Page 2
When servicing this product, under no circumstances should the commercially available discharging wrist strap device, which should be original design be modified or altered without permission from Zenith removed for potential shock reasons prior to applying power to the unit under Electronics Corporation.
All manuals and user guides at all-guides.com TABLE OF CONTENTS SPECIFICATIONS..............4 DESCRIPTION OF CONTROLS ...........5 ADJUSTMENT INSTRUCTIONS ..........8 BLOCK DIAGRAM...............10 EXPLODED VIEW...............12 EXPLODED VIEW PARTS LIST .........13 REPLACEMENT PARTS LIST ..........14 SCHEMATIC DIAGRAM............PRINTED CIRCUIT BOARD ........... - 3 -...
Page 4
All manuals and user guides at all-guides.com SPECIFICATIONS Model L15V26D Horizontal size (inches) 15.2 Height (inches) 14.5 Depth (inches) Weight (pounds) Power requirements AC 120V, 60Hz Television system NTSC Television channels VHF : 2 ~ 13, UHF : 14 ~ 69...
Page 5
All manuals and user guides at all-guides.com DESCRIPTION OF CONTROLS Front of the Front of the Side Control Panel Side Control Panel Channel Buttons Volume Buttons Enter Button Menu Button TV/Video Button On/Off Button Remote Control Sensor Power/Standby indicator Illuminates red in standby mode, Illuminates green when the TV is turned on.
Page 6
All manuals and user guides at all-guides.com DESCRIPTION OF CONTROLS Back of the Back of the Connection Panel Connection Panel VIDEO (MONO) AUDIO S-VIDEO AC INPUT PC INPUT ANT IN COMPONENT(480i/480p/720p/1080i) (120V) VIDEO IN +75 Ω SOUND DVD/DTV IN S-Video Input Power Cord Socket PC Sound Headphone Jack...
Page 7
All manuals and user guides at all-guides.com DESCRIPTION OF CONTROLS Remote Control Buttons Remote Control Buttons power tv/video POWER TV/VIDEO NUMBERS CLOSED CAPTIONS menu mute MUTE MENU ENTER enter CHANNEL ( DE ) VOLUME ( F G ) sleep SLEEP TIMER flashbk dasp DASP...
All manuals and user guides at all-guides.com ADJUSTMENT INSTRUCTIONS 5. RS232C(RMS Only) (1) Use the Untwisted 232C Cable (2) Use the PC program which is sent by Zenith (3) 232C Protocol Command Remark Power On E110F1 Turn the set on.
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST For Capacitor & Resistors, the CC, CX, CK, CN : Ceramic RD : Carbon Film charactors at 2nd and 3rd digit CQ : Polyestor RS : Metal Oxide Film RUN DATE : 2003.8.20 in the P/No.
Page 15
All manuals and user guides at all-guides.com REPLACEMENT PARTS LIST LOCA. NO PART NO DESCRIPTION LOCA. NO PART NO DESCRIPTION C128 0CE227BH618 220UF KME 25V M C649 0CQ1031N509 0.01U 100V K 0CE227DF618 220UF STD 16V M C651 0CE107BH618 100UF KME 25V M C209 0CE476DF618 47UF STD 16V M...
