Electrolux ESI 65010 User Manual

Hide thumbs Also See for ESI 65010:
Table of Contents

Advertisement

Quick Links

user manual
dishwasher
Downloaded from DishWasher-Manual.com Manuals
ESI 65010

Advertisement

Table of Contents
loading

Related Manuals for Electrolux ESI 65010

Summary of Contents for Electrolux ESI 65010

  • Page 1 Downloaded from DishWasher-Manual.com Manuals ESI 65010...
  • Page 2 We were thinking of you when we made this product Downloaded from DishWasher-Manual.com Manuals...
  • Page 3 Electrolux electrolux 3 Welcome to the world of Electrolux Thank you for choosing a first class product from Electrolux, which hopefully will provide you with lots of pleasure in the future. The Electrolux ambition is to offer a wide variety of quality products that make your life more comfortable.

  • Page 4: Table Of Contents

    4 electrolux contents Contents Safety information Product description Control panel First use Daily use Washing programmes Care and cleaning Something not working Technical data Hints for test institutes Installation Environment concerns Guarantee/Customer Service The following symbols are used in this manual: Important information concerning your personal safety and information on how to avoid damaging the appliance.

  • Page 5: Safety Information

    5 Safety information Do not take any dishes out of the dishwasher before the end of the dishwashing cycle. In the interest of your safety and to After use, isolate the appliance ensure the correct use, before...
  • Page 6 6 electrolux safety information Child safety This appliance is designed to be operated by adults. Don’t allow For electrical and water connection children to use the dishwasher carefully follow the instructions unsupervised. given in specific paragraphs. Keep all packaging well away from children.

  • Page 7: Product Description

    7 Product description Upper basket Water hardness dial Salt container Detergent dispenser Rinse aid dispenser Rating plate Filters Lower spray arm Upper spray arm Downloaded from DishWasher-Manual.com Manuals...

  • Page 8: Control Panel

    Control panel On/Off button Programme selection buttons Delay start button Programme button lights, digital display and indicator lights Downloaded from DishWasher-Manual.com Manuals...
  • Page 9 9 Indicator lights Programme in progress Illuminates when a washing programme is set and remains illuminated for all the duration of the washing programme. Turns off when the washing programme has ended. End of programme Illuminates when a washing programme has ended.
  • Page 10 10 electrolux control panel Setting mode Always remember that when: setting the water softener, activating/deactivating the rinse aid dispenser, the appliance MUST be in setting mode: Press On/Off button, ALL programme button lights are illuminated and in the digital display 3 horizontal lines are visible = appliance in setting mode.

  • Page 11: First Use

    11 First use Before using your dishwasher for the Set the water softener first time: The dishwasher is equipped with a Ensure that the electrical and water softener designed to remove water connections comply with the minerals and salts from the water...
  • Page 12 12 electrolux first use The water softener must be set in 3. Press button 1, the lights of both ways: manually, using the water buttons 2 and 3 turn off while the hardness dial and electronically, using light of the button 1 goes on...
  • Page 13 13 Filling with dishwasher salt 4. Replace the cap making sure that there is no trace of salt on the screw thread or on the gasket. 5. Replace the cap tightly turning it Only use salt specifically designed for clockwise until it stops with a click.

  • Page 14: Filling With Rinse Aid

    14 electrolux first use Filling with rinse aid According to the finish and drying results obtained, adjust the dose of Rinse aid ensures thorough rinsing, rinse aid by means of the 6 position and spot and streak free drying. selector (position 1 minimum dosage, Rinse aid is automatically added position 6 maximum dosage).

