Crosley CDM2450TS User Manual

Top control dishwasher
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
A
技 术 要 求 ：
1 .该 手 册 印 刷 颜 色 均 为 黑 色 : P A N T O N E B L A C K C
2 .纸 张 规 格 为A 5 ,要 求 按A 5规 格 输 出 菲 林 与 印 刷
3 .最 后 一 页 为 封 底,如 果 供 应 商 的 排 版 需 要 加 空 白 页,
B
请 加 在 封 底 之 前
4 .封 面 封 底 需 过 光 油
C
处数 分区
标记
D
编
制
审 核
审 定
批 准
1
1
更改文件号 签 名
校对
性能
排版
日期
英文用户手册
WQP12-65M3
WQP12-65M4
日 期
阶 段 标 记
REV. 00
数
量
1
共
1
张
2
比 例
封面封底128克双铜纸,
内页80G双胶纸
1:1
重
量
佛山市顺德区美的
洗涤电器制造有限公司
第
1
张
2
A
B
C
D
D

Advertisement

Table of Contents
loading

Related Manuals for Crosley CDM2450TS

Summary of Contents for Crosley CDM2450TS

  • Page 1 技 术 要 求 ： 1 .该 手 册 印 刷 颜 色 均 为 黑 色 : P A N T O N E B L A C K C 2 .纸 张 规 格 为A 5 ,要 求 按A 5规 格 输 出 菲 林 与 印 刷 3 .最...
  • Page 2 USER GUIDE Top Control Dishwasher CDM2450TS ） (6 Program third rack adjustable upper rack Before using your new product, please read these instructions to prevent any damage.

  • Page 3: Table Of Contents

    Contents Introduction ......... . .3 IMPORTANT SAFETY INSTRUCTIONS .

  • Page 4: Introduction

    Introduction Congratulations on your purchase of a high-quality Midea product. Your new represents the state of the art in dishwasher design and is designed for reliable and trouble-free performance. IMPORTANT SAFETY INSTRUCTIONS CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN This symbol indicates that dangerous voltage constituting a risk of electric shock is present within your dishwasher.
  • Page 5 WARNING Electric Shock Hazard Failure to follow these instructions can result in electric shock, fire, or death. WARNING-DANGER ̶Never allow children to play with, operate, or crawl inside the dishwasher. Turn off the dishwasher before carrying out user maintenance on it. If a component part is damaged, it must be replaced by the manufacturer, its service agent, or similar qualified persons in order to avoid a hazard.
  • Page 6 • Do not store or use combustible materials, gasoline or other flammable vapors and liquids in the vicinity of this or any other appliance. • Use only detergents or rinse agents recommended for use in a dishwasher and keep them out of the reach of children. Keep young children and infants away from dishwasher when it is •...

  • Page 7: Package Contents

    Package contents • Dishwasher • Drain Hose • Installation kits ( 4 wood screws ; 2 top mounting clip ; 1 hose clamp) • User Guide • Installation Guide Main components Top rack Upper spray arm (on some model) Cup shelf Upper rack Middle spray arm Tub gasket...

  • Page 8: Installing And Setting Up Your Dishwasher

    Installing and setting up your dishwasher Water supply temperature should be between 120° F and 149° F (49° C and 65° C). Dispose of the discarded appliance and packing material properly. The dishwasher must be grounded or it can result in a risk of electric shock. If there is any damage of the contact to the dishwasher, please contact Customer Service.

  • Page 9: Filter System

    An automatic sensor checks the incoming water temperature and, if it is not hot enough, the timer will be delayed to allow for the water to heat for the main wash of all cycles. This happens even when hi-temp wash is selected, so that higher temperature will be available to handle heavier soil loads.

  • Page 10: Using Your Dishwasher

    Using your dishwasher Using the control panel Your dishwasher's control panel is located on the top edge of the door. The door must be opened to make settings and operate the dishwasher. Power Turn on / off the power by press and hold for 3 seconds. Cycles soil on Select a cycle based on the type of dishes to be washed and the level of...
  • Page 11 CYCLE DESCRIPTION WATER USE CYCLE TIME (MINUTES) Use to lock all controls to prevent children from accidently changing the dishwasher Control cycle or starting the dishwasher. Press the Normal and 1 Hr Wash buttons at the same Lock time to select or cancel the function. The indicator light show the status.
  • Page 12 Available Options CYCLES Sanitize Heated Steam Hi Temp Zone wash Cyclone Jet prewash Auto √ √ √ √ Heavy √ √ √ √ √ √ Normal √ √ √ √ √ √ √ √ Light&ECO √ √ √ √ √ √...
  • Page 13 16 - START̶Press to start the dishwasher after you have selected a cycle and function (if desired). And close the door within 4 seconds of pressing START. The cycle indicator and the function indicator (if selected) turns on. If you donʼt close the door within four seconds of pressing START, the dishwasher pauses.

