Spyder
Programmable Controllers
Controller Programmable
Model Type
PUB1012S Unitary
PUB4024S Unitary
PUB6438S Unitary
PVB000AS VAV
PVB4022AS VAV
PVB4024NS VAV
PVB6436AS VAV
PVB6438NS VAV
Each controller communicates via an EIA-485 BACnet MS/TP network communications network, capable of baud rates between
9.6 and 115.2 kilobits.
Controllers are field-mountable to either a panel or a DIN rail.
SPECIFICATIONS
General Specifications
Rated Voltage: 20–30 Vac; 50/60 Hz
Power Consumption:
100 VA for controller and all connected loads (including the
actuator on models models PVL0000AS, PVL4022AS,
and PVL6436AS).
Controller Only Load: 5 VA maximum; models PUB1012S,
PUB4024S, PUB6438S, PVB4024NS, and PVB6438NS.
®
BACnet
Table 1. Controller configurations.
Universal Digital
Inputs Inputs
(UI) (DI)
0
a
1
0
a
4
6 4
0 0
a 0
4
0
a
4
6 4
6 4
INSTALLATION INSTRUCTIONS
PRODUCT DESCRIPTION
The PUB and PVB controllers are part of the Spyder family.
These controllers are BACnet MS/TP network devices
designed to control HVAC equipment. These controllers
provide many options and advanced system features that
allow state-of-the-art commercial building control. Each
controller is programmable and configurable through software.
These controllers are for use in VAV (Variable Air Volume),
Unitary, and advanced HVAC applications. Each controller has
flexible, universal inputs for external sensors, digital inputs,
and a combination of analog and digital Triac outputs. All the
models are described in Table 1. The photo to the left is the
model PVB6436AS, which includes the actuator.
Analog Digital
Outputs Outputs
(AO) (DO)
1 2
2 4
3 8
0 0
2 2
2 4
3 6
3 8
Controller and Actuator Load: 9 VA maximum; models
PVL0000AS, PVL4022AS, and PVL6436AS.
External Sensors Power Output: 20 Vdc ±10% @ 75 mA max-
imum.
VAV Operating & Storage Temperature Ambient Rating (mod-
els PVB0000AS, PVB4022AS, PVB4024NS, PVB6436AS,
and PVB6438NS).:
Minimum 32 ºF (0 ºC); Maximum 122 ºF (50 ºC)
Unitary Operating & Storage Temperature Ambient Rating
(models PUB1012S, PUB4024S, and PUB6438S.):
Minimum -40 ºF (-40 ºC); Maximum 150 ºF (65.5 ºC)
Relative Humidity: 5% to 95% non-condensing
LED: Provides status for normal operation, controller down-
load process, alarms, manual mode, and error conditions
Velocity
Pressure Series 60
Sensor Floating
(Microbridge) Actuator
NO NO
NO NO
NO NO
YES YES
YES YES
YES NO
YES YES
YES NO
Put Bar Code Here
62-0310-04
