ELECTROLUX HOME PRODUCTS PTY LTD
ABN 51 004 762 341
Technical Publication Nº DW107 Book WD 6
WEB SITE ADDRESS: www.partnship.com.au
OUTER PANEL & LINER ASSEMBLY
ELECTRICAL ASSEMBLY
WATER CIRCUIT ASSEMBLY
WATER SOFTENER ASSEMBLY
DOOR PANEL ASSEMBLY
BASKET ASSEMBLY
PROGRAMME CHART
WIRING DIAGRAM
CIRCUIT DIAGRAM
COMPONENT TESTING (SERVICE)
REGENERATION CYCLE
SAFETY FEATURES – CONTROLS/ALARMS
OPTIONS FOR IMPROVING WASH PERFORMANCE
COMPONENT DIAGNOSTICS TEST
FUNCTION DIAGNOSTICS CYCLE
TEST CYCLE (ABBREVIATED WASH PROGRAMME)
TABLE OF ALARM CODES
GENERAL DATA
RELEASE DATE:- 10/02
© Copyright 2003 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services
ELECTROLUX
ELECTRONIC
DISHWASHERS
SECTION
Issue: 1
Date: 08/03
PAGE Nº
2 - 3
4 - 5
6 - 7
8 - 9
10 - 11
12 - 13
14
15
16
17
17 – 18
18 – 20
21
21 – 23
23 – 24
25 – 26
27
28
MODELS:
ESI6180X
PNC 911 896 071
ESI6180U
PNC 911 896 072

Advertisement

loading

Related Manuals for Electrolux ESI6180X

Summary of Contents for Electrolux ESI6180X

  • Page 1 23 – 24 TEST CYCLE (ABBREVIATED WASH PROGRAMME) 25 – 26 TABLE OF ALARM CODES GENERAL DATA MODELS: ESI6180X PNC 911 896 071 RELEASE DATE:- 10/02 ESI6180U PNC 911 896 072 © Copyright 2003 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
  • Page 2 MODELS: ESI6180X EX. VIEW DRAWING 3927 ESI6180U OUTER PANEL & LINER ASSEMBLY Page 2 DW 107...
  • Page 3 ITEM PART Nº DESCRIPTION Ex. 3927 110A 1525390-00/9 Tube, Manifold to Base "O" Ring, Ferrule, Manifold 50249145-00/9 130A 1524445-01/0 Sealing Sleeve, Outer Manifold, Drying 1523599-01/5 Liner Assembly N.P.N. Spring, Hinge 1524312-00/4 Tray, Drip 1523673-01/8 Hinge Kit, Door (LH/RH. ) 50251714-00/7 Flap, Support, Solenoid 1526379-00/1 Crossbar, Front, Upper...
  • Page 4 MODELS: ESI6180X EX. VIEW DRAWING 3926 ESI6180U ELECTRICAL ASSEMBLY Page 4 DW 107...
  • Page 5 ITEM PART Nº DESCRIPTION Ex. 3926 Valve, Anti-Overflow 1520233-00/6 Pump Assy. Kit (Inc. Items 130, 130A and 251) 50267491-00/4 007A 1520393115 Switch, Micro, Anti-Overflow Element, Heater (230V - 2100W) 1115773-00/2 Capacitor (4 μF) 1522966-10/8 011A 1521029-10/6 Capacitor, Anti-Interference Switch, Pressure (Inc. Item 110) 1529790-70/9 Switch, Push Button (1 Button) 1524481-01/5...
  • Page 6 MODELS: ESI6180X EX. VIEW DRAWING 3890 ESI6180U WATER CIRCUIT ASSEMBLY Page 6 DW 107...
  • Page 7 ITEM PART Nº DESCRIPTION Ex. 3890 Hose, Connecting, Stand 1529849-31/5 110C 1520464-31/2 Tube, Water Balance Hose, Inlet, Safety (1500 mm) 1522221-12/4 Hose, Drain 0571 400 142 Scroll, Wash 1522410-20/6 Filter, Drain Pump (Grey) 1524505-10/2 120B 1525490-12/2 Filter, Column (Grey) Retainer, Sump 1522342-02/9 125A 50248856-00/2 "O"-Ring, Manifold, Outer...
  • Page 8 MODELS: ESI6180X EX. VIEW DRAWING 3924 ESI6180U WATER SOFTENER ASSEMBLY Page 8 DW 107...
  • Page 9 ITEM PART Nº DESCRIPTION Ex. 3924 005A 1529746-70/1 Valve, Electric Sensor, Salt 1523184-00/8 Hose, Valve 1529902-10/6 110A 1529902-20/5 Hose 110E 1520465103 Tube, Regeneration Tank Drain (250 mm) Softener, Water (Inc. Items 5A, 110, 110A, 110E, 130C & 514) 1524624-20/0 127A 1522340-03/1 Connector, Outlet Valve Seal, Decalcifier 1525274-00/5...
  • Page 10 MODELS: ESI6180X EX. VIEW DRAWING 3928 ESI6180U DOOR PANEL ASSEMBLY Page 10 DW 107...
  • Page 11 ESI6180 ITEM PART Nº DESCRIPTION Ex. 3928 Switch, Micro, Door 50253835-00/8 Gasket, Door Bottom, 1520425008 Panel, Door (Black) 1524571-15/3 305A 1524849-80/7 Glass Assy., Door (Inc. Items 514, 525A, 530, 538 & 563) Glass Assy., Door (Inc. Items 514, 525A, 530, 538 & 563) 1524849-70/8 Panel Assy., Door, Inner (Inc.
  • Page 12 MODELS: ESI6180X EX. VIEW DRAWING 3925 ESI6180U BASKET ASSEMBLY Page 12 DW 107...
  • Page 13 ITEM PART Nº DESCRIPTION Ex. 3925 Adjustment, Height. L/H. (Grey) 1522655-20/6 Adjustment, Height. R/H. (Grey) 1522655-30/5 Basket Assy., Bottom (Grey)(Inc. Items 523A, 523C & 581B) 1529791-53/3 319A 1525575-41/9 Basket, Upper (Grey) Grate, Cutlery Basket (Grey) 1525019-10/3 Basket Assy., Cutlery (Grey)(Inc. Item 320) 1525593-00/8 342B 1524377-10/6 Basket (Knife)(Grey)

