Operators Manual
Direct Steam Table Top Kettles
Table-Top Direct
Steam Kettles
MODELS: KDT- 1 - T
KDT- 3 - T
KDT- 6 - T
KDT-12 - T
KDT-20 - T
SD Stands
MODELS: SD - 450
SD - 650
SD - 760
SD -1050
SD -1200
SD -1600
SD -1800
Kettles on
SD Stands
MODELS: SD -450 - K 6
SD -650 - K12
SD -760 - K12
SD -760 - K20
SD -1050 - K 6 6
SD -1200 - K 6 12
SD -1600 - K 6 20
SD -1600 - K12 12
SD -1600 - K12 20
SD -1600 - K20 20
™
Cleveland
Enodis
Installation, Operation & Service
1333 East 179th St., Cleveland, Ohio, U.S.A. 44110
Phone: (216) 481-4900 Fax: (216) 481-3782
Visit our web site at www.clevelandrange.com
SE95008 Rev. 6
