B_07802
Pneumatic double diaphragm pump
ZIP52 - ZIP80
Translation of the Original Operating Manual
+

 II 2 G Ex h IIB T4 Gb X
For professional use.
Always observe the information in this manual, particularly the safety
instructions and the warning instructions. Store the manual in a safe place.
Edition: 09/2021

Advertisement

Table of Contents
loading

Related Manuals for WAGNER ZIP52

Summary of Contents for WAGNER ZIP52

  • Page 1 B_07802 Pneumatic double diaphragm pump ZIP52 - ZIP80 Translation of the Original Operating Manual    II 2 G Ex h IIB T4 Gb X For professional use. Always observe the information in this manual, particularly the safety instructions and the warning instructions. Store the manual in a safe place.

  • Page 3: Table Of Contents

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 Table of Contents TABLE OF CONTENTS About these instructions Preface Warnings, Notices and Symbols in these Instructions General Characters and Symbols Languages Abbreviations Terminology for the Purpose of this Manual Using in accordance with the instructions...
  • Page 4 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 Table of Contents Troubleshooting and Rectification Repairs 10.1 Repair Personnel 10.2 Repair Notes 10.3 Tools 10.4 Cleaning the Parts after Disassembly 10.5 Assembly of the Device 10.6 Replacing the Diaphragm (Due to Breakage)

  • Page 5: About These Instructions

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 1   About these instructions 1   ABOUT THESE INSTRUCTIONS 1.1   PREFACE The operating manual contains information about safely operating, maintaining, cleaning and repairing the device. The operating manual is part of the device and must be available to the operating and service personnel.

  • Page 6: Languages

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 1   About these instructions – Non-numbered list, first level – Non-numbered list, second level = cross-reference on page ♦ = wearing parts ⋆ = included in service set ● = not part of the standard equipment but available as a special accessory 1.4 ...

  • Page 7: Terminology For The Purpose Of This Manual

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 1   About these instructions 1.6   TERMINOLOGY FOR THE PURPOSE OF THIS MANUAL Cleaning Cleaning Manual cleaning of devices and device parts with cleaning agent. Flushing Internal flushing of paint-wetted parts with flushing agent.

  • Page 8: Using In Accordance With The Instructions

    WAGNER explicitly prohibits any other use! The device may only be operated under the following conditions: 4 Use the device only to work with the materials recommended by WAGNER. 4 Do not deactivate safety fixtures. 4 Use only WAGNER original spare parts and accessories.

  • Page 9: Processible Working Materials

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 2   Using in accordance with the instructions C) Non-conductive polypropylene versions The pneumatic double diaphragm pump must be employed outside of explosion hazard zones. 2.4   PROCESSIBLE WORKING MATERIALS Fluid materials like paints and lacquers.

  • Page 10: Misuse

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 2   Using in accordance with the instructions 2.5   MISUSE Misuse can lead to physical injury and/or property damage! Special attention must be paid that: 4 No dry coating products, e.g., powder are processed.

  • Page 11: Identification

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 3   Identification 3   IDENTIFICATION 3.1   IDENTIFICATION OF NON-IGNITABLE PRODUCTS Device types: C) Non-conductive polypropylene versions Pneumatic double diaphragm pumps with Order no. ZIP52 ZIP52 PF U552.PTSS7 U553.PHSD7 U553.PTSS7 3.2   EXPLOSION PROTECTION IDENTIFICATION...

  • Page 12: Type Plate

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 3   Identification Safe Handling of WAGNER Spray Devices Mechanical sparks can form if the device comes into contact with metal. In an explosive atmosphere: 4 Knocking or pushing metal against metal is to be avoided.
  • Page 13 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 3   Identification Type plate of EX versions Wagner International AG II 2 G Ex h IIB T4 Gb X CH-9450 ALTSTÄTTEN Assembled by WAGNER in Switzerland ZIP52 Max. Fluid pressure: 8bar-0.8MPa-116psi Max.

  • Page 14: Basic Safety Instructions

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 4   Basic Safety Instructions 4   BASIC SAFETY INSTRUCTIONS 4.1   SAFETY INSTRUCTIONS FOR THE OPERATOR 4 Keep this operating manual at hand near the device at all times. 4 Always follow existing regulations concerning occupational safety and accident prevention regulations.

