Lexicon MC-12HD Software Upgrade Instructions
Lexicon mc-12hd: supplementary guide
Hide thumbs
Also See for MC-12HD:
- User manual (215 pages) ,
- Protocol manual (135 pages) ,
- Supplementary manual (4 pages)
Related Manuals for Lexicon MC-12HD
Summary of Contents for Lexicon MC-12HD
- Page 1 MC-12HD Software Upgrade Instructions...
-
Page 2: Important Safety Instructions
• Increase the separation between the equipment and the receiver. • Connect the equipment into an outlet on a circuit different from that to which the receiver is connected. • Consult the dealer or an experienced electronic technician for help. - Page 3 Tel: 781-280-0300 Fax: 781-280-0490 www.harmanspecialtygroup.com Customer Service Lexicon and the Lexicon logo are registered trademarks of Harman International Industries, Inc. U.S. Patent Nos. D454,553; Tel: 781-280-0300 D454,860; 5,796,844; 5,870,480 and other worldwide patents issued and pending. Fax: 781-280-0499 © 2007 Harman International Industries, Incorporated. All rights reserved.
-
Page 4: Documentation Conventions
Introduction DOCUMENTATION CONVENTIONS This document contains general safety, installation and operation instructions for the Lexicon Product. It is important to read this user guide before attempting to use the product. Pay particular attention to safety instructions. The following symbols are used in the document:... -
Page 5: Software Installation Instructions
MAKING CONNECTIONS If the computer has only a USB connector, a USB-to-serial port adapter is required to make the connection to the MC-12HD. It is not required if the computer has an RS-232 connector. Certain USB-to-serial port adapters have been reported to be incompatible with the upgrade kit. - Page 6 Software Upgrade Instructions NAVIGATING THE WINDOWS OPERATING SYSTEM The upgrade kit uses standard Windows operating system navigation commands to install the software and upgrade the MC-12HD. The following descriptions are provided for reference: • Back Returns to the previous window.
- Page 7 MC-12HD is powered off, or the computer experiences a problem. Note: The MC-12HD is designed to preserve the upgrade process during serial communication failures. But, certain factors such as serial cable type, serial cable length, communication failures.
- Page 8 Software Upgrade Instructions TO UPGRADE THE MC-12HD: Note: It will take about 45 minutes to upgrade the MC-12HD. Avoid using the MC-12HD while the upgrade is in progress. 1. Exit all computer programs. 2. Power off the MC-12HD with the rear panel power switch.
- Page 9 MC-12HD, treating these as “preserved user settings.” 13. Power off the MC-12HD with the rear panel power switch. Then, disconnect the serial extension cable from the MC-12HD and the computer.
