A r n o l d
POWERMOBIL
Maintenance Instructions
System
POWERMOBIL
The protocol SPR2-240.832.01.02.02 is required for
these instructions
Print No.:
SPR2-240.831.01.02.02
Replaces: SPR2-240.831.01.01.02
02830011
SP
1999
© Siemens AG
The reproduction, transmission or use
of this document or its contents is not
permitted
without
express
authority. Offenders will be liable for
damages. All rights, including rights
created by patent grant or registration
of a utility model or design, are
reserved.
English
Doc. Gen. Date: 07.05
written

Advertisement

Table of Contents
loading

Related Manuals for Siemens POWERMOBIL SP

Summary of Contents for Siemens POWERMOBIL SP

  • Page 1 Maintenance Instructions System POWERMOBIL The protocol SPR2-240.832.01.02.02 is required for these instructions 02830011 1999 © Siemens AG The reproduction, transmission or use of this document or its contents is not permitted without express written authority. Offenders will be liable for damages.
  • Page 2 Assemblers and other persons who are not employed by or otherwise directly affiliated with or authorized by Siemens or one of its affiliates are directed to contact one of the local offices of Siemens or one of its affiliates before attempting installation or service pro- cedures.

  • Page 3: Table Of Contents

    Measurements ............35 Siemens AG SPR2-240.831.01.02.02...
  • Page 4 Final work steps ............43 6 _______ Changes to Previous Version _____________________________________ 44 POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 4 of 44 07.05 CS PS 24...

  • Page 5: Requirements

    General Information General Information Requirements The requirements described in chapter 1 of the Service Instructions also apply to mainte- nance. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 5 of 44 Medical Solutions 07.05 CS PS 24...

  • Page 6: Required Documents

    Systems equipped with an I.I. laser light localizer • Installation and Setting Instructions RXR2-130.033.03 1.2.5 Systems equipped with DICOM bridge • DICOM Bridge Installation and Setting Instructions SPR2-130.033.04 POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 6 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 7: Systems Equipped With Codonics Printer

    General Information 1.2.6 Systems equipped with Codonics printer • Codonics printer EP 1660 Installation and Setting SPR2-130.814.01 Instructions Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 7 of 44 Medical Solutions 07.05 CS PS 24...

  • Page 8: Required Tools, Measurement And Auxiliary Devices

    Service PC • Cable for connecting service PC to 99 00 440 RE999 host • Service software* (see system folder) • Sealing compound 34 43 009 POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 8 of 44 07.05 CS PS 24 Medical Solutions...
  • Page 9 • Special oil (Optimol Optipit) 55 07 525 • Special oil (Slic Pac PTFE) 55 07 517 • Torque wrenches 34 30 063 34 24 553 Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 9 of 44 Medical Solutions 07.05 CS PS 24...

  • Page 10: Spare Parts Which May Be Needed

    • Cable deflector wheels small/POWERMOBIL stand • Conductive rubber/POWERMOBIL stand and monitor trolley • Touch-up paint 34 44 403 • Spray paint 84 27 734 RH999 POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 10 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 11: Emphasized Text

    Fig. 1: Safety Notes Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 11 of 44 Medical Solutions 07.05...

  • Page 12: Safety Information

    TD00-000.860.01... must be complied with. CAUTION Electrical voltage! Non-compliance can result in material damage. When working on the system, ESD regulations must be observed. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 12 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 13: Radiation Safety Information

    To avoid burns, switch the system off prior to touching parts or components and allow at least 5 minutes of cool- ing. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 13 of 44 Medical Solutions 07.05...
  • Page 14 Perform the required work with special care and atten- tion to detail. If needed, wear working gloves. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 14 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 15: Safety Information - Risk Of Infection

    NOTE The eye is not in immediate danger. (blinking reflex of the eye). Nevertheless do not look directly into the laser beam. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 15 of 44 Medical Solutions 07.05...

  • Page 16: Information On The Protective Conductor Resistance Test

    (according to DIN VDE 0751-1:2001-10, Fig. C3). Pos. 1 System Pos. 2 Application part (not available) Pos. 3 Measurement setup (integrated into measuring device) POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 16 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 17: Information On Measuring The System Leakage Current

    The measuring procedure indicated in the report must be used. If the first measured value has to be newly determined (see note), a measuring procedure can be selected (direct measurement or differential measurement). Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 17 of 44 Medical Solutions 07.05...
  • Page 18 Fig. 4: Measuring circuit for direct measurement of the system leakage current in compliance with DIN VDE 0751-1:2001-10, Fig. C5 for protection class I. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 18 of 44 07.05 CS PS 24 Medical Solutions...
  • Page 19 - even if the limit value of 2.5 mA is not exceeded. The evaluation is not necessary in the case of a new determination. File the report sheet in the system folder or log book. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 19 of 44 Medical Solutions 07.05...

  • Page 20: Explanation Of Abbreviations In The Maintenance Certificate

    Customer-specific code Installed Volume Component Maintenance Unit The steps identified by these abbreviations are part of the maintenance certificate and should be checked off upon completion. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 20 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 21: Maintenance Interval

    General Information Maintenance interval • 12 months Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 21 of 44 Medical Solutions 07.05 CS PS 24...