  • Page 15: Daily Use

    15 Daily use Check if it’s necessary to refill with - Lay small objects in the cutlery dishwasher salt or rinse aid basket. Load cutlery and dishes into the Plastic items and pans with non dishwasher. stick coatings have a tendency to Fill with dishwasher detergent .
  • Page 16 16 electrolux daily use For washing in the dishwasher the following cutlery and dishes are not suitable: - Cutlery with wooden, horn, china or mother-of- pearls handles. - Plastic items that are not heat resistant. - Older cutlery with glued parts that are not temperature resistant.
  • Page 17 17 Open the door and slide out the The two rows of prongs on the lower baskets to load the dishes. basket can be easily lowered to allow you to load pots, pans and bowls. The lower basket...
  • Page 18 18 electrolux daily use The cutlery basket To make loading of the cutlery basket easier, lower the cutlery basket handle (fig.2). Long bladed knives stored in an fig. 2 upright position are a potential hazard. Long and/or sharp items of cutlery...
  • Page 19 19 The cutlery basket is in two parts which can be separated to give greater loading flexibility. To separate the two parts, slide them horizontally in opposite directions and pull them apart (fig. 4). fig. 4 To reassemble, reverse the procedure.
  • Page 20 20 electrolux daily use The upper basket For glasses with long stems (according to the size and The upper basket is designed for dimensions), set the glass holder to saucers, salad bowls, cups, glasses, the left or right position. pots and lids.
  • Page 21 21 Adjusting the height of the upper basket If washing very large plates you can load them in the lower basket after moving the upper basket to the higher position. Maximum height of the dishes in the lower basket...
  • Page 22 22 electrolux daily use Use of detergent 20 = approximately 20 g of detergent 30 = approximately 30 g of detergent Only use detergents specifically 3. All programmes with prewash designed for use in dishwashers. need an additional detergent dose (5/10 g) that must be placed in the Please observe the manufacturer’s...
  • Page 23 23 "Multi-tab function" Activation/deactivation of the Multi- tab function This appliance is equipped with the "Multi-tab function", that allows the Simultaneously press and hold the use of combi detergent tablets. two buttons positioned over the Multi- tab symbol, until the "Multi-tab These products are detergents with a function "indicator light illuminates.
  • Page 24 24 electrolux daily use Activation/deactivation of the rinse aid dispenser 1. Press the On/Off button. The If you decide to turn back to the dishwasher must be in setting use of standard detergent system mode. we advise that you: 1. Deactivate the "Multi-tab function".
  • Page 25 25 Select and start a washing Setting and starting the programme programme with "delay start" 1. After having selected the washing programme, press the delay start button until the flashing number of hours for the delay start will appear Select the washing programme and in the digital display.
  • Page 26 26 electrolux daily use Interrupt or cancel a washing The selection of the washing programme in progress ONLY if it’s programme and delay start can absolutely necessary. also occur with the door closed. Attention! Hot steam may escape Keep in mind that in this way, once when the door is opened.
  • Page 27 27 End of the washing programme The dishwasher will automatically stop and the programme in progress indicator light turns off. The end of programme indicator light will illuminate. The indicator light of the programme just ended will remain The digital display turns off.

  • Page 28: Washing Programmes

    28 electrolux washing programmes Washing programmes Programme Degree of Type of load Programme description soil Prewash Main wash up to 70°C Crockery, 2 intermediate rinses cutlery, pots Heavy soil Final rinse and pans Intensive Drying Prewash Main wash up to 50°C or 65°C...
  • Page 29 29 Washing programmes information (1) During the "Auto" washing programme the amount of soil on the dishes is determined by how cloudy the water is. The programme duration, water and energy consumption levels can vary; this depends upon if...

  • Page 30: Care And Cleaning

    30 electrolux care and cleaning Care and cleaning Cleaning the filters 4. Take hold of the coarse filter (A) by the handle with the hole and The filters must be checked and remove from the microfilter (B). cleaned from time to time. Dirty filters will degrade the washing result.
  • Page 31 31 Frost precautions Avoid placing the machine in a location where the temperature is NEVER try to remove the spray below 0°C. If this is unavoidable, arms. empty the machine, close the If residues of soil have clogged the...

