Craftsman C459-62102 Operator's Manual

Front tine tiller, 208cc engine
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Operator's Manual
208cc Engine
Front Tine Tiller
Model No. C459-62102
CAUTION: Before using this
product, read this manual
and follow all safety rules
and operating instructions.
Sears Canada Inc., 290 Yonge Street, Toronto, On M5B 2C3
®
Visit our web: sears.ca
• SAFETY
• ASSEMBLY
• OPERATION
• MAINTENANCE
• PARTS LIST
769-06799
4/12/2012

Advertisement

Table of Contents
loading

Related Manuals for Craftsman C459-62102

Summary of Contents for Craftsman C459-62102

  • Page 1 Operator’s Manual ® 208cc Engine Front Tine Tiller Model No. C459-62102 • SAFETY • ASSEMBLY • OPERATION • MAINTENANCE • PARTS LIST CAUTION: Before using this product, read this manual and follow all safety rules and operating instructions. Sears Canada Inc., 290 Yonge Street, Toronto, On M5B 2C3 769-06799 Visit our web: sears.ca...

  • Page 2: Table Of Contents

    TABLE OF CONTENTS Safe Operation Practices ..... 3 Off-Season Storage ......22 Safety Symbols .

  • Page 3: Safe Operation Practices

    SAFETY INSTRUCTIONS Warning Danger This machine was built to be operated according to the safe opera- This symbol points out important safety instructions which, if not tion practices in this manual. As with any type of power equipment, followed, could endanger the personal safety and/or property of carelessness or error on the part of the operator can result in yourself and others.
  • Page 4 SAFETY INSTRUCTIONS Safe Handling of Gasoline: • Look down and behind and use care when in reverse or pulling machine towards you. To avoid personal injury or property damage use extreme care in handling gasoline. Gasoline is extremely flammable and the vapors are •...
  • Page 5 SAFETY INSTRUCTIONS noTice regarDing eMiSSionS • Do not change the engine governor settings or over-speed the engine. The governor controls the maximum safe operating speed Engines which are certified to comply with California and federal of engine. EPA emission regulations for SORE (Small Off Road Equipment) are •...

  • Page 6: Safety Symbols

    SAFETY INSTRUCTIONS SafeTy SyMbolS This page depicts and describes safety symbols that may appear on this product. Read, understand, and follow all instructions on the machine before attempting to assemble and operate. Symbol Description READ THE OPERATOR’S MANUAL(S) Read, understand, and follow all instructions in the manual(s) before attempting to assemble and operate WARNING—...

  • Page 7: Safety Labels

    SAFETY LABELS S33894 2.5 cm 7.5 cm 12.5 cm 18.5 cm 10W30...

  • Page 8: Assembly & Adjustments

    ASSEMBLY IMPORTANT: This unit is shipped without gasoline or oil in the engine. Be certain to service engine with gasoline and oil as instructed in the Operation section of this manual before operating your machine. NOTE: Reference to right and left hand side of the Tiller is observed from the operating position.
  • Page 9 ASSEMBLY Tighten the bolt securely after securing the handle brace. See Figure 4. Locate the carriage bolt, bell washer and hand knob packed with your tiller. tail Bracket Insert the carriage bolt through the welded bracket on the handle, bell washer, handle brace and into the hand knob. See Figure 4. Select one of the three handle height positions (three notches in the welded handle bracket) and tighten the hand knob to secure Clevis...
  • Page 10 ASSEMBLY aDjUSTMenTS Warning Prior to operating your tiller, carefully read and follow all instructions below. Perform all adjustments to verify your tiller is operating safely and properly. Hex nut Check the adjustment of the wheels: The tiller is shipped with the wheels adjusted so that the machine sits level.

