User Manual
The Seismix 1 subwoofer has been designed to complement existing Stereo or Home
Theatre systems where size and placement of the subwoofer is an important consideration.
The amplifier module and 10" bass driver are identical to that used in the Seismix 3, however
they have been re-designed in a smaller enclosure to allow for installation in a cabinet or
where there is a space restriction. The Seismix 1 is an Explosive Experience.
Seismix 1: specifications
Drivers
Bass Driver
Nominal 255mm (10") diameter paper cone driver developed for
high level, low frequency reinforcement
Electronics
Amplifier Powe
200 watts RMS into the nominal 4 ohm driver
Maximum instantaneous power 400 watts
Amplifier S/N
>70dB
Distortion - Input to Speaker <0.1% – @ 80 watts RMS
Line Level Inputs
Left Input (mono)
Left + Right Input (stereo) Lo – 450mV RMS for maximum output
General
Frequency Range
22Hz – 150Hz (-6dB) in room response
Output
120dB maximum SPL in room response
Auto Power On / Off
15 minute delay before switching to standby after no input signal
Phase Select
0° or 180° (relative to input signal)
Cabinet
Enclosure Type
Bass Reflex, front vented
Dimensions
365mm high x 315mm wide x 340mm deep
Material
17mm MDF
Finish
Vinyl or lacquered timber veneer
Weight
15kg
Due to continued development specifications may change without notice
Lo – 900mV RMS for maximum output
Hi – 100mV RMS
Hi – 50mV RMS
