- Page 1 User Manual for CPS825AVR with USB Interface and PowerPanel Plus™ Software ADDITIONAL INSTALLATION TIPS CAN BE FOUND AT www.cyberpowersystems.com/faqs.htm...
-
Page 2: Table Of Contents
AUTOMATIC VOLTAGE REGULATOR The CPS825AVR controls utility power voltage levels that can be inconsistent. The incoming utility power may be at a damaging level to important data files, but with the Automatic Voltage Regulation of the CPS825AVR the computer will only experience a consistent voltage level. -
Page 3: Description
Insure that the equipment plugged into the three battery power-supplied outlets does not exceed the UPS unit’s rated capacity (825VA/410W for CPS825AVR). If rated unit capacities are exceeded, an overload condition may occur and cause the UPS unit to shut down or the circuit breaker to trip. -
Page 4: Hardware Installation Guide
HARDWARE INSTALLATION GUIDE Your new UPS may be used immediately upon receipt. However, recharging the battery for at least four hours is recommended to insure that the battery’s maximum charge capacity is achieved. Charge loss may occur during shipping and storage. To recharge the battery, simply leave the unit plugged into an AC outlet. - Page 5 Turn off your UPS Connect the Serial Cable to your UPS and the open serial port on the rear panel of the computer. If you would like to use USB interface, please connect the USB adapter with the Serial Cable then connect the USB to your computer.
-
Page 6: Software User Manual
FOR WINDOWS 2000 Click on Start, point to Settings, and then click Control Panel. Double-click on Power Options. On the UPS Tab, click Select. In the UPS Selection Dialog Box, under Manufacturers, click None. Exit to the desktop. Shutdown the computer. Turn the UPS off and unplug it. - Page 7 Setup Button: Click the setup button to open the Setup Window. Model: This shows the model of the CyberPower UPS that is being used. Version: This shows the hardware version. Status Bar: The area display messages about the status of the software.
- Page 8 POWERPANEL PLUS™ SETUP WINDOW Play Sound: With this option enabled, the software will play audible voice messages through your computer speakers. A sound card and speakers are required Time between Power Failure and Shutdown: This is the user controllable delay between when the power fails and the software starts the shutdown process.
- Page 9 Special Setting: This setting allows you to schedule a one-time startup/shutdown Schedule Display: This area displays the days/dates and times of any scheduled startups and shutdowns. Turn On: Select the day/date and time that you want the computer system to restart. Can only be used in conjunction with a scheduled shutdown.
- Page 10 The UPS will begin beeping, indicating a power failure. Save and close any open files. Shut down the operating system. Once the computer system is shutdown, turn the UPS off. As the battery discharges, the unit will beep more rapidly, indicating that the battery is nearing discharge. Once the test is complete, plug the UPS back in to the AC outlet and start your computer.
- Page 11 REMINDER: Batteries are consider HAZARDOUS WASTE and must be disposed properly. Contact your local government for more information about proper disposal and recycling of batteries.
- Page 12 AC outlet. User is advised to disconnect all electrical equipment from the outlet and have the outlet checked by an electrician. APPROXIMATE RUNTIME IN MINUTES Sample Systems Load CPS825AVR Model Desktop PC with 15” Monitor 45-60 (Watts) Runtime Desktop PC with 17” Monitor 30-45 Desktop PC with 21”...
-
Page 13: Led Indicators
Battery not fully charged. Recharge the battery by leaving the UPS plugged in. expected runtime. Battery is slightly worn out. Contact CyberPower Systems about replacement batteries at tech@cyberpowersystems.com The on/off switch is designed to prevent Turn the UPS off. Wait 10 seconds and then turn the UPS on. -
Page 14: Warranty
CyberPower will inspect and examine the Product within ten (10) days of receipt. If the Product is not as warranted, CyberPower will repair or replace the Product and return it to you at CyberPower’s expense, or, if CyberPower is unable to or decides not to repair or replace the Product (if defective) within a reasonable time, CyberPower will refund to you the full purchase price you paid for the Product (purchase receipt showing price paid is required). - Page 15 Guarantee, CyberPower will (in addition to Limited Warranty remedies for the CyberPower Product itself) repair (or pay the costs of repair) or replace the Connected Equipment or, at the option of CyberPower, as permitted by law, pay to the Initial Customer the “Agreed Damage Amount”...
- Page 16 (collectively, “High Risk Activities”). CyberPower expressly disclaims any express or implied warranty of fitness for High Risk Activities. CyberPower does not authorize use of any of its products use in any High Risk Activities.
- Page 17 Toll-Free: (877)-297-6937 Tel: (952)-403-9500 Fax: (952)-403-0009 Email: sales@cyberpowersystems.com Web: www.cyberpowersystems.com Entire contents copyright ©2002 CyberPower Systems, Inc. All rights reserved. Reproduction in whole or in part without permission is prohibited. PowerPanel Plus™ is a trademark of CyberPower Systems (USA), Inc.
