Kodak DP850 User Manual

Ultra digital projector
Hide thumbs Also See for DP850:
Table of Contents

Advertisement

Quick Links

Download this manual
CONTENTS
1.
Before you start.........................................................................................2
2.
Important information ...............................................................................5
3.
Connecting a computer to the KODAK DP850 ULTRA ..........................6
4.
Connecting a video source to the KODAK DP850 ULTRA ..................10
5.
Connecting a TV-source to the KODAK DP850 ULTRA ......................12
6.
Using the KODAK DP850 ULTRA ..........................................................14
7.
Using the menus .....................................................................................19
8.
Maintenance ............................................................................................32
9.
What do I do if (Trouble shooting).........................................................33
1
Page 1

Advertisement

Table of Contents
loading

Related Manuals for Kodak DP850

Summary of Contents for Kodak DP850

  • Page 1 Before you start...2 Important information ...5 Connecting a computer to the KODAK DP850 ULTRA ...6 Connecting a video source to the KODAK DP850 ULTRA ...10 Connecting a TV-source to the KODAK DP850 ULTRA ...12 Using the KODAK DP850 ULTRA ...14 Using the menus ...19...

  • Page 2: Before You Start

    Thanks to the unique KODAK Graphical User Interface, the KODAK DP850 ULTRA offers true plug and play operation from remote control, which by the way also can control your computer. 1.1 Color coding for ease of use...

  • Page 3: Accessories

    1.2 Accessories Please take a few minutes to make sure that your KODAK DP850 ULTRA contains all the necessary parts: 1.2.1 Computer accessories for external PC/MAC Computer cable Enhanced Video Connector (EVC), male at both ends, 3 m/9.8 ft. Cable for PC / MAC audio (Stereo jack, 0.3m/1 ft.)
  • Page 4 EVC cable Super-video cable Composite video cable Audio cable Stereo jack cable Figure 1: Product and accessories Softbag PC adapter PS/2 mouse for PC RS232 mouse for PC Mac adapter ADB mouse for Macintosh Batteries Interactive Remote Control Contents...

  • Page 5: Insert Batteries In The Remote Control

    NOTE! Please use caution when transporting the unit. WARNING! Tampering with or opening the KODAK DP850 ULTRA can be dangerous. For replacement of the lamp, see the instruc- tions support with the replacement lamp. Leave maintenance to authorized KODAK service personnel. Please contact your local dealer with any service or maintenance questions you may have.

  • Page 6: Connecting A Computer To The Kodak Dp850 Ultra

    3. Connecting a computer to the KODAK DP850 ULTRA The procedure for connecting a computer to the KODAK DP850 ULTRA is the same for all types of computers. Make sure the computer, monitor and KODAK DP850 ULTRA are switched off.
  • Page 7 Connecting to a laptop, notebook Back panel of computer PC adapter EVC cable Figure 3: Connecting to a laptop, notebook Connecting to an Apple PowerBook Back panel of computer MAC adapter EVC cable Figure 4: Connecting to an Apple PowerBook Contents...
  • Page 8 Connecting to a desktop PC with standard RGB Back panel of computer PC adapter PC monitor EVC cable Figure 5: Connecting to a desktop PC with standard RGB Connecting to an Apple Macintosh desktop computer Back panel of computer MAC adapter PC monitor EVC cable Figure 6:...
  • Page 9 Connecting the mouse cable and stereo jack (PC) Back panel of computer PC adapter PC monitor EVC cable Figure 7: Connecting the mouse cable and stereo jack (PC) Connecting the mouse cable and stereo jack (MAC) Back panel of computer MAC adapter PC monitor EVC cable...