  • Page 14: Basic Operation

    Basic operation 1 Load the dishwasher (See “Preparing and loading dishes” on page 13). 2 Add detergent (See “Filling the detergent dispenser” on page 20). 3 Add rinse aid (See “Filling the rinse aid dispenser” on page 21). 4 Select the cycle you want (See the “Basic operation” on page 9). The indicator will light when the selection is made.
  • Page 15 Adjusting the top rack This dishwasher has a convenient top rack for silverware, cutlery, and small items. This rack can be adjusted to accommodate varying loads, as shown below. Left and right racks aligned Left rack adjusted to lower position and right rack angled Left rack adjusted to lower position and right rack to upper position Left rack adjusted to lower position and right rack moved to the left Left rack adjusted to lower position and right rack removed...
  • Page 16 Loading the top rack You can place the items in the top rack randomly or in an orderly fashion. The image below (just the sketch map for location)shows how to load the top rack for 16 place settings: Large spoons Knives Small spoons Small forks...
  • Page 17 Adjusting the upper rack The height of the upper rack can be adjusted to accommodate loading taller dishes in either rack. 1 Lift the rack to move it to the upper position. Upper rack in the upper position 2 Press the handle to move it to the lower position. Upper rack in the Lower position Loading the upper rack The upper rack is designed for cups, glasses, small plates, bowls, and plastic...
  • Page 18 Loading suggestions are shown below: 8 place settings 12 place settings 14 place settings 16 place settings...
  • Page 19 Loading the bottom rack The bottom rack is designed to accommodate plates, bowls, saucers, and cookware. The adjustable rack lets you load items up to 13 inches high. Large items should be placed along the edge, with the inside faces down, so they do not interfere with the middle or lower spray arms or prevent the detergent dispenser from opening.

  • Page 20: Adding A Dish

    Loading the silverware basket The silverware basket is divided into three separate sections, which can be placed in either the upper or lower racks. Spoons Forks and salad forks Forks and salad forks Knives Large forks Large spoons Large forks Knives Caution Make sure that nothing protrudes...

  • Page 21: Filling The Detergent Dispenser

    Filling the detergent dispenser Open the detergent dispenser flap by pushing the detergent dispenser release catch. Add detergent into the larger cavity (A) for the main wash cycle . For better cleaning result, especially if you have very dirt items, pour a small amount of detergent onto the door.

  • Page 22: Filling The Rinse Aid Dispenser

    Filling the rinse aid dispenser Your dishwasher is designed to use a liquid rinse aid. The use of rinse aid greatly improves drying performance after the final rinse. Do not use a solid or bar-type rinse aid. Under normal conditions, the rinse aid will last approximately one month.

  • Page 23: Factors Affecting Performance

    Factors affecting performance Using rinse aid Rinse aid greatly improves drying and reduces water spots and filming. Without rinse aid, your dishes and dishwasher interior will have excessive moisture. In addition, the heated dry option will not perform as well without rinse aid. The rinse aid dispenser, located next to the detergent cup, automatically releases a measured amount of rinse aid during the last rinse.

  • Page 24: Maintaining Your Dishwasher

    Factors affecting performance Caution TO AVOID BURN INJURY: Allow the heating element to cool before attempting to clean the interior of your dishwasher. Cleaning the stainless steel panel Clean the stainless steel door and handle regularly with a soft cloth and standard household cleaner to remove the debris.
  • Page 25 2 Rotate the cylinder filter, then lift it out. 3 Lift the fine filter from the bottom of the tub. 4 Take out the fabric filter.

  • Page 26: Cleaning The Door And Tub Gaskets

    5 Flush the filters by holding them under running water. 6 Replace the fabric filter. 7 Replace the fine filter. 8 Replace the cylinder filter. 9 Replace the bottom rack. Cleaning the door and tub gaskets Clean the door gasket with a damp cloth to remove food particles regularly.

  • Page 27: Cleaning The Air Gap

    The inside of the dishwasher is self-cleaning under normal use. If needed, the tub gasket can be cleaned with a damp cloth. Use a brush to clean the opening in the end of the gasket. Cleaning the air gap Air gap is an external plumbing device that is not part of your dishwasher. Some state or local plumbing codes require the addition of a drain air gap between a built-in dishwasher and the home drain system.

  • Page 28: Troubleshooting

    3 Place a pan under the inlet valve, then disconnect water line from the inlet valve and drain it into a pan. 4 Disconnect drain line from pump and drain the water into a pan. To restore service: 1 Reconnect the water, drain, and electrical power. 2 Turn on water and electrical power supply.
  • Page 29 PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION The dishwasher won’t The door may not be closed Make sure that the door is closed and latched. start properly. The power is off or not Make sure that the power is connected and turned on. connected.
  • Page 30 PROBLEM POSSIBLE CAUSE POSSIBLE SOLUTION Spots and filming on Water hardness is too high For extremely hard water, install a water softener. dishes Dishes are loaded improperly. Reload the dishwasher as shown in “Preparing and loadingdishes” on page 12. Old or damp rinse aid power is Use fresh, liquid rinse aid.

  • Page 31: Specifications

    Specifications Specifications Capacity Max 16 place settings Dimensions (WxDxH) 23.9 x 24.5 x 33.8 in. (606 x 622 x 858mm) Power requirements 120 V~60 Hz Current 8.4 A Water pressure Between 20 and 120 psi (138 and 827kPa) Noise (dB) 45 dB...
