- Page 1 Electronic Thermostats TAYSTAT 370, 371, 380 OWNER’S GUIDE Pub. No. 22-5184-01 69-1247-1...
- Page 2 FEATURES The Trane Co. sells comfort systems. Comfort is achieved through matching the correct equipment and controls. This thermostat is designed to provide the maximum comfort for your needs. Some of the basic offerings are: • Simple and easy to use. The keys make it easy for you to change your temperature setting.
-
Page 3: Setting System And Fan Switches
SETTINGS Setting SYSTEM and FAN Switches System and fan settings are controlled by using SYSTEM and FAN switches located on the bottom of the thermostat case. Note: When the TAYSTAT 380 is used with two-stage heating equipment, there is an air flow change when the stage change occurs. - Page 4 First set the SYSTEM switch: Cool: Normal setting for months when your home needs cooling (air conditioning). Digital display shows a snowflake when cooling is on. Off: Both heating and cooling are off. Heat: Normal setting for months when your home needs heating.
- Page 5 Displaying Temperature Setting NOTE: Your temperature setting can be set anywhere from 50° to 99°F (10° to 37°C). The temperature setting and the room temperature display separately. The indicator points to Set when the temperature setting displays, and to Room when the room temperature displays.
-
Page 6: Changing Temperature Setting
Changing Temperature Setting 1. To lower the temperature setting, press the key. When in the heating mode, lowering the temperature at night or during the day can lower your energy costs. Room M18442 2. To raise the temperature setting, press the key. - Page 7 CAUTION Equipment Damage Hazard. Can cause permanent damage to the compres- sor or other equipment. To avoid possible equipment damage, do not operate cooling when outside temperature is below 50°F (10°C). See equipment manufacturer instructions. To avoid possible compressor damage, allow the compressor to remain off for five minutes before restarting.
-
Page 8: Troubleshooting Guide
TROUBLESHOOTING GUIDE Symptom Action Heating or Check that the SYSTEM switch on Cooling will not the thermostat is set to Heat come on. or Cool. Check if the circuit breaker is tripped—reset the circuit breaker. Check if the fuse is blown— replace the fuse. -
Page 9: Limited Warranty
LIMITED WARRANTY Low Voltage Room Thermostats This warranty is extended by American Standard Inc., to the original purchaser and to any succeeding owner of the real property to which the Thermostat is originally affixed, and applies to products purchased and retained for use within the U.S.A. - Page 10 This warranty does not cover failure of your Thermostat if it is damaged while in your possession or if the failure is caused by unreasonable use. In no event shall Warrantor be liable for incidental or consequential damages. In no event shall any implied warranty of merchandise or fitness for use exceed the terms of the limited warranty stated above.
- Page 11 Parts will be provided by our factory organization or an authorized service organization in your area. All you need to do is look us up in the Yellow Pages or write to the address given below. If you wish further help or informa- tion concerning this warranty, contact: American Standard Inc.
-
Page 12: Customer Assistance
CUSTOMER ASSISTANCE If, after reading this guide, you have any questions concerning the operation of your thermostat, please call the Thermostat Customer Assistance Helpline at 1-877-880-3381, Monday-Friday, 7:00 am-5:30 p.m., Central time. For service, contact your local heating and cooling contractor.
