Lexicon MC-12HD Release Note

The purpose of this document is to communicate any points that are not fully discussed or to correct
and update text within the MC-12 HD User Guide, Part No. 070-17555, Rev 0.
Manual revisions pertinent to the V1.21 Software upgrade:
The V1.21 software upgrade provides the following support for the MC-12HD Digital Controller:
• Compatibility with Pioneer Kuro Plasma and Sony KDS monitors.
• Resolves the video artifacts issue (occurrence of a blue line to the left side of the picture) with Toshiba
HD-DVD players.
• Resolves the loss of center channel condition that can occur while using the Logic 7 multi-channel
surround modes.
Manual revisions pertinent to the V1.20 Software upgrade:
With the V1.20 software upgrade, the MC-12 HD supports 1080p 60 Hz, 1080p 50 Hz, and 1080p 24 Hz
video resolutions over HDMI. The following changes pertain to the MC-12 HD user manual in support of
this change:
Page 1-2: About the MC-12 HD summary
The MC-12 HD can pass digital video signals of up to 1080p, and multiple digital audio channels (5.1
channels) at sample rates of up to 96 kHz through the HDMI interface.
Page 2-23: HDMI Status menu and page 2-29: HDMI Status menu description
The VID FMT (Video Format) parameter can display 480i, 480p, 720p, 1080i, and 1080p as possible video
resolution settings, as reflected by the actual setup of the MC-12 HD Processor.
Page A-2: HDMI Performance Specifications
The Video Resolutions parameter can display 480i, 480p, 720p, 1080i, and 1080p as possible video
resolution settings. Note that the available resolution levels are dependent upon the capabilities of the
HDMI display connected to the MC-12 HD HDMI output connector.
Manual revision pertinent to the V1.10 Software upgrade:
Page 3-22: Format Detection Parameter description
The format detection parameter does not apply to the Dolby PLIIx family of listening modes.
The Format Detect parameter is independently adjustable for each input. It was implemented to correct
anomalies in certain mixed audio format and satellite broadcast signals. Within the V1.10 software
upgrade, if you require the FAST FORMAT DETECT setting for one of your inputs, you should avoid using
PLIIx listening modes with that input.
Lexicon Part No. 070-20650 | Rev 1 | 2/08
MC-12 HD Digital Controller
