  • Page 1: Operation Guide

    FS-1030D Operation Guide...

  • Page 3: Table Of Contents

    Prolonged Non-Use and Moving the Printer ........
  • Page 4 OPERATION GUIDE...

  • Page 5: Legal And Safety Information

    Copying or other reproduction of all or part of this guide, any copyrightable subject matter without the prior written consent of Kyocera Mita Corporation is prohibited. Any copies made of all or part of this guide, any copyrightable subject must contain the same copyright notice as the material from which the copying is done.
  • Page 6 License Agreements IBM Program License Agreement This product was developed using the Tornado™ Real Time Operating System and Tools from Wind River Systems. This product contains UFST™ and MicroType Inc. THE DEVICE YOU HAVE PURCHASED CONTAINS ONE OR MORE SOFTWARE PROGRAMS (“PROGRAMS”) WHICH BELONG TO INTERNATIONAL BUSINESS MACHINES CORPORATION (“IBM”).
  • Page 7 Province of Ontario. Otherwise, this license is governed by the laws of the country in which you acquired the Program. All resident fonts in this printer are licensed from Monotype Imaging Inc. Helvetica, Palatino and Times are registered trademarks of Linotype-Hell AG.
  • Page 8 Monotype Imaging License Agreement “Software” shall mean the digitally encoded, machine readable, scalable outline data as encoded in a special format as well as the UFST Software. You agree to accept a non-exclusive license to use the Software to reproduce and display weights, styles and versions of letters, numerals, characters and symbols (“Typefaces”) solely for your own customary business or personal purposes at the address stated on the registration card you return to Monotype Imaging.
  • Page 9 Compliance and Conformity FCC statement (for users in the United States) OPERATION GUIDE IN NO EVENT WILL MONOTYPE IMAGING BE LIABLE FOR LOST PROFITS, LOST DATA, OR ANY OTHER INCIDENTAL OR CONSEQUENTIAL DAMAGES, OR ANY DAMAGES CAUSED BY ABUSE OR MISAPPLICATION OF THE SOFTWARE AND TYPEFACES.

  • Page 10: Precautions For Use

    Shielded circular cables should be used for interfacing with the computer. Any modifications without prior permission of Kyocera may cause harmful interference. If any modifications or changes are made to this equipment without prior permission of Kyocera, Kyocera as the manufacturer does not guarantee the compliance with the FCC Rules.

  • Page 11: Caution Labels

    To minimize the concentration of ozone gas to less than 0.1 ppm, we recommend you not to install the printer in a confined area where ventilation is blocked. Label inside the machine (Laser radiation warning) For Europe, Asia, For U.S.A.
  • Page 12 Manufacturer's address: 704-19 Nojino, Tamaki-Cho, Watarai-Gun, Mie- Ken 519-0497, Japan Declares that the product: Product name: Page Printer Model number: FS-1030D (as tested with the enhancement optional unit: PF-17 and IB-21E) Conforms to the following product specifications. EN 55 022:1998+A1:2000+A2:2003 Class B...
  • Page 13 Model number: FS-1030D (as tested with the enhancement optional unit: PF-17 and IB-21E) Description of device: This page printer model FS-1030D is 22-ppm; A4 size and utilized plain paper; laser; dry toner etc. The printer can be equipped with the optional paper feeder model PF-17.

  • Page 14: Energy Star Program

    Maschinenlärminformations-Verordnung 3. GPSGV: Der höchste Schalldruckpegel beträgt 70 dB (A) oder weniger gemäß EN ISO 7779. Kyocera Mita will not be liable to customers or any other person or entity for any loss or damage caused or alleged to be caused directly or indirectly...
  • Page 15 Group for Energy Efficient Appliances (GEEA) Please read this Operation Guide before using the machine. Keep it close to the machine for easy reference. Symbols OPERATION GUIDE The goal of GEEA is efficient use of energy. This product has a high- efficiency profile and meets the criteria for receiving the GEEA-Label.

