Congratulations on purchasing this state-of-the-art Weather Station as an example of fine design and quality piece of engineering. The operation of this product is simple and
straightforward. By reading this instruction manual, users will receive a better understanding of the Weather Station together with the optimum benefit of all its features.
The Weather Station
LCD
Display
The Temperature Transmitter
Features of the Weather Station
•
4 digits LCD time display
•
Current indoor temperature display in degree Fahrenheit
•
Simultaneous minimum and maximum indoor temperature recordings
•
Current relative humidity display with "☺" Smilling or " " Sad face for comfort level reading.
•
3 weather icons for weather forecasting
•
Weather tendency indicator
•
Relative air pressure inHg with adjustable reading ranges
•
Air pressure history for the past 72 hours (electronic barometer with barometric pressure and trend)
•
Current outdoor temperature display in degree Fahrenheit
•
Simultaneous minimum and maximum outdoor temperature recordings.
•
LCD contrast changeable to 8 different tones
•
Low battery indicator
•
Wall mounting
Features of the Temperature Transmitter:
•
Remotely transmits outdoor temperature at 433MHz to the Weather Station
•
With wall mounting holder
Getting Started
Please follow these steps to ensure that your Weather Station and Temperature Transmitter work correctly together:
Remove all pieces from the packaging and place onto a table in front of you.
Check that you have complete:
1.
Weather Station
2.
433MHz temperature transmitter
3.
Sealed pack with 3 screws and double-sided tape for wall mounting the transmitter
Setting up
(picture of the weather station; cover separate from the unit)
Battery
cover
Battery compartment
Wireless Weather Station
Instruction Manual
Hanging Hole
Holder
Battery
compartment
Battery
cover
+ Key
Advertisement
Related Manuals for La Crosse Technology WS-7090U
Summary of Contents for La Crosse Technology WS-7090U
- Page 1 Congratulations on purchasing this state-of-the-art Weather Station as an example of fine design and quality piece of engineering. The operation of this product is simple and straightforward. By reading this instruction manual, users will receive a better understanding of the Weather Station together with the optimum benefit of all its features.
-
Page 2: Lcd Contrast Setting
LCD contrast setting There are 8 different LCD contrast tones to suit the hanging level of the Weather Sation (default at Level 5). Simply hang the Weather station in the desired place and adjust the contrast level so that the LCD digits are sharp and clear from that particular level. - Page 3 For every sudden or significant change in the air pressure, the weather icons will update accordingly to represent the change in weather. If the icons do not change, then it means either the air pressure has not changed or the change has been too slow for the Weather station to register. However, if the icon displayed is a sun or raining cloud, there will be no change of icon if the weather gets any better (with sunny icon) or worse (with rainy icon) since the icons are already at their extremes.
- Page 4 After the resetting or setting up, weather readings should be discarded for the next 12 to 24 hours as this will allow sufficient time for the Weather Station to operate at a constant altitude and thus enabling a more accurate reading.
- Page 5 Fix a screw (not supplied) into the desired wall, leaving the head extended out by about 5mm. Using the Weather Station’s hanging hole, carefully hang it onto the screw. Remember to ensure that it locks into place before releasing. Option 2 – using four permanent fixing screws Carefully remove the front cover as described in Setting up (above) Hold the Weather Station level against the wall and using a sharp object or pen, mark the four points.
-
Page 6: Specifications
(1hPa = 0.03 inch mercury (inHg)) (0, -1, -3, -6, -12, -24, -48, -72) Temperature checking intervals Indoor : 10 seconds Outdoor to the weather Station : twice in 10 minutes Transmitter temperature reading update : 30 seconds Transmitting frequency... -
Page 7: Warranty Information
La Crosse Technology provides a 1-year warranty on this weather station. Contact La Crosse Technology immediately upon discovery of any defects covered by this warranty. Before sending the Weather Station in for repairs, contact La Crosse Technology. The Weather Station will be repaired or replaced with the same or similar model.