  • Page 14: Important Safety Notice

    MODELS: ESI6180X PROGRAMME CHART ESI6180U EX. 3929 IMPORTANT SAFETY NOTICE This diagram has been prepared for use by electrically qualified service technicians. The manufacturer cannot be held responsible for the interpretation of its service publications nor for any injury or damage that may occur in connection with their use.
  • Page 15 MODELS: ESI6180X WIRING DIAGRAM ESI6180U EX 3930 IMPORTANT SAFETY NOTICE This diagram has been prepared for use by electrically qualified service technicians. The manufacturer cannot be held responsible for the interpretation of its service publications nor for any injury or damage that may occur in connection with their use.
  • Page 16 MODELS: ESI6180X CIRCUIT DIAGRAM ESI6180U EX. 3931 IMPORTANT SAFETY NOTICE This diagram has been prepared for use by electrically qualified service technicians. The manufacturer cannot be held responsible for the interpretation of its service publications nor for any injury or damage that may occur in connection with their use.
  • Page 17 COMPONENT TESTING In order to facilitate testing of the components, a Test Procedure has been created showing the contacts to which the probes of the tester should be connected and the reading for each component. To gain access to the electronic control board and the harness connectors, dismantle the door. •...
  • Page 18 REGENERATION CYCLE Each time the regeneration procedure is performed, the chambers are drained completely (about 230ml of water) • Cycle counting for "special" regeneration is performed by the electronic control system and is based on the number of fill phases rather than on the actual number of cycles; this makes the process independent of the number and type of programmes performed.

  • Page 19: Alarm Condition

    ALARM CONDITION In the event of an ALARM condition • Dishwasher operation stopped. • The three Digits in the Display window indicate the corresponding ALARM CODE [ A L ]. • All the Leds switch off. • All the keys Sw1 - Sw5, are disabled including the Cancel function. Example of Alarm:- Heating Time-out: The Display shows [A L 3] (A and L flashing).
  • Page 20 WATER FILL TIME-OUT - ALARM [A L 5] This is a TIME-OUT, which is operative only during the water fill phases. • The control system disconnects the water fill solenoid. • The maximum time open for the fill solenoid is 4min for the entire fill phase. If this time limit is exceeded, an alarm condition is generated.
  • Page 21 OPTIONS FOR IMPROVING WASHING PERFORMANCE In cases in which the user is dissatisfied with the wash performance, a procedure has been developed (exclusively for Service Engineers) that makes it possible to utilise a series of supplementary options which improve the wash performance. These options are memorised in the electronic control system and consist of three functions, each identified by a specific code which allows them to be used when necessary.
  • Page 22 PART 1 Press Sw1 b) SERVICE CUSTOMIZATION – The display will show: DGT_1 [ A ] letter DGT_2 [ ] off DGT_3 [ . ] number [ 0, 1, 2, 3 ] (supplementary options) Example: [ A . 0 ] = no supplementary options (standard setting). Press Sw1 again c) NUMBER OF WASHING CYCLES - the Display shows the number of washing cycles in two phases:...
  • Page 23 With the door CLOSED: Once the test procedure has been started: The component will be tested for a maximum time (Time-out), as shown in the table. To proceed to the subsequent component, press Sw1 until the test procedure is completed. On completion of the test procedure, the display shows [C d 6] to indicate that the last component has been tested.
  • Page 24 INDICATIONS Once the Diagnostics cycle has started, the sub-phase can be advanced according to the sequence of the washing cycle selected, simply by pressing a key. The Display (…) shows the current sub-phase via the 3 digits:- DGT_1 & DGT_2 [ F ] [ d ] Two letters (Abbreviation for Function Diagnostics) DGT_3 [ .

  • Page 25: Test Cycle

    7. To cancel the diagnostics cycle currently being performed, press Sw5 and hold down for 5 seconds. At the end of the cycle, the display shows [ - - - ] for 5 seconds to indicate the end of the programme and the system exits the diagnostics cycle automatically.
  • Page 26 Setting the Test Cycle With the door CLOSED and the dishwasher switched OFF 1. Press and hold down Sw2 & Sw5. 2. Press Sw0 to switch the appliance on. 3. Hold down Sw2 & Sw5 for about 5 seconds until the buzzer sounds. After 5 seconds, the display will show [C O L] (abbreviation for “collaudo”...
  • Page 27 VERIFICATION OF ALARM CODES In order to facilitate identification of an ALARM CONDITION indicated on the control panel and which causes one of the safety features to intervene, the possible causes for each alarm condition are listed in the table below together with suggested solutions. Note: The control board is unlikely to be the cause of an alarm condition, and should therefore be checked last.

  • Page 28: General Data

    GENERAL DATA 220-240 Volt, 50 Hz. (Min. 187 V to Max. 254 V) Power Supply 2300 Watt (Inc. 2100 Watt Heating Element) Total Wattage 11 Litre (Bio programme) Water Consumption 1.1 KWh (Bio programme) Electricity 169 Min. (Bio programme) Duration of Cycle 47 dbA Noise Level Part Nº...