  • Page 16: Installation Precautions

    Installation Precautions Environment The following symbols indicate that the related section includes information on prohibited actions. Specifics of the prohibited action are indicated inside the symbol. [Warning of prohibited action] [Disassembly prohibited] The following symbols indicate that the related section includes information on actions which must be performed.

  • Page 17: Other Precautions

    During printing, some ozone is released, but the amount does not cause any ill effect to one's health. If, however, the printer is used over a long period of time in a poorly ventilated room or when printing an extremely large number of copies, the smell may become unpleasant.
  • Page 18 Power Supply/Grounding the Machine Other Precautions Handling of Plastic Bags WARNING: Do not use a power supply with a voltage other than that specified. Avoid multiple connections in the same outlet. These types of situations present a danger of fire or electrical shock. Plug the power cord securely into the outlet.
  • Page 19 Precautions for Use Cautions when Using the Machine WARNING: Do not place metallic objects or containers with water (flower vases, flower pots, cups, etc.) on or near the machine. This situation presents a danger of fire or electrical shock should they fall inside.
  • Page 20 CAUTION Do not pull the power cord when removing it from the outlet. If the power cord is pulled, the wires may become broken and there is a danger of fire or electrical shock. (Always grasp the power plug when removing the power cord from the outlet.) Always remove the power plug from the outlet when moving the machine.
  • Page 21 Cautions when Handling Consumables Other Precautions OPERATION GUIDE CAUTION Use of controls or adjustments or performance of procedures other than those specified herein may result in hazardous radiation exposure. CAUTION Do not attempt to incinerate the Toner Container. Dangerous sparks may cause burns. Keep the Toner Container out of the reach of children.
  • Page 22 Chapter 2 - Loading Paper This chapter explains on loading paper. Chapter 3 - Connecting and Printing This chapter explains on setting the printer up ready for use, and how to print from your workstation. Chapter 4 - Maintenance This chapter explains how to replace the toner container and how to care for your printer.
  • Page 23 35 for information. IMPORTANT: Ensure paper is not stapled and clips are removed. CAUTION: Do not attempt to incinerate the toner container. Dangerous sparks may cause burns. WARNING: Keep the plastic bags that are used with the printer away from children.
  • Page 24 xxii OPERATION GUIDE...

  • Page 25: Machine Parts

    Paper Stopper Top Cover MP Tray Cassette Front Cover OPERATION GUIDE 1 Machine Parts Output Tray Option Interface Slot Cover Side Cover USB Interface Connector Operation Panel Ready Indicator Data Indicator Attention Indicator Toner Indicator Cancel Key GO Key Power Rear Cover Switch Power Cord...

  • Page 26: Indicators

    There are four indicators located on the top right of the printer. The indicators are used to identify the status of the printer at any time. To identify the printer status, check the indicators on the printer and then refer to the table below.

  • Page 27: Keys

    Keys Refer to the following table for the name and description of the basic functions of each key. Status Cancel At Ready At Error After Power OPERATION GUIDE Operation Press for 1 second or more Press momentarily Press for 3 to 10 seconds Press for 10 seconds or more Press momentarily Press until the...
  • Page 28 Machine Parts OPERATION GUIDE...

  • Page 29: Loading Paper

    MP Tray 50 sheets (80 g/m 60 to 163 g/m A4, B5 (JIS), A5, Folio, Legal, Letter, Oficio II, Statement, Executive, A6, B6, B5 (ISO), Envelope C5, Envelope #10, Envelope #9, Envelope #6, Envelope Monarch, Envelope DL, 16K, Other 70 × 148 to 216 × 356mm (2.8 × 5.8" to 8.5 ×...

  • Page 30: Preparing The Paper

    IMPORTANT: Ensure paper is not stapled and clips are removed. Pull the cassette completely out of the printer. IMPORTANT: When pulling the cassette out of the printer, ensure it is supported and does not fall out. Adjust the paper length guide to the paper size required.
  • Page 31 Do not load paper above the triangle mark located on the width guide. Ensure the side to be printed is facing down and the paper is not folded, curled, or damaged. Push the cassette back into the printer until it stops.