  • Page 15: Safety Instructions For The Personnel

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 4   Basic Safety Instructions 4 Make sure that all people within the work area wear static dissipative shoes. Footwear must comply with EN 20344. The measured insulation resistance must not exceed 100 MΩ.
  • Page 16 4 In the event of functional faults, remedy the fault as described in the chapter on troubleshooting and rectification. 4 If needed, the liquid ejection devices must be checked by experts (e.g., WAGNER service technician) at least every 12 months for their work-safe condition in accordance with DGUV regulation 100-500 Chapter 2.29 and Chapter 2.36.
  • Page 17 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 4   Basic Safety Instructions 4 Earth the workpieces being painted. 4 Ensure that all persons inside the working area are grounded, e.g., that they are wearing static dissipative shoes. 4 Wear static dissipative gloves when spraying. The grounding takes place via the spray gun's handle or its trigger.
  • Page 18 Danger due to improper maintenance and repair! Danger to life and equipment damage. 4 Only a WAGNER service center or a suitably trained person may carry out repairs and replace parts. 4 Repair or replacement of devices or parts of devices are only allowed to be performed outside the hazard area by qualified personnel.
  • Page 19 4   Basic Safety Instructions 4 Use only WAGNER original spare parts and accessories. 4 Do not change or modify the device; if change is necessary, contact WAGNER. 4 Only repair and replace parts that are listed in Chapters Accessories and Spare Parts [8 56] and that are assigned to the device.

  • Page 20: Description

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description 5   DESCRIPTION 5.1   COMPONENTS B_06950 Delivery manifold Product input Air input Product distributor Product output Grounding connection 5.2   MODE OF OPERATION The double diaphragm pump is driven with compressed air. A pneumatic manifold alternates in supplying two diaphragms with compressed air.

  • Page 21: Scope Of Delivery

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description 5.4   SCOPE OF DELIVERY Order no. Designation ZIP diaphragm pump The standard equipment includes: See Chapter Declaration of Conformity [8 70] Declaration of Conformity 2330425 Operating manual, in German See Chapter Languages [8 6] Operating manual in the local language The delivery note shows the exact scope of delivery.
  • Page 22 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description 5.5.2   Technical Data for Metallic Pump Versions Pump body Description Units Zip 52 Zip 52 ZIP 52 PF Zip 80 Pump ratio 1 : 1 Volume flow per double stroke (DH) cm³...
  • Page 23 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description Pump body Description Units Zip 52 Zip 52 ZIP 52 PF Zip 80 Product temperature °C 4 – 90 °F 39 – 194 Ambient temperature °C 4 – 40 °F...
  • Page 24 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description Pump body Acetal Acetal Description Units Zip 52 ZIP 52 PF Zip 52 ZIP 52 Air inlet connection (plug) BSP(R) 1/4" Maximum suction height 15.7 15.7 Maximum solid body size Inches 0.08...
  • Page 25 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description 5.5.4   Dimensions and Connections B_04007 S = E + (2 x N) B_04028 Wall mount ZIP52 ZIP52 ZIP52 ZIP52 PF ZIP52 PF ZIP80 Aluminum SSt mm; inch PP and acetal...
  • Page 26 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description ZIP52 ZIP52 ZIP52 ZIP52 PF ZIP52 PF ZIP80 Aluminum SSt mm; inch PP and acetal Aluminum PP and acetal Aluminum mm; inch mm; inch mm; inch mm; inch mm; inch 100;...
  • Page 27 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description Diagram ZIP52 bar (MPa) nl/min <psi> <scfm> 10 (1.0) <145> <26.9> 8.0 (0.8) <21.4> <116> 6.0 (0.6) <16.1> <87> 4.0 (0.4) <10.7> <58> 2.0 (0.2) <5.4> <29> l/min <2.64>...
  • Page 28 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 5   Description Diagram ZIP80 bar (MPa) nl/min <psi> <scfm> 10 (1.0) <145> <26.9> 8.0 (0.8) <21.4> <116> 6.0 (0.6) <16.1> <87> 4.0 (0.4) <10.7> <58> 2.0 (0.2) <5.4> <29> l/min B_04034 <3.96>...