  • Page 32: Something Not Working

    32 electrolux something not working Something not working The dishwasher will not start or stops during operation. Certain problems are due to the lack of simple maintenance or oversights, which can be solved with the help of the indications described in the chart, without calling out an engineer.
  • Page 33 33 Malfunction Possible cause and solution The programme does not start The dishwasher’s door has not been properly closed. Close the door. The main plug is not plugged in. Insert the main plug. The fuse has blown out in the household fuse box.
  • Page 34 34 electrolux something not working The wash results are not satisfactory The dishes are not clean The wrong washing programme has been selected. The dishes are arranged in such a way as to stop water reaching all parts of the surface. The baskets must not be overloaded.

  • Page 35: Technical Data

    35 Technical data Dimensions Width 59.6 cm Height 81.8 - 87.8 cm Depth 55.5 cm Electrical connection Information on the electrical connection is given Voltage - Overall power - on the rating plate on the inner edge of the Fuse dishwasher’s door...
  • Page 36 36 electrolux technical data Consumption values Programme Programme Energy Water duration consumption consumption (in minutes) (in kWh) (in litres) Intensive 110 - 120 1.8 - 2.0 23 - 25 Auto 90 - 115 1.1 - 1.5 12 - 23 Quick 1.05...

  • Page 37: Hints For Test Institutes

    37 Hints for test institutes Testing in accordance with EN 60704 Test in accordance with EN 50242 must be carried out with appliance must be carried out when the salt fully loaded and using the test container and rinse aid dispenser programme (see "Consumption...

  • Page 38: Installation

    38 electrolux installation Installation Levelling Good levelling is essential for correct closure and sealing of the door. Any electrical and/or plumbing When the appliance is correctly work required to install this levelled, the door will not catch on appliance should be carried out by either side of the cabinet.
  • Page 39 39 (Attention! NOT all models of Water inlet hose with safety valve dishwashers have fill and drain hoses After connecting the double-walled provided with locknut. In this case, water inlet hose, the safety valve is this kind of facility is not possible).
  • Page 40 40 electrolux installation Water outlet hose connection The total length of the drain hose, including any extension you might The end of the drain hose can be add, must be no longer than 4 metres. connected in the following ways: The internal diameter of the extension 1.
  • Page 41 41 Electrical connection Safety standards require the appliance to be earthed. Prior to using the appliance for the first time, ensure that the rated voltage and type of supply on the rating plate match that of the supply where the appliance is to be installed.

  • Page 42: Environment Concerns

    42 electrolux environment concerns Environment concerns Packaging material Old appliance The packaging materials are The symbol on the product or on environmentally friendly and can be its packaging indicates that this recycled. The plastic components are product may not be treated as identified by markings, e.g.

  • Page 43: Guarantee/Customer Service

    43 Guarantee/Customer Service Belgium 3. So as to avoid more severe damage, the defect must be DECLARATION OF GUARANTEE brought to our attention TERMS. immediately. Our appliances are produced with the 4. Applying the guarantee is subject greatest of care.
  • Page 44 In this event, we reserve the right to ask for a financial Belgium contribution calculated according Electrolux Home Products Belgium to the length of time it has been ELECTROLUX SERVICE used. Bergensesteenweg 719 1502 Lembeek 13.
  • Page 45 Luxembourg European guarantee Grand-Duché de Luxembourg This appliance is guaranteed by ELECTROLUX HOME PRODUCTS Electrolux, in each of the countries Rue de Bitbourg. 7 listed in the following page, for the L-1273 Luxembourg-Hamm period specified in the appliance guarantee or otherwise by law. If you...
  • Page 46 Domáce spotrebiče SK, Seberíniho 1, 821 03 Bratislava Suomi www.electrolux.fi Sverige +46 (0)771 76 76 76 Electrolux Service, S:t Göransgatan 143, S-105 45 Stockholm Türkiye +90 21 22 93 10 25 Tarlabafl› caddesi no : 35 Taksim Istanbul –ÓÒÒˡ +7 495 9377837 129090 ÃÓÒÍ‚‡, ŒÎËÏÔËÈÒÍËÈ...
  • Page 47 Downloaded from DishWasher-Manual.com Manuals...
  • Page 48 Downloaded from DishWasher-Manual.com Manuals 117991 68/0-00-19012007...