  • Page 32: Mp Tray

    MP Tray Paper placed on the MP tray is automatically fed and overrides the cassette. Open the MP tray towards you until it stops. Pull out the subtray and unfold the flap. Adjust the paper width guides and slide the paper into the tray as far as it will go.
  • Page 33 After use, close the flap on the subtray, then push in the subtray and close the MP tray. NOTE: Be careful not to push the tray back into the printer with the subtray folded out horizontally as shown in the figure. OPERATION GUIDE...
  • Page 34 Loading Paper OPERATION GUIDE...

  • Page 35: Connecting And Printing

    USB Interface Connector Parallel Interface Connector Connections Connecting the USB Cable OPERATION GUIDE 3 Connecting and Printing Connect the USB cable (not included) to the USB Interface Connector. NOTE: Use a USB cable with a rectangular Type A plug and a square Type B plug.

  • Page 36: Connecting The Parallel Cable

    Connect the other end of the printer cable to the computer’s parallel interface connector. Install the printer close to an AC wall outlet. If an extension cord is used, the total length of the power cord plus extension should be 5 meters (16 feet) or less.

  • Page 37: Loading Software

    When the printer is first switched on after toner installation, there will be a delay of approximately 15 minutes before the printer gets ready to print. Once the indicator lights, printer installation is complete.

  • Page 38: Printing

    Ensure the paper required is loaded in the printer. From the application File menu, select Print. The Print dialog box displays. Select the drop down list of printer names. All the printers installed are listed. Select the FS-1030D. Select the options required, enter the number of copies required and if printing more than one set, select Collate.

  • Page 39: Maintenance

    Cleaning Tasks The printer should be cleaned on a regular basis to ensure optimum performance. Use a clean, lint free cloth to clean dust and dirt from the printer. Process Unit The process unit should be removed to allow for printer cleaning tasks. The charger...

  • Page 40: Toner Container

    Toner Container To replace the toner container use the instructions below. CAUTION: Do not attempt to incinerate the toner container. Dangerous sparks may cause burns. Do not attempt to force open or destroy the toner container. Open the top cover. Turn lock lever A to the unlock position, push lock lever B to the right and pull out the toner...
  • Page 41 OPERATION GUIDE Install the new toner container in the printer. Push firmly on the top of the container at the positions marked PUSH HERE, until you hear a click. Turn lock lever A to the lock position and close the top cover.

  • Page 42: Cleaning The Printer

    Cleaning the Printer To avoid print quality problems, the interior of the printer must be cleaned with every toner container replacement. Open the top cover and front cover. Lift the process unit together with the toner container out of the printer.
  • Page 43 (CLEANER HOME POSITION When cleaning is complete, return the process unit to its position, aligning the guides at both ends with the slots in the printer. Close the front cover and top cover.

  • Page 44: Prolonged Non-Use And Moving The Printer

    Prolonged Non-Use and Moving the Printer Prolonged Non-use Moving the Printer If you ever leave the printer unused for a long period of time, remove the power cord from the wall outlet. We recommend you consult with your dealer about the additional actions you should take to avoid possible damage that may occur when the printer is used next time.

  • Page 45: Troubleshooting

    OPERATION GUIDE 5 Troubleshooting The table below provides basic solutions for problems you may encounter with the printer. We suggest you consult this table to troubleshoot the problems before calling for service. Check Items Check the indicator.

  • Page 46: Print Quality Problems

    Gray background Dirt on the top edge or back of the paper The printer will stop when a paper jam occurs in the printer or if paper is misfed. The printer will go offline and the attention indicator ( flash.

