SERVICE NOTES
Contents
3-6 CUTTER PROTECTION REPLACEMENT
4-1 SPECIAL TOOL
4-2 SERVICE MODE
4-3 HOW TO UPGRADE FIRMWARE
Windows is registered trademark or trademark of Microsoft Corporation in the United States and/or other countries.
Unauthorized copying or transferral, in whole or in part, of this manual is prohibited.
1-1
1-3
1-5
1-6
1-7
1-7
5 Supplemental Information
5-1 OPERATIONAL SEQUENCE
5-2 SENSOR MAP
2-1
2-2
6 Troubleshooting
2-5
6-1 START AND END POINTS DO NOT MATCH
6-2 STITCH CUT
6-3 MEDIA SHIFTING
3-1
6-4 TOOL UP/DOWN ERROR
3-5
6-5 FAN REVOLUTION
3-7
6-6 MOTOR ERROR
3-10
3-13
7 Service Activities
3-14
7-1 INSTALLATION CHECK LIST
7-2 MAINTENANCE CHECK LIST
7-3 SPECIFICATION
4-1
4-2
4-4
4-6
4-8
GX-24
POSITION ADJUSTMENT
POSITION ADJUSTMENT
First Edition
Copyright©2005 ROLAND DG CORPORATION
4-10
4-13
4-16
5-1
5-2
6-1
6-2
6-3
6-3
6-4
6-4
7-1
7-5
7-6
GX-24 '05. May
8770-00
Advertisement
Table of Contents
Related Manuals for Roland CAMM-1
Summary of Contents for Roland CAMM-1
-
Page 1: Table Of Contents
First Edition Windows is registered trademark or trademark of Microsoft Corporation in the United States and/or other countries. GX-24 '05. May Unauthorized copying or transferral, in whole or in part, of this manual is prohibited. Copyright©2005 ROLAND DG CORPORATION 8770-00... - Page 2 Revision Record Revision Date Description of Changes Approval Issued 2005.5.30 First Edition Kato Sato...
-
Page 3: Structure & Spare Parts
1 Structure & Spare Parts 1-1 COVERS... - Page 4 1-1 COVERS PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts- Parts No. Parts Name Parts No. Parts Name 1 22095160 S1 31019159 APRON,B GX-24 SCREW,BINDING M4*6 NI 2 22095159 S2 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. APRON,F GX-24 3 W022805612 ASSY,PANEL BOARD GX-24 S3 31019401 SCREW,BINDING M4*6 NI+EXT.TW 4 21835115...
-
Page 5: Frame
1-2 FRAME... - Page 6 1-2 FRAME PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts- Parts No. Parts Name Parts No. Parts Name 1 22805624 ASSY,FEED MOTOR GX-24 S1 31019135AS SCREW SET,BIND M3*6 NI 100 PCS. 2 22805625 ASSY,SCAN MOTOR GX-24 S2 31019159 SCREW,BINDING M4*6 NI 3 W022805616 ASSY,PLATE BOARD GX-24 S3 31019703AS SCREW,BINDING P-TIGHT 3*8BC 100P 4 22805631...
