MODEL: WHE7074SA Diagnostic Manual
WHE7074SA 925060317-00
Version
Status
Date
first edition
1
modified from documents provided by
NICOLA BEGGIO
ARESI1004 Issue 1
Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services
Diagnostics Procedure
Double Freezer Westinghouse French Door
-
Created/
Modified by
11/06/2018 Warren Steele
Comment
1
Advertisement
Related Manuals for Electrolux WHE7074SA
Summary of Contents for Electrolux WHE7074SA
- Page 1 WHE7074SA 925060317-00 Diagnostics Procedure Double Freezer Westinghouse French Door Version Status Date Created/ Comment Modified by first edition 11/06/2018 Warren Steele modified from documents provided by NICOLA BEGGIO ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 2 Westinghouse UI Functional Areas The image below shows the following functional areas: Light guide windows: Area through which light will be conducted to light the first surface Icons. ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 3 MODEL: WHE7074SA Diagnostic Manual Capacitive touch areas: Areas that will be sensitive to the touch of the user. ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 4 How to enter The Diagnostic Mode: "+" (freezer) and "–" (freezer) To enter The diagnostic mode, press and hold buttons for 10 seconds during the normal runtime of the appliance ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 5 Availible Test a. Turns On all the LED's of the Display Initial diagnostic start up - a. Turns Off all the LED's of the Display First Push "+" ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 6 It may take a few minutes for the evaporator to heat up. Maximum 5 e. Press (CUBE) button to change the minutes ON or 45°C Fresh Food Evap Defrost sensor threshold. status ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 7 Fan runs on maximum speed when “on”; the load L ”; stopped when medium speed when “ “oF” is displayed c. Press (CUBE) button to change the status. ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 8 Press (CUBE) to c. Chute Heater is activated when “on”, Heater change the status of deactivated when “oF”. the load d. Press (CUBE) button to change the status. ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 9 DC Water Pump is piloted and it is Pump change the status of possible to have 3 states. the load. b. When pump is stopped “oF” is showed. Then you have reverse piloting displaying “rv”. ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 10 Arm/ Ice bail arm. . the load Level Bucket b. Allow bail arm to drop freely. It shows “Em” (empty) when tray returns to “home” position. Continue..next page ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 11 Reed Switch when door closed; “OP” when is open. Dispenser Press the Dispenser a. On Refrigerator Display it shows “CL” Paddle Paddle when door closed; “OP” when is open. ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
-
Page 12: Ambient Temperature Sensor
IceMaker Tray Sensor. b. It is displayed in °C or ° F according to UI selection of the temperature representation. c. “OP” if open-circuit; “SH” if short-circuit. ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services... - Page 13 Version of the string. User Interface (main UI) b. It is built of 8 digits. The same digit is displayed simultaneously on the 2 displays (Freezer and Refrigerator). ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
- Page 14 Convertible SEA market. 3) Items n° 17, 32, 74, 76, 77 are not present on Double Freezer Asia Pacific Westinghouse WHE7074SA because the VCZ compartment is not present and the drawer works as standard freezer. 4) The ID_String related to software version of the Indigo User Interface is not displayed for Double Freezer Asia Pacific Westinghouse model WHE7074SA because the UI on the VCZ drawer is not present.
- Page 15 MODEL: WHE7074SA Diagnostic Manual Seven-segment display character representation Appendix A. Numbers: Letters: ARESI1004 Issue 1 Copyright 2018 ELECTROLUX HOME PRODUCTS PTY LTD Technical Services...
