- Page 1 Telemetry Transmitter Installation Guide Models covered Tx300 Building Block Video Ltd., Unit 1, Avocet Way, Diplocks Industrial Estate, Hailsham, East Sussex, UK. Tel: +44 (0)1323 842727 Fax: +44 (0)1323 842728...
-
Page 2: Safety Precautions
INTRODUCTION The BBV Tx300 is a very easy-to-use keypad for use in a single-camera CCTV system. It is easily installed into either a new or an existing system simply by connecting a BNC input and output, or twisted wire pair and a 9-volt supply. -
Page 3: Keypad Functions
LAYOUT OF THE BBV Tx300 KEYPAD KEYPAD FUNCTIONS Pan and Tilt Action: Press the relevant direction arrow(s) Tx300 Telemetry Transmitter Installation Handbook Rev-03 Page 3 of... -
Page 4: Iris Level Program
High Speed Lens Action is activated. Inching is achieved by quick presses of the key. Auxiliary Function Switch There is only one auxiliary function switch on the Tx300, it is designated as the lights relay, press for on, press for off. SELF TEST To run Self-Test, press Program and Focus Far. - Page 5 During random pan, the camera can be tilted to the desired angle using the up/down buttons. Random pan is disabled by pressing either the pan right or the pan left button. Tx300 Telemetry Transmitter Installation Handbook Rev-03 Page 5 of...
- Page 6 If the Rx is over driven from the RF/ Laser/Microwave equipment, the error LED will light. Connecting a 470R Tx300/400/400DC resistor across Pin 1/2 cures problem. PROGRAM AUTOPAN IRIS FOCUS ZOOM & PRESETS LENS TILT Tx300 Telemetry Transmitter Installation Handbook Rev-03 Page 6 of...