  • Page 47: Output Tray And Rear Cover

    Check to see if paper is loaded correctly. If not, reload the paper. Push the cassette back in securely. Open and close the top cover to clear the error. The printer warms up and resumes printing. Remove the paper from the MP tray.
  • Page 48 Open the top cover and front cover. Lift the process unit together with the toner container out of the printer. NOTE: The drum in process unit is sensitive to light. Never expose the process unit to light for more than five minutes.
  • Page 49 Close the front cover and top cover. Reload the MP tray. The printer warms up and resumes printing. When a paper jam occurs in the duplex section, clear it using the following procedure. Open the rear cover and remove the jammed paper as shown in the figure.
  • Page 50 Insert the cassette into the slot in the printer. Open and close the printer’s top cover to clear the error. The printer then automatically warms up and resumes printing. Open the top cover and front cover.
  • Page 51 If it has not be fed as far as the metal registration roller, remove the paper from the MP tray side. Insert the process unit together with the toner container, back machine. Close the front cover and top cover. The printer warms up and resumes printing.
  • Page 52 Troubleshooting OPERATION GUIDE...

  • Page 53: Options

    Printer OPERATION GUIDE 6 Options The FS-1030D printer has the following options available to satisfy your printing requirements. For instructions on installing individual options, refer to the documentation included with the option. Some options are explained in the following sections.

  • Page 54: Expansion Memory

    Expansion Memory Installing the DIMM To expand the printer memory for more complex print jobs and faster print speed, you can plug in optional memory modules (DIMM) in the memory slot provided on the printer main controller board. You can select additional memory modules from 64, 128, or 256MB.

  • Page 55: Setting The Printer Driver

    Click the Windows Start button, and then click Printers and Faxes. Right click the Kyocera Mita FS-1030D KX icon, and click Properties. The Properties dialog box will open. Click the Device Settings tab. Enter the total memory size installed to the printer (up to 288MB) in the...

  • Page 56: Compactflash (Cf) Card

    CompactFlash (CF) Card The printer is equipped with a slot for a CompactFlash card with the maximum size of 256MB. A CompactFlash card is useful for storing fonts, macros, and overlays. You can use the IC Link for Windows utility to download fonts, etc., to a CompactFlash card.

  • Page 57: Network Interface Card (Ib-21E)

    Windows, Macintosh, UNIX, NetWare, etc. NOTE: If the Serial Interface Board is installed, remove it to use the Network Interface Card. Turn off the printer and disconnect the power cord and printer cable. Remove the option interface slot cover. Insert the Network Interface Card and secure it with the screws removed in step 2.
  • Page 58 Options OPERATION GUIDE...

  • Page 59: Specifications

    250 sheets (80g/m ), 200 sheets (duplex printing) 10 seconds or less Fast 1200 mode 600 dpi (vertical and horizontal) with KIR (Kyocera Image Refinement) EcoPrint mode More than 100,000 pages (with 5% print coverage) Average 2,000 pages, Maximum 20,000 pages...
  • Page 60 Item Memory Standard Maximum Interfaces Parallel Option Operating Environment Temperature Relative Humidity Altitude Illumination Dimensions (W) × (H) × (D) Weight Operating noise (in accordance with ISO 7779 [Bystander Position, sound pressure level at the front]) Description 32MB 288MB 1 (IEEE 1284) 1 (Full-Speed USB) IB-11: Serial interface board IB-21E: Network interface card (10BASE-T/100BASE-TX)
  • Page 61 Index Attention indicator Cancel key Cassette paper length guide paper size stopper triangle mark width guides Caution labels CD-ROM Cleaning charger cleaner lint free cloth process unit registration roller transfer roller CompactFlash card 29, Data indicator DIMM socket Duplexer front cover rear cover Envelope GO key...
  • Page 62 Paper Type Parallel interface connector Parallel interface connector Power connecting cord connector switch Precautions for use xvii Printer cable Process unit charger cleaner charger wire cleaner home position drum Ready indicator Serial interface board Service status page Sleep mode Specifications...
  • Page 65 ©2005 is a trademark of Kyocera Corporation...
  • Page 66 Rev. 1.2 2006.1...