-
Page 7: Carriage
1-3 CARRIAGE PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts- Parts No. Parts Name Parts No. Parts Name 1 W022805615 ASSY,CARRIAGE BOARD GX-24 S1 31329601AS CLAMP SET,INSULOK T-18S 100 PCS. 2 22805623 ASSY,CARRIAGE GX-24 S2 31379106AS CLAMP SET,MINI MB-2 20 PCS. 3 W022805614 ASSY,CROP-BOARD GX-24 S3 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. -
Page 8: Chassis
1-4 CHASSIS PARTS LIST -Main Parts- PARTS LIST -Supplemental Parts- Parts No. Parts Name Parts No. Parts Name S1 31289102AS CUPSCREW SET,M3*6 NI 50 PCS. 7877009020 ASSY,MAIN BOARD GX-24 22525113 BUSH,FOOT FF-2 TW 22815158 CHASSIS,GX-24... -
Page 9: Accessories
1-5 ACCESSORIES PARTS LIST -Main Parts- Parts No. Parts Name 1 7877103001 ASSY,GX-V-KIT 230VC-KIT 2 22355647 BASE, SHEET CM-24 3 23445109 CABLE,USB 1.8M TW 4 23495119 CABLE-AC,2P 117V 2.5M TW 5 23495120 CABLE-AC,2P 230V 2.5M TW 6 23495122 CABLE-AC,2P 240VE 2.5M TW 7 23495123 CABLE-AC,2P 240VA 2.5M TW 8 22605469... -
Page 10: Electrical Section
2 Electrical Section 2-1 WIRING MAP... -
Page 11: Main Board
2-2 MAIN BOARD MAIN BOARD COMPONENT DIAGRAM_COMPONENT SIDE It indicates the version of the Main Board. DIP SW No. 1 - 4 : Always OFF... - Page 12 MAIN BOARD_Circuit Diagram 1/2...
- Page 13 MAIN BOARD_Circuit Diagram 2/2...
-
Page 14: Other Circuit Boards
2-3 OTHER CIRCUIT BOARDS OTHER CIRCUIT BOARDS_COMPONENT SIDE PANEL BOARD CROP BOARD (Soldering Side) CARRIAGE BOARD PINCH BOARD (Soldering Side) - Page 15 OTHER CIRCUIT BOARDS_Circuit Diagram LCD1 LCD LMC-SSC2K16DLNY-01 PANEL BOARD VCC3 RS20M113JA03 VCC3 TEST SW13 TSTB-2-L ORIGIN SW12 TSTB-2-L PAUSE SW11 TSTB-2-L LEFT CURSOR SW10 TSTB-2-L TOP CURSOR TSTB-2-L DOWN CURSOR TSTB-2-L RIGHT CURSOR TSTB-2-L 17FMN-BTK-A MENU TSTB-2-L FORCE TSTB-2-L ENTER TSTB-2-L POWER TSTB-2-L...
-
Page 16: Replacement Of Main Parts
3 Replacement of Main Parts The necessary adjustments after the replacement of each part, and the referential time for each work are described as follows. TOOL CARRIAGE REPLACEMENT : 10min. PINCH ROLLER REPLACEMENT : 5min. 1. TOOL HEIGHT ADJUSTMENT < Total Time : 5min. > 2. -
Page 17: Manual Tool/Crop Mark Sensor
Disconnect the Cables of CROP MARK SENSOR, SOLENOID PINCH ROLLER SENSOR and SOLENOID. CROP MARK SENSOR PINCH ROLLER SENSOR Unhook and remove the CABLE STAY. HOOK CABLE STAY Remove the TOOL CARRIAGE. SCREWS Remove the CABLE TIE for fixing the wirings. CABLE TIE... - Page 18 Remove the CROP MARK SENSOR from the TOOL CARRIAGE. SCREWS Fix the CROP MARK SENSOR to the new TOOL CARRIAGE. SCREWS Fix the Cables of CROP MARK SENSOR and SOLENOID with the CABLE TIE. CABLE TIE Pass the PINCH ROLLER SENSOR CABLE through PINCH ROLLER SENSOR CABLE the hole of the TOOL CARRIAGE and fix the TOOL CARRIAGE by lifting it up.
- Page 19 Fix the CABLE STAY and fix the Cables with the HOOK HOOK. CABLE STAY Connect the Cables of CROP MARK, PINCH ROLLER SOLENOID and SOLENOID. CROP MARK SENSOR PINCH ROLLER SENSOR Carry out the following adjustments. 1. TOOL HEIGHT ADJUSTMENT 2.
- Page 20 3-2 MAIN BOARD_REPLACEMENT Remove the RIGHT SIDE COVER, PANEL, TOP REAR APRON RIGHT SIDE COVER COVER, TOP PANEL, UNDER PANEL, FRONT TOP PANEL TOP COVER APRON and REAR APRON. Make sure to disconnect the Cables connected to the PANEL from the MAIN BOARD.