  • Page 29: Assembly And Commissioning

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning 6   ASSEMBLY AND COMMISSIONING 6.1   TRAINING OF ASSEMBLY/COMMISSIONING PERSONNEL – The assembly and commissioning personnel must have the technical skills to safely commission the device. – When assembling, commissioning and carrying out all work, read and follow the operating manuals and safety regulations for the additionally required system components.
  • Page 30 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning Info Ensure that the national explosion prevention rules and regulations are observed when setting up the device. Connections Configurations B_04021 B_07862 B_07863 Type 1 Type 2 Type 3...
  • Page 31 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning B_06951 Product delivery valve Air suction filter Product hose Suction hose Return valve Air cut-off valve Delivery manifold Air pressure regulator Suction manifold 1. Install the pump on a flat and horizontal foundation and screw it down tightly or mount it on a wall mount.
  • Page 32 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning × B_04011 Compressed air connection: The compressed air supply must be properly dimensioned. Connect the pump's compressed air connection to the pressure distribution network. Establish the connection to the pump fitting.

  • Page 33: Grounding

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning 6.5.3   Product Supply Lines DANGER Bursting hose, bursting threaded joints! Danger to life from injection of product. 4 Ensure that the hose material is chemically resistant to the sprayed products.
  • Page 34 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning B_06952 Grounding scheme (example) Part / workstation Cable cross section Conveyor 16 mm²; AWG6 Work piece < 1 MΩ Spraying stand 16 mm²; AWG6 Alternative: Spray booth Floor, static dissipative Product tank 6 mm²;...

  • Page 35: Commissioning

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning 2. Crimp the grounding cable on the connection and screw it back onto the pump’s foot. 3. Ground the product tank to an on-site grounding connection. 4. Ground the other parts of the system to an on-site grounding connection.
  • Page 36 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 6   Assembly and Commissioning 6.7.3   Pressure Tightness Test WARNING Overpressure! Risk of injury from bursting components. 4 The operating pressure must not exceed the value shown on the type plate. 1. Gradually increase the pressure in pump with the pressure regulator until maximum pressure is reached.

  • Page 37: Operation

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 7   Operation 7   OPERATION 7.1   TRAINING THE OPERATING PERSONNEL – The operating personnel must be qualified to operate the entire system. – The operating staff must be familiar with the potential risks associated with improper behavior as well as the necessary protective devices and measures.

  • Page 38: Pressure Relief / Work Interruption

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 7   Operation Info In case air accidentally flows into the pump suction inlet, the air pressure must immediately be reduced to avoid the pump working at an excessive speed. 7.4   PRESSURE RELIEF / WORK INTERRUPTION The pressure must always be relieved: –...
  • Page 39 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 7   Operation WARNING Incompatibility of cleaning/flushing agent and working medium! Risk of explosion and danger of poisoning by toxic gases. 4 Examine the compatibility of the flushing and cleaning agents and working media on the basis of the safety data sheets.
  • Page 40 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 7   Operation 6. Secure the spray gun. 7. Dispose of the contents of the tank (8) according to the local regulations. In case of start-up problems: 1. Close the air cut-off valve (4).

  • Page 41: Cleaning And Maintenance

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 8   Cleaning and Maintenance 8   CLEANING AND MAINTENANCE 8.1   CLEANING 8.1.1   Cleaning Personnel Cleaning work should be undertaken regularly and carefully by qualified and trained personnel. They should be informed of specific hazards during their training.
  • Page 42 DANGER Incorrect maintenance/repair! Danger to life and equipment damage. 4 Only a WAGNER service center or a suitably trained person may carry out repairs and replace parts. 4 Use only WAGNER original spare parts and accessories. 4 Only repair and replace parts that are listed in the spare parts chapter and that are assigned to the device.
  • Page 43 Yearly or as required 1. In accordance with DGUV regulation 100-500, Chapters 2.29 and 2.36: 4 Have the liquid ejection devices checked by an expert (e.g. WAGNER service technician) as required, but no later than every 12 months to ensure that they are in safe working order.
  • Page 44 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 8   Cleaning and Maintenance 8.2.5   Emptying Pump WARNING Gas mixtures can explode if there is an incompletely filled pump! Danger to life from flying parts. Ignition of potentially explosive surrounding atmosphere.
  • Page 45 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 8   Cleaning and Maintenance 6. Close return valve (2). Emptying up to the gun 1. Point the spray gun, without nozzle, into the tank (8) and open it. 2. Slowly open pressure regulator (3). Be ready for the switch from working product to air.

  • Page 46: Replacing The Diaphragm (Preventive Maintenance)

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 8   Cleaning and Maintenance 6. Slowly open the air cut-off valve (4). 7. Slowly turn air pressure up on the pressure regulator (3) and only until the pump is running regularly. Be ready to switch from air to working product and prevent back spray.

