ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
IMPORTANT - This Document is customer property and is to remain with this unit. Please return to service informa-
tion pack upon completion of work.
These instructions do not cover all variations in systems nor provide for every possible contingency to be met in connection with
the installation. Should further information be desired or should particular problems arise which are not covered sufficiently for the
purchaser's purposes, the matter should be referred to your installing dealer or local distributor.
Section 1. Safety ............................................................................................................................2
Section 2. Overview and Common Steps ....................................................................................3
Section 3. Coil with a Mechanically Fitted TEV ...........................................................................4
Section 4. Coil with a Brazed TEV ................................................................................................6
Section 5. Coil with a FCCV ..........................................................................................................8
Section 6. Reconnecting new coil assembly ............................................................................10
Table of Contents
........................................................................................................................................3
..............................................................................................................................3
...........................................................................................................................................4
..........................................................................................................................4
....................................................................................................................4
...........................................................................................................................................6
....................................................................................................................6
.................................................................................................................................................8
...........................................................................................................................................8
..................................................................................................................8
Installer's Guide
Replacement Coils
Includes all coil models
COL16255 through COL16291, COL16559,
COL16760, COL16761
Kit numbers BAYCOIL55, 56, 57, 58, 59, 71,
72, 73, 74, 75, 78, 79, 80, 83
18 - AH4 7D1 - 2
A341869P22