  • Page 22: Technical Safety Checks (Tsc)

    SIM Monitors/displays 2.2 Are all cables and cable guides secure 3. Electrical safety, check: and without any visible damage? SIE Cables and plugs SIE Voltage discharge rubber POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 22 of 44 07.05 CS PS 24 Medical Solutions...
  • Page 23 3.2 Leakage current or equivalent leakage n.a. current measurement 3.2.1 Leakage current measurement 3. Electrical safety, check: SIE Leakage current 5.1 Final work steps, check: SIE Leakage current Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 23 of 44 Medical Solutions 07.05 CS PS 24...
  • Page 24 SIM Lifting column 5.4 Does the collision protection device Check the collision protection, if it is stop all system movements properly (e.g. installed. collision protection)? Otherwise: n.a. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 24 of 44 07.05 CS PS 24 Medical Solutions...
  • Page 25 Enter the results of the check. Have the operator, or a person authorized by the operator, sign the TSC report. Hand the TSC report over to the operator, or a person authorized by the operator. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 25 of 44 Medical Solutions 07.05...

  • Page 26: Visual Inspection Of Exterior

    Inspect the entire system for damage, such as damage to the housing or paint. Damage to the mains connection • Check power lines, plugs, socket panels and outlets for damage. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 26 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 27: Inspection Of Environment

    Mains voltage • Measure the line voltage and compare it to the line voltage label on the monitor trolley. Internal line impedance • Measure the internal line impedance. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 27 of 44 Medical Solutions 07.05 CS PS 24...

  • Page 28: Mechanical Safety

    - Lubricate the bearing surfaces of the lifting column guide and the spindle. Emergency Stop switch • Press the Emergency Stop switch. The lifting column may not be raised or lowered. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 28 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 29: I.i. Laser Light Localizer

    The guide rails must lock properly into place when fully pushed into position. • If necessary, use a cleaning brush to remove dirt from the rails. 3.1.4 Monitors/displays Monitor/displays Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 29 of 44 Medical Solutions 07.05...

  • Page 30: Labels

    - Replace any illegible labels or markings. ID labels • Ensure that all required ID labels are attached and in good condition. - Replace any illegible labels or markings. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 30 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 31: Electrical Safety

    Move the the cables of the hand and foot switches to check for breaks and short cir- cuits. Dose rate • Switch the system on • Check the dose rate (see the POWERMOBIL service instructions for this purpose). Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 31 of 44 Medical Solutions 07.05 CS PS 24...

  • Page 32: Monitors/Displays

    Check the SIMOMED N monitor as prescribed in the checklist. • Check the luminance of the standard monitors with 100/120 Hz. • Check the luminance of the TFT displays. Check the ambient light sensor. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 32 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 33: Operation

    Check whether the operating icons and button labels are clearly legible and recogniz- able. • Check whether the light indicators of the operating elements and displays are properly functioning. • Check all system operating functions. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 33 of 44 Medical Solutions 07.05 CS PS 24...

  • Page 34: Conductive Rubber

    Monitor trolley voltage discharge rubber • Inspect the voltage discharge rubber on the POWERMOBIL monitor trolley for damage or dirt. If necessary, clean or replace it. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 34 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 35: Measurements

    The leakage current test is part of the safety inspection. However, it is recommended to perform it only at the end of maintenance, with the system closed. See (Final work steps / p. 43). Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 35 of 44 Medical Solutions 07.05...

  • Page 36: Maintenance

    Check that the fan is functioning properly. 4.1.2 Codonics printer Ventilation • Clean the ventilation slots of the printer and Framegrabber. • Check that the fan is functioning properly. Cleaning POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 36 of 44 07.05 CS PS 24 Medical Solutions...
  • Page 37 Clean the printer as described in the maintenance chapter of the Codonics user manu- al. Use the customer’s cleaning pads (some cleaning pads are included in the delivery volume of the printer). Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 37 of 44 Medical Solutions 07.05...

  • Page 38: Operating Value Inspection

    38 Maintenance, Operating Value / Functional Inspection Operating value inspection Error memory • Read out the error memory of the system and analyze the results. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 38 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 39: Functional Inspection

    Monitor display of the iris collimator aperture • Select I.I. full format. • Close the iris collimator (X-iris) completely. • Mark the diameter of the collimated iris collimator aperture on the monitor. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 39 of 44 Medical Solutions 07.05 CS PS 24...
  • Page 40 The previously indicated monitor display of position and angle of rotation must coincide with the actual position of the slot diaphragm. • Select I.I. zoom format. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 40 of 44 07.05 CS PS 24 Medical Solutions...
  • Page 41 The previously displayed monitor display must match the position and angle of rotation of the actual slot diaphragm position. NOTE Perform this check with the lowest possible kV values so that the front edges of the slot diaphragm plate are effectively visualized. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 41 of 44 Medical Solutions 07.05...
  • Page 42 Inspect the image quality according to the chapter “Testing the image quality” in the in- stallation instructions SPR2-130.814.01... Maintenance • Entire system: Touch up any paint damage as needed. POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 42 of 44 07.05 CS PS 24 Medical Solutions...

  • Page 43: Final Work Steps

    (damaged insulation, damage caused by water ingress or humidity, defective interference suppressor, etc.) - even if the limit value of 2.5 mA is not exceeded. Siemens AG SPR2-240.831.01.02.02 POWERMOBIL Page 43 of 44 Medical Solutions 07.05...
  • Page 44 Changes to Previous Version Changes to Previous Version Document was converted to DMS POWERMOBIL SPR2-240.831.01.02.02 Siemens AG Page 44 of 44 07.05 CS PS 24 Medical Solutions...
