for Safety number UL 864, sixth edition. Factory Mutual (FM) approval pending. A typical FC-2000 control panel is illustrated in Figure 1; your system may have more or fewer modules depending on your requirements. All systems have a Central Processor Unit (CPU) Module, located in the top left position, and at least one initiating module.
- Page 4 Modules Voice Control Module (telephone or speaker circuit configuration), DCM-4 Dual Channel Module, TCM-2 and TCM-4 Time Control Modules. The FC-2000 is offered under a Basic Equipment (BE-2000) package, Components which provides the CPU-2000 Module, the VP-1 Vented Dress Panel, BP-3 Battery Dress Panel, one CHS-4 Chassis, interconnecting cables, and instruction manuals.
- Page 5 PWD # progmkey CPU-2000 Central Processor Module This module is the heart of the FC-2000. It controls and monitors the system modules and provides a full accounting of system status. In addition, the CPU contains two indicating appliance circuits, a remote signaling municipal tie circuit, and Form-C alarm and trouble contacts.
- Page 6 CHS-4 Chassis For the mounting of up to four FC-2000 modules or AVPS-24 Audio Visual Power Supplies. Occupies one cabinet row. VP-1 Vented Dress Panel Covers the top row of modules in the FC-2000. CPU Slide-In Labels SYSTEM FC-2000 FC-2000...
- Page 7 CHS-4 Chassis except for the CPU. avps24 MPM-2 DC VO LTS DC AM PS 15 2 0 2 5 30 3 5 The Main Power Meter (MPM-2) provides a voltmeter and ammeter for the MPS-24A only. Introduction—FC-2000 Introduction...
- Page 8 Eight 4.7K, 1/2-watt izm-8mod IZE-A Initiating Zone Expander Converts the eight initiating device circuits on the Initiating Zone IZ E-A Module (IZM-8) for Style D operation. The expander plugs into the bottom of the IZM-8. ize-amod 8 Introduction—FC-2000 Introduction...
- Page 9 AIM-200 Addressable Intelligent Module The AIM-200 Addressable Intelligent Module serves as an interface between the FC-2000 and intelligent/addressable devices. To the CPU, the AIM-200 looks like an IZM-8 Initiating Zone Module. On its single SLC circuit, the AIM-200 can communicate with up to 99 intelligent detectors (1551J, 2551J, and 5551J) and 99 addressable modules (M500MJ, M501MJ, M502MJ, M510CJ, and BGX-101L).
- Page 10 Circuits feature manual ON/OFF control switches and can be disabled or enabled as needed. ELRs, dummy load resistors, slide-in labels and an auxiliary bell power harness are provided with each module. icm-4mod 10 Introduction—FC-2000 Introduction...
- Page 11 CHS-4M Chassis/Dress Panel Assembly For expansion beyond the first row in the cabinet. One CHS-4M is needed for each additional row of system modules. The CHS-4M includes the CHS-4 chassis, the MP-1 Module Dress Panel, and the expander ribbon. Introduction—FC-2000 Introduction...
- Page 12 VRAM-1 memory chips installed, up to two user-defined messages may be programmed into the AMG-1 (one per VRAM). Up to 24 seconds in length, both user-messages can be produced at the AMG-1 through the built-in microphone, or downloaded through a standard audio cassette recorder. 12 Introduction—FC-2000 Introduction...
- Page 13 Command Center with fire fighter’s telephone capability. With the FFT-7, up to seven telephones may conduct a simultaneous conversation. For more details on voice evacuation equipment, refer to the FC-2000 Fire Fighter’s Command Center Technical Bulletin in this manual. FFT-7S Fire Fighters Telephone...
- Page 14 ACM-16AT by 16 system points. The AEM-16AT is identical in size and frontal appearance to the ACM-16AT. One to three of these expander modules can be supported by an ACM-16AT, to a maximum of 64 system points. 14 Introduction—FC-2000 Introduction...
- Page 15 Control switches for Acknowledge, Signal Silence, and System Reset Time/date display field ABF-1 package with key switch and phone jack options Mounts up to 6000 feet from the panel s lsw itch Local piezo sounder with alarm/trouble resound Introduction—FC-2000 Introduction...
- Page 16 Table 1: Cabinet Configuration Options Cabinet Maximum Number of Primary Module Chassis Positions CAB-A3 CAB-B3 1 or 2 4 or 8 CAB-C3 1, 2, or 3 4, 8, or 12 CAB-D3 1, 2, 3, or 4 4, 8, 12, or 16 16 Introduction—FC-2000 Introduction...
-
Page 17: Fire Alarm System Limitations
Equipment used in the system may not be technically compatible with the control. It is essential to use only equipment listed for service with your Johnson Controls fire controller. Telephone lines needed to transmit alarm signals from a premise to a central monitoring station may be out of service or temporarily disabled. - Page 18 Adequate written records of all inspections should be kept. While installing a fire alarm system may make lower insurance rates possible, it is not a substitute for fire insurance. 18 Introduction—FC-2000 Introduction...
- Page 19 Notes Introduction—FC-2000 Introduction...
- Page 20 Notes Controls Group FAN 406 507 E. Michigan Street FC-2000 Technical Manual P.O. Box 423 Rev. Level — Milwaukee, WI 53201 Printed in USA 20 Introduction—FC-2000 Introduction...