  • Page 11: Operation

    STOP position. Meets anSi Safety Standards Craftsman Tillers conform to the safety standard of the American National Standards Institute (ANSI).
  • Page 12 OPERATION air filTer Subsequent Uses Only use high quality detergent oil rated with API service classifica- The air filter is a device on the engine air intake that prevents dust and tion SF, or SG. Select the oil’s SAE viscosity grade according to the dirt entering the engine.
  • Page 13 OPERATION To STarT engine To engage DriVe & TineS Attach spark plug wire and rubber boot to spark plug. For forward motion of the wheels and power to the tines pull the Fill tank to no more than 1/2 inch below bottom of filler neck to Forward Clutch Bail up against the handlebar.
  • Page 14 OPERATION yoke back Attach the wheel yoke so that the wheels are toward the rear (closest to depth stake) for deep tilling and cultivating by removing the clevis pin and cotter pin. See Figure 15. wheel Yoke Handle Knob Figure 17 wheel •...
  • Page 15 OPERATION Figure 19 Figure 18 Suggested Tilling Patterns • When preparing a seedbed, go over the same path twice in the first row, then overlap one-half the tiller width on the rest of the passes. See Figure 19. • When finished in one direction, make a second pass at a right angle, See Figure 20.
  • Page 16 OPERATION Tilling on a Slope Till only on moderate slopes, never on steep ground where the footing is difficult. Tilling up and down slopes is recommended over terracing. Tilling UPhill vertically on a slope allows maximum planting area and also leaves room for cultivating.

  • Page 17: Service & Maintenance

    SERVICE AND MAINTENANCE MainTenance ScheDUle Warning Follow the maintenance schedule given below. This chart describes Before performing any type of maintenance/service, disengage all service guidelines only. Use the Service Log column to keep track of controls and stop the engine. Wait until all moving parts have come to completed maintenance tasks.
  • Page 18 SERVICE AND MAINTENANCE Remove the spark plug boot and use a spark plug wrench to remove the plug. See Figure 23. Visually inspect the spark plug. Discard the spark plug if there is apparent wear, or if the insulator is cracked or chipped. Clean the spark plug with a wire brush if it is to be reused.
  • Page 19 SERVICE AND MAINTENANCE check engine oil Check oil before each use. Stop engine and wait several minutes before checking oil level. With the tiller on level ground, the oil must be to FULL mark on dipstick. Remove oil fill dipstick and wipe clean with cloth. Replace dipstick into the oil filler neck, but do not screw it in.
  • Page 20 SERVICE AND MAINTENANCE lUbricaTion After every 10 operating hours, oil or grease the lubrication points. Use clean lubricating oil (#30 weight motor oil is suitable) and clean general purpose grease (grease containing a metal lubricant is preferred, if available). • Remove the tines and clean the tine shaft.
  • Page 21 SERVICE AND MAINTENANCE TineS The tines will wear with use and should be inspected at the beginning of each tilling season and after every 30 operating hours. The tines can be replaced. Refer to the Parts List section of this manual for part Clevis Pin numbers.

  • Page 22: Off-Season Storage

    OFF-SEASON STORAGE Warning Never store tiller with fuel in tank indoors or in poorly ventilated areas where fuel fumes may reach an open flame, spark, or pilot light as on a furnace, water heater, clothes dryer, or gas appliance. PreParing The Tiller Warning When the tiller won’t be used for an extended period, prepare it for Never leave engine unattended while it is running.

  • Page 23: Troubleshooting

    TROUBLESHOOTING Warning Before performing any type of maintenance/service, disengage all controls and stop the engine. Wait until all moving parts have come to a complete stop. Disconnect spark plug wire and ground it against the engine to prevent unintended starting. Always wear safety glasses during operation or while performing any adjustments or repairs. Problem cause remedy...

  • Page 24: Parts List (Tiller)

    PARTS LIST craftsman Tiller — Model no. c459-62102...
  • Page 25 PARTS LIST craftsman Tiller — Model no. c459-62102 PART DE SCRIP TION 686-0081A-0637 Wheel Hanger Brkt. Ass’y 911-0415 Clevis Pin 3/8 Dia 714-04043 Bow Tie Cotter Pin 734-04547 Wheel Assembly 8 x 1.75 738-0929 Shoulder Screw .496 ID x 1.445 OD 710-0805 Hex Bolt 5/16-18 x 1,50"...
  • Page 26 PARTS LIST craftsman Tiller — Model no. c459-62102 39 31...
  • Page 27 PARTS LIST craftsman Tiller — Model no. c459-62102 PART DE SCRIP TION 986-0091 Chain Case Assembly Complete 642-0002-0637 Inner Tine Ass’y - RH 642-0003-0637 Inner Tine Ass’y - LH 642-0004-0637 Outer Tine Ass’y LH 642-0005-0637 Outer Tine Ass’y RH 911-0415...