  • Page 47: Cleaning/Replacement Of The Suction And Delivery Non-Return Valves

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 8   Cleaning and Maintenance 4. Remove the released diaphragm with its corresponding internal disc, and remove the shaft from the motor block. 5. Clamp the end of the shaft released from the diaphragm in a bench vice (with soft jaws to avoid damaging it) and remove the external diaphragm disc from the opposite end of the shaft.

  • Page 48: Troubleshooting And Rectification

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 9   Troubleshooting and Rectification 9   TROUBLESHOOTING AND RECTIFICATION Problem Cause Remedy The pump does not The air motor does not work or Close the air cut-off valve, increase the pressure, work.

  • Page 49: Repairs

    DANGER Incorrect maintenance/repair! Danger to life and equipment damage. 4 Only a WAGNER service center or a suitably trained person may carry out repairs and replace parts. 4 Use only WAGNER original spare parts and accessories. 4 Only repair and replace parts that are listed in the spare parts chapter and that are assigned to the device.

  • Page 50: Tools

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 10   Repairs 10.3   TOOLS The following tools are required for assembling and disassembling the device (if possible, always bring entire tool sets with you): – Torque wrench set – Allen wrench set 10.4 ...
  • Page 51 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 10   Repairs 3.5 Nm 2.6 lbft 2 Nm; 1.5 lbft 2 Nm 1.5 lbft B_04018 1. Dismantle the motor in accordance with Chapter Replacing the Diaphragm (Preventive Maintenance) [8 46]. 2. Remove the reversing valve (2).

  • Page 52: Function Test After Repair Work

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 11   Function Test after Repair Work 11   FUNCTION TEST AFTER REPAIR WORK After all repairs, the device must be checked for safe condition before recommissioning. The necessary scope of inspection and testing depends on the repair carried out and must be documented by the repair personnel.

  • Page 53: Disposal

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 12   Disposal 12   DISPOSAL 12.1   DEVICE When the devices must be scrapped, please differentiate the disposal of the waste materials. The following materials have been used: – Stainless steel – Aluminum –...

  • Page 54: Accessories

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 13   Accessories 13   ACCESSORIES B_04029 Pos K Order no. Designation ZIP pump P123.00 Pressure regulator 9998677 Pressure gauge T760.00M Wall mount T406.00 Suction hose, stainless steel, complete H401.07 Filter support disc T453.03...
  • Page 55 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 13   Accessories Connections Configurations B_04021 B_04061 B_04020 LEFT/LEFT U55x.xxxx1 UNIVERSAL / UNIVERSAL INDEPENDENT / INDEPEN- DENT U55x.xxxx7 U55x.xxxx8 U551.303 Order number DOC 2330426 | Edition 09/2021...

  • Page 56: Spare Parts

    DANGER Incorrect maintenance/repair! Danger to life and equipment damage. 4 Only a WAGNER service center or a suitably trained person may carry out repairs and replace parts. 4 Use only WAGNER original spare parts and accessories. 4 Only repair and replace parts that are listed in the spare parts chapter and that are assigned to the device.

  • Page 57: Zip52 Pump - Metallic - Universal Connections

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts 14.3   ZIP52 PUMP - METALLIC - UNIVERSAL CONNECTIONS 5 Nm; 3.7 lbft (U551.303) 12 Nm; 8.8 lbft 5 Nm; 3.7 lbft 5 Nm; 3.7 lbft B_04022 Order no.
  • Page 58 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts Order no. Order no. Order no. Order no. Order no. Designation ⋆ ♦ G921.05 Product di- aphragm ⋆ ♦ G921.06 Support di- aphragm 9900333 Screw, M6x35 9900338 9900338...

  • Page 59: Zip52 Pump - Metallic - Independent Connections

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts 14.4   ZIP52 PUMP - METALLIC - INDEPENDENT CONNECTIONS 5 Nm; 3.7 lbft 12 Nm; 8.8 lbft 5 Nm; 3.7 lbft 5 Nm; 3.7 lbft B_04023 Order no. Designation U550.ATSS8 DDP ZIP52...
  • Page 60 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts Order no. Designation K1012.62 Self-tapping screw K1041.62 Rivet K1044.62 Screw T6103.00 Motor ⋆ ♦ T6105.00 Valve unit Y622.00A Cable lug Cover type plate Round type plate B0177.14 Fitting ⋆...