  • Page 10: Connecting A Video Source To The Kodak Dp850 Ultra

    4. Connecting a video source to the KODAK DP850 ULTRA The procedure for connecting a video source to the KODAK DP850 ULTRA is the same for S-video and Composite video SECAM, PAL N and PAL M modes are manually selected by pressing the “Green Button“. If the right format is not found the first time, press again.
  • Page 11 KODAK DP850 ULTRA. Figure 10: Using external speakers When external speakers are connected, these can be turned on or off from the KODAK DP850 ULTRA. To control the internal speakers, see section on Adjust audio settings, section 7.3.3. Contents...

  • Page 12: Connecting A Tv-Source To The Kodak Dp850 Ultra

    Figure 11: Connecting to TV- source NOTE! Requires TV tuner to be installed. In order to use the KODAK DP850 ULTRA as a TV out- put; connect the TV antenna to the TV connector on the KODAK DP850 ULTRA plug panel.
  • Page 13 If you do not have a decoder you simply set your TV up just like you would with an antenna. This is also the same with the KODAK DP850 ULTRA. You must scroll the channel name in the TV Setup menu until you find the correct channel for your cable system.

  • Page 14: Using The Kodak Dp850 Ultra

    6. Using the KODAK DP850 ULTRA 6.1 Different program modes for the KODAK DP850 ULTRA KODAK DP850 ULTRA has different modes of operation: Stand-by mode Normal mode Quick mode Menu mode Pointer mode Blank mode Stand-by mode In stand-by mode the projector is turned off and can be turned on by using defined keys, see section 6.3...

  • Page 15: Kodak Remote Control

    To allow remote control of your computer Pointing it towards the projection screen operates the remote control. An infra red beam bounces from the screen to an infrared receiver on the KODAK DP850 ULTRA. NOTE! Make sure nothing is blocking the IR receiver in...
  • Page 16 Small gray key Interrupt/break an action (right mouse key) Menu The menu key gives access to the KODAK menu con- trol functions. To move within the various menu func- tions, position the arrow cursor by pressing the sensi- tive mouse pad and click with the left mouse button which is located underneath the remote control.

  • Page 17: Using The Touch Panel On The Kodak Dp850 Ultra

    KODAK DP850 ULTRA projector The touch panel gives you direct access to the most important functions of the KODAK DP850 ULTRA. It is very handy to use when the remote control has low batteries, or you simply have forgotten to bring it with you.
  • Page 18 Press the Zoom key to zoom the projected image to the desired size. Stand by The stand by key will set the KODAK DP850 ULTRA in stand by mode. The lamp will turn off, and the fans will run for a little while cooling the projector before stop- ping.

  • Page 19: Adjusting The Height And Angle Of The Kodak Dp850 Ultra

    6.4 Adjusting the height and angle of the KODAK DP850 ULTRA You can adjust the height and angle of the KODAK DP850 ULTRA by adjusting the four small feet under- neath the product. NOTE! The KODAK DP850 ULTRA should never be left with an angle of more than 15 degrees over a longer period of time.

  • Page 20: Main Menu

    Stand by This function sets the projector in stand-by mode Auto set-up Auto set-up will do automatic set-up of the projector: Horizontal and vertical position Sampling clock Phase Chooses between available video formats and...
  • Page 21 Source You can connect four different sources to the KODAK DP850 ULTRA; one computer source, two video sources and one TV tuner (optional). You select the source you want to use by clicking on the icon representing the source. Use the pressure-...

  • Page 22: Set-Up Menu

    The picture orientation menu is used for rotating and mirroring the picture. Normal Normal is used when the projector is standing on a table projecting a picture on a screen. Mirror Mirror is used when the projector is projecting the...

  • Page 23: Mouse System

    RS232 mouse, you must choose MS Serial Mouse in this menu. If your PC uses PS/2 mouse, you must choose PS/2 in the menu. Selected system will be active until another system is chosen. When shipped the KODAK DP850 ULTRA is set up to PS/2. Contents...

  • Page 24: Language

    7.2.3 Language Language selection This menu allows you to choose between six different menu languages: English, French, German, Italian, Spanish and Norwegian. Click in the box next to the language you want to use. Click on the OK button. The window will disappear, and the selected language will be used in the main menu and in all other menus.