  • Page 28: Parts List (Engine)

    PARTS LIST craftsman engine Model 170-V0b for c459-62102. Ref. Part No. Description 951-11285 Exhaust Pipe Gasket 712-04214 Nut, M8 751-12294 Muffler Assembly 710-05002 Bolt 951-10806 Air Cleaner Housing 712-04213 710-05102 Self-Tapping Bolt M4.2×16 951-12135 Silencer Plate 951-10794 Air Cleaner Assembly...
  • Page 29 PARTS LIST craftsman engine Model 170-V0b for c459-62102. Ref. Part No. Description Ref. Part No. Description 951-10797 Carburetor Assembly Float Pin 951-11571 Carburetor Gasket Plate Emulsion Tube 951-11177 Control Lever,Choke Needle Valve Choke Shaft Main Jet Choke Plate Needle Valve Spring...
  • Page 30 PARTS LIST craftsman engine Model 170-V0b for c459-62102.
  • Page 31 PARTS LIST craftsman engine Model 170-V0b for c459-62102. Ref. Part No. Description 951-11253 Piston Ring Set 951-11632 Piston Pin Snap Ring 951-12007 Piston 951-11633 Piston Pin 710-04915 Bolt M6×12 951-11113 Air Shield 951-11573 Connecting Rod Assembly 951-11356 Governor Arm Shaft 736-04461 Washer 5.2×1.9...
  • Page 32 PARTS LIST craftsman engine Model 170-V0b for c459-62102.
  • Page 33 PARTS LIST craftsman engine Model 170-V0b for c459-62102. Ref. Part No. Description Ref. Part No. Description 710-05276 Muffler Stud M8×36 710-04968 Bolt M6×16 951-10657 Muffler Stud Assembly 951-11054 Valve Cover 710-05101 Stud M6×110 731-07059 Breather Hose 951-11567 Carburetor Insulator Gasket...
  • Page 34 PARTS LIST craftsman engine Model 170-V0b for Model c459-62102 Ref. Part No. Description 951-12126 Oil Seal 25×41.25×6 951-10792 Ignition Coil Assembly 710-04919 Bolt M6×25 951-10805 Flywheel 951-10909 Fan, Cooling 951-10911 Pulley, Starter 712-04209 Nut, Special, M14×1.5 710-04915 Bolt M6×12 951-11583...
  • Page 35 PARTS LIST craftsman engine Model 170-V0b for c459-62102 Ref. Part No. Description Ref. Part No. Description 710-04968 Bolt M6×16 951-11914 Dipstick Decoration Cover 951-11067 Throttle Control Knob 710-04905 Bolt 951-12131 Primer Bracket 710-04915 Bolt M6×12 710-04928 Bolt M6×12 951-11903 Oil Fill Tube O-Ring...
  • Page 36 Parts List craftsman Tiller Model no. c459-62102 777D16042 777D15447 777S33318 777I23189 777I23190 777I23259 777I23174 777D16043 777S33612 10W30 777D16041...

  • Page 37: Warranty Statement

    WARRANTY STATEMENT General: Craftsman products are warranted to be free from defects in materials or workmanship for a specific time period as set-out below (the “Warranty Period”). Warranties extend to the original purchaser of a Craftsman product only. Purchases made through an online auction or through any website other than www.sears.ca are excluded.
  • Page 38 (This page applicable in the U.S.A. and Canada only.) Sears brands Management corporation (Sears), the california air resources board (carb) and the United States environmental Protection agency (U.S. ePa) emission control System Warranty Statement (owner’s Defect Warranty rights and obligations) EMISSION CONTROL WARRANTY COVERAGE IS APPLICABLE TO CERTI- YEAR 1997 AND LATER ENGINES WHICH ARE PURCHASED AND USED FIED ENGINES PURCHASED IN CALIFORNIA IN 1995 AND THEREAF-...
  • Page 39 look for relevant emissions Durability Period and air index information on your engine emissions label Engines that are certified to meet the California Air Resources Board (CARB) Tier 2 Emission Standards must display information regarding the Emissions Durability Period and the Air Index. Sears Brands Management Corporation makes this information available to the consumer on our emission labels.

  • Page 40: 1-800-4-My-Home

    REPAIR PROTECTION AGREEMENT Congratulations on making a smart purchase. Your new Craftsman® Once you purchase the Agreement, a simple phone call is all that it product is designed and manufactured for years of dependable opera- takes for you to schedule service. You can call anytime day or night, or tion.
  • Page 41 02488 Trademarks of Sears Brands Management Corp. used under license by Sears Canada Marque déposée / Marque de commerce de Sears Brands Management Corp. utilisée en vertu d’une licence de Sears Canada...
  • Page 42 NOTES...
