7FS100A

Welcome to Follett

Follett equipment enjoys a well-deserved reputation for excellent performance, long-term reliability and outstanding
after-the-sale support. To ensure that this equipment delivers that same degree of service, review this guide
carefully before you begin your installation.
Should you need technical help, please call our Technical Service group at (877) 612-5086 or (610) 252-7301.
Please have your model number, serial number and complete and detailed explanation of the problem when
contacting Technical Service.

Getting Started

After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. All freight
is to be inspected upon delivery. If visible signs of damage exist, please refuse delivery or sign your delivery receipt
"damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed
photos of the damage with the original packaging so that we may start the freight claim process.
801 Church Lane • Easton, PA 18040, USA
Toll free (877) 612-5086 • +1 (610) 252-7301
www.follettice.com
Countertop and Freestanding Ice and Water
Dispenser with Chewblet
7CI100A, 7FS100A, 15CI100A, 15FS100A
Installation, Operation and Service Manual
7CI100A
15FS100A
®
Serial numbers after K70778
15CI100A
Installation and Service Videos:
www.follettice.com/servicevideolibrary
Ice Machine
00951640R24

Advertisement

Table of Contents
loading

Related Manuals for Follett 7FS100A

Summary of Contents for Follett 7FS100A

  • Page 1: Welcome To Follett

    If visible signs of damage exist, please refuse delivery or sign your delivery receipt "damaged." Follett Customer Service must be notified within 48 hours. Wherever possible, please include detailed photos of the damage with the original packaging so that we may start the freight claim process.

  • Page 2: Table Of Contents

    Base Stand ................44 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 3: Before You Begin

    00981100R01 Check your paperwork to verify that you received the correct dispenser. Follett configuration numbers are designed to provide information about the type of dispenser you are receiving. The following is an explanation of the different model numbers.

  • Page 4: Important Safety Information

    Important Safety Information Please read and adhere to the following safety information while installing, using, or servicing your Follett Ice Dispenser. 1. Always disconnect power before servicing the dispenser. 2. Ice is slippery. Maintain counters and floors around dispenser in a clean and ice-free condition.

  • Page 5: Specifications

    § Must be grounded - requires 3-prong outlet. Do not remove ground. Refrigeration WARNING! Do not damage the refrigerant circuit. Refrigerant can cause personal injury and/or damage dispenser. § Refrigerant R134a – 5.0 ounces (142 grams) Heat Rejection § 1700 BTU/hr (498 W) 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 6: Series Detailed Drawing

    17.50" 17.50" (115 V only) (44.5 cm) (44.5 cm) 6.88" 6.75" (17.5 cm) (17.2 cm) power cord 2.50" 3.00" (6.4 cm) (7.6 cm) water inlet: 1/4" MPT or John Guest push-in fitting 24.38" (61.9 cm) 22.12" (56.2 cm) 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 7: Series Detailed Drawing

    22.50" (57.2 cm) 22.38" (56.8 cm) power cord 6.88" 6.75" (17.5 cm) (17.2 cm) 46.75" (118.7 cm) water inlet: 2.50" 3.00" (6.4 cm) (7.6 cm) 1/4" MPT or John Guest push-in fitting 24.38" (61.9 cm) 22.12" (56.2 cm) 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 8: Installation

    * If your dispenser has the internal water filter option, the water filter must be installed for the dispenser to operate. Because internal components will need to Plug be accessed for both procedures, Follett recommends installing the water filter just prior to initial sanitizing. Valve 5.

  • Page 9: Freestanding Installation

    8 ft (2.4 m) cord and plug. § Water: supply line (with shut-off valve) connects to the dispenser's 1/4" MPT or John Guest push-in fitting inlet. NOTICE! If installing optional Leg Accessory, complete those steps before proceeding. See page 11 for Leg Accessory instructions. 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 10 * If your dispenser has the internal water filter option, the water filter must be installed for the dispenser to operate. Because internal components will need to Plug be accessed for both procedures, Follett recommends installing the water filter just prior to initial sanitizing. Valve Connect power supply.
  • Page 11 If your dispenser has the internal water filter option, the water filter must be installed for the dispenser to operate. Because internal components will need to be accessed for both procedures, Follett recommends installing the water filter just prior to initial sanitizing.

  • Page 12: Maintenance/Cleaning Mode

    4. Remove the two screws (Fig. 11.3) on the front panel (behind the drip tray). 5. Remove and set aside the front panel (Fig. 11.4). Do not disengage the plug on the back of the User Interface or the tubing at the water dispenser chute (if so equipped). 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 13: Filter Display Indicator Activation

    Filter Display Indicator Activation Fig. 12 If you purchased your dispenser with a Follett filter, the filter display indicator activation has been preset at the factory. If you are using an “after market filter,” an adjustment may be made to activate the “Fresh Filtered Ice &...

  • Page 14: Cleaning And Sanitizing Procedure

    § 7 Series: Follow the directions on the SafeCLEAN Plus packaging to mix 3 gal (11.4 L) of Follett SafeCLEAN Plus solution. Use 100 F (38 C) water. 15 Series: Follow the directions on the SafeCLEAN Plus packaging to mix 6 gal (22.7 L) of Follett SafeCLEAN Plus solution.