  • Page 25: Quick Menu

    7.2.4 Quick menu Quick menu settings In the quick menu you can assign functionality for the quick key on the remote control. When clicking on the quick key you will be able to switch between all the functions you have selected in this menu. In this example, the first time you click on the quick key you will activate the volume function.

  • Page 26: Zap Menu

    If a TV tuner is installed and selected as source you can select TV channel by using the zap keys. Pointer You can activate the pointer function in the projector. One click activates the pointer and the next click deactivates it.

  • Page 27: Television Programs

    7.2.6 Television programs This menu is only displayed if the TV tuner is installed and TV tuner is selected as source. The television program menu is then activated by pressing the ”television program” icon The TV setup menu is divided in two parts: Automatic TV station Program Automatic TV station search...

  • Page 28: Product Information

    7.2.7 Product information Product information Click on the product information icon in order to get information about the product and company. Press the main menu button again to exit this screen 7.3 Control panel menu Control panel menu In the control panel you have access to menus for adjusting picture and audio settings.

  • Page 29: Picture Control

    7.3.1 Picture control Picture control Select the picture control menu for adjusting brightness, saturation and tint. When PC is selected as source, only brightness will be available. When PAL/SECAM video is selected brightness, contrast and saturation will be available. All options will be available for NTSC video.

  • Page 30: Picture Positioning

    7.3.3 Audio control Audio control Select this function when you have connected an audio signal to the ‘Audio in’ on the KODAK DP850 ULTRA connectors (or through the EVC cable). Use the four sliders to adjust volume, bass, treble and balance until you have a satisfying sound.

  • Page 31: Synchronization Adjustments

    7.3.5 Color manager Color tone settings The color manager is designed to give you maximum performance from your KODAK DP850 ULTRA projector, independent of ambient light conditions. In the color manager menu you can choose between four pre-defined Color settings.

  • Page 32: Maintenance

    Zoom and focus adjustments In this menu you can adjust the Zoom and Focus of the KODAK DP850 ULTRA by clicking on the up and down arrows in the menu. When you have adjusted the image to your satisfaction, click on the OK button to exit and save your new settings.

  • Page 33: What Do I Do If (Trouble Shooting)

    The KODAK DP850 ULTRA is not connected to electricity. Check that the power cable is connected to the KODAK DP850 ULTRA and the wall outlet. No source signal is detected (the KODAK Welcome Picture appears) Possible causes and remedies: The computer has not been switched on.
  • Page 34 No Image Appears Possible causes and remedies: The KODAK DP850 ULTRA has not been switched on. Check the ON/OFF switch at the back. There is no electricity in the power outlet in the wall. Check that there is power in the power outlet.

  • Page 35: Table Of Contents

    BEFORE YOU START ...2 • 1.1 Color coding for ease of use ...2 • 1.2 Accessories...3 • 1.2.1 Computer accessories for external PC/MAC ...3 • 1.2.2 Video accessories ...3 • 1.2.3 Other cables/accessories ...3 • 1.2.4 Optional cables and accessories ...3 •...
  • Page 36 CONNECTING A VIDEO SOURCE TO THE KODAK DP850 ULTRA ...10 • 4.1 Using external speakers...11 Contents...
  • Page 37 6.1 Different program modes for the KODAK DP850 ULTRA ...14 • 6.2 KODAK Remote control...15 • 6.3 Using the touch panel on the KODAK DP850 ULTRA ...17 • 6.4 Adjusting the height and angle of the KODAK DP850 ULTRA ...19...
  • Page 38 USING THE MENUS...19 • 7.1 The Menu System ...19 • 7.1.1 Main menu...20 • 7.2 Set-up Menu ...22 • 7.2.1 Picture orientation ...22 • 7.2.2 Mouse system ...23 • 7.2.3 Language ...24 • 7.2.4 Quick menu...25 • 7.2.5 Zap menu ...26 •...