  • Page 61: Zip52 Pump - Conductive Acetal

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts 14.5   ZIP52 PUMP - CONDUCTIVE ACETAL 4.5 Nm; 3.3 lbft (U55x.xxxx7) (U55x.xxxx1) 12 Nm; 8.8 lbft 7 Nm; 5.2 lbft (U55x.xxxx7) B_04062 4.5 Nm; 3.3 lbft (U55x.xxxx1) Order no.
  • Page 62 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts Order no. Order no. Designation F831.07G-A Conductive diaphragm cover ⋆ ♦ G921.07B G921.05 Diaphragms ⋆ ♦ G921.06 Support diaphragm 9907050 Screw, M6x40 9907249 Screw, M6x75 9910204 Self-locking nut, M6...

  • Page 63: Zip52 Pump - Polypropylene - Universal Connections

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts 14.6   ZIP52 PUMP - POLYPROPYLENE - UNIVERSAL CONNECTIONS 5 Nm; 3.7 lbft 12 Nm; 8.8 lbft 7 Nm; 5.2 lbft 5 Nm; 3.7 lbft B_04024 Order no. Order no.
  • Page 64 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts Order no. Order no. Order no. Designation ⋆ ♦ G921.06 G921.06 Support diaphragm 9907050 Screw, M6x40 9907249 Screw, M6x75 9910204 Self-locking nut, M6 9920103 Washer, 6 K508.62 Washer, 6x18 K1041.62...

  • Page 65: Zip80 Pump - Aluminum - Universal Connections

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts 14.7   ZIP80 PUMP - ALUMINUM - UNIVERSAL CONNECTIONS 5 Nm; 3.7 lbft 12 Nm; 8.8 lbft 5.5 Nm; 4.06 lbft 5 Nm; 3.7 lbft B_04026 Order no. Designation U555.ATSS7 DDP ZIP80...
  • Page 66 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts Order no. Designation 9907050 Screw, M6x40 9900333 Screw, M6x35 9910208 Nut M8 9910204 Self-locking nut, M6 9920102 Washer 8 K1057.62 Screw K1041.62 Rivet K1053.62 Screw M405.24 Plug, 3/4"...

  • Page 67: Zip Motor

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts 14.8   ZIP MOTOR 3.5 Nm; 2.6 lbft 2 Nm; 1.5 lbft 2 Nm; 1.5 lbft B_04027 Zip 52 ZIP 52 PF Zip 80 Designation Order no. Order no.

  • Page 68: Service Sets

    Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts Zip 52 ZIP 52 PF Zip 80 Designation Order no. Order no. Order no. ⋆ ♦ F829.07 Shaft guide bushing F830.07 Cover (exhaust side) T6103.00A T6104.00A Motor block with safety valve ♦...
  • Page 69 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 14   Spare Parts Pump No. Diaphragm Valve seat Valve ball Service set O-ring set Air valve set U553.PHSD7 UHMWPE Stainless Acetal (POM) T9080.00G T9077.00 P4003.00 steel U553.PTSS7 PTFE Stainless Stainless steel T9080.00...

  • Page 70: Declaration Of Conformity

     II 2 G Ex h IIB T4 Gb X EU Declaration of Conformity The EU Declaration of Conformity is enclosed with this product. If needed, further copies can be ordered through your WAGNER dealer by specifying the product name and serial number. Order number: 2334618 15.1.2   Non-Ex Versions...
  • Page 71 Identification: EU Declaration of Conformity The EU Declaration of Conformity is enclosed with this product. If needed, further copies can be ordered through your WAGNER dealer by specifying the product name and serial number. Order number: 2334619 Order number DOC 2330426 | Edition 09/2021...
  • Page 72 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 15   Declaration of Conformity Order number DOC 2330426 | Edition 09/2021...
  • Page 73 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 15   Declaration of Conformity Order number DOC 2330426 | Edition 09/2021...
  • Page 74 Operating manual Pneumatic double diaphragm pump ZIP52 - ZIP80 15   Declaration of Conformity Order number DOC 2330426 | Edition 09/2021...
  • Page 76 Order number DOC 2330426 Edition 09/2021 Germany J. Wagner GmbH Otto-Lilienthal-Strasse 18 Postfach 1120 D-88677 Markdorf Telephone: +49 (0)7544 5050 Fax: +49 (0)7544 505200 E-mail: ts-liquid@wagner-group.com Switzerland Wagner International AG Industriestrasse 22 CH-9450 Altstätten Telephone: +41 (0)71 757 2211 Fax: +41 (0)71 757 2222 More contact addresses on the internet at: www.wagner-group.com...