  • Page 15: Service

    7 Series:12 hours has elapsed, 15 Series: 4 hours has elapsed or ice or water has dispensed. Making ice Green Gearmotor, compressor, and fan motor energized. Low bin Green Bin switch closed calling for ice. Power on Green Power supplied to unit. 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 16: Evaporator Disassembly

    User Interface. Lift and remove the top panel, set aside (Fig. 16.5). 8. Remove two screws (Fig. 16.6) and remove left side panel. 9. Remove two screws (Fig. 16.7) and remove right side panel. 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 17 § Pull gear motor from auger (Fig. 18.3). § Remove main housing insulation (Fig. 18.4). 13. Remove all traces of Petrol-gel from auger shaft. 14. Remove compression nozzle: Fig. 19 § Loosen hose clamp (Fig. 19.1). § Remove transport tube (Fig. 19.2). 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 18 16. Remove compression nozzle retainer (Fig. 20.2). 17. Remove compression nozzle (Fig. 20.3). 18. Remove main housing: Fig. 21 § Disconnect vent line from T fitting (Fig. 21.1). 19. Remove three M6x25 socket head allen screws Fig. 22 (Fig. 22.1). 20. Remove main housing (Fig. 22.2). 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 19: Evaporator Assembly

    Contact with bare skin will cause premature seal failure. 5. Install auger (Fig. 24.4). 6. Install main housing: Fig. 25 § Slide main housing onto auger shaft (Fig. 25.1). § Install three M6x25 allen screws (Fig. 25.2). § Connect vent line to T fitting (Fig. 25.3). 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 20 8. Install transport tube (Fig. 27.1). Fig. 27 9. Tighten hose clamp (Fig. 27.2). 10. Install gear motor: Fig. 28 § Install main housing insulation (Fig. 28.1). § Slide gear motor onto auger shaft (Fig. 28.2). § Install two M6x90 allen screws (Fig. 28.3). 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 21 13. Install spacer, ensure that key is captured in slot Fig. 30 (Fig. 30.1) 14. Insert screwdriver into groove of auger shaft and pry shaft Fig. 31 outwards (Fig. 31.1). 15. Insert retainer into groove (Fig. 31.2), ensure that retainer is aligned with hole in spacer. 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 22 16. Install screw and tighten (Fig. 32.1). Fig. 32 17. Plug in gear motor (Fig. 33). Fig. 33 § BLUE to BLUE § BLACK to BLACK § WHITE to WHITE § Connect ground wire with ground screw. 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 23: Water Feed Schematic

    Water Feed Schematic Evaporator Float Water Chute (optional) Water Solenoid Valve Filter (optional) (optional) Water Solenoid Valve 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 24: Bin Melt Water/Evaporator Feed/Clean Out System Schematic

    Bin Melt Water/Evaporator Feed/Clean Out System Schematic Storage Bin Vent System Schematic Storage Bin Vent Tube Reservoir 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 25: Refrigeration Schematic

    Refrigeration Schematic CONDENSER FILTER-DRIER CAP TUBE COMPRESSOR EVAPORATOR LOW PRESSURE LIQUID HIGH PRESSURE VAPOR HIGH PRESSURE LIQUID LOW PRESSURE VAPOR 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 26: Condenser Fan Motor Removal (7 Series Shown)

    Condenser Fan Motor Removal (7 Series Shown) 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 27: User Interface Display Identification

    Exit Maintenance Mode by pressing and holding maintenance/clean switch until no longer displays. 8000-hour Press and hold the reset button on the Service and circuit board for one minute. maintenance check 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 28 D45191, the phone and wrench will not be illuminated. Internal leak in Locate leak and repair - Press reset dispenser on control board. Contact Follett if unit is leaking. Sleep mode Press either dispense button to return to normal operation. 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 29: Electrical Wiring Diagram

    Service (continued) Electrical Wiring Diagram 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 30: Parts

    Parts 7 Series Exterior 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 31 00990796 Not Shown Drip Tray Drain Kit 00956375 Not Shown Drip Tray Drain Kit with 4" legs 00981977 Not Shown Replacement Overlay, Agion, User Interface (5 pieces) 01362623 Not Shown Replacement Overlay, Agion, User Interface (50 pieces) 01363761 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 32: Series Interior

    7 Series Interior 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 33 Valve, Failsafe Solenoid 00957738 Compressor with Mounting Hardware 01157296 Condenser 00958017 Condenser Fan, Cord and Hardware 01157288 Control Board with Stand-offs 00958033 Capacitor, Gearmotor 00958041 Sensor, Retainer Hardware Kit 00958066 Relay and Overload 01157387 Heat Exchanger, Kit 01233998 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 34: Series Exterior

    15 Series Exterior 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 35 00990796 Not Shown Drip Tray Drain Kit 00956375 Not Shown Drip Tray Drain Kit with 4" legs 00981977 Not Shown Replacement Overlay, Agion, User Interface (5 pieces) 01362623 Not Shown Replacement Overlay, Agion, User Interface (50 pieces) 01363761 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 36: Series Interior

    15 Series Interior 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 37 Valve, Failsafe Solenoid 00957738 Compressor with Mounting Hardware 01157296 Condenser 00958017 Condenser Fan, Cord and Hardware 01157288 Control Board with Stand-offs 01051978 Capacitor, Gearmotor 00958041 Sensor, Retainer Hardware Kit 00958066 Relay and Overload 01157387 Heat Exchanger, Kit 01233998 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 38: Series Bin Assembly

    7 Series Bin Assembly 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 39 Flag, shuttle 00998286 Spring, wave 00998302 Bracket, shuttle support (Before serial number K46457) 00998260 Bracket, shuttle support (After serial number K46456) 00998336 Screws (2), self-tapping, #10 x 5/8 00998328 Screws (2), M3 x 12 Phillips pan head 00998294 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 40: Series Bin Assembly

    15 Series Bin Assembly 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 41 Bin assembly, 15 Series (does not include ice transport tube and insulation) 01255488 Agitator 01255504 Coupling, transport tube 00998278 Flag, shuttle 00998286 Spring, wave 00998302 Bracket, shuttle support 00998260 Screws (2), self-tapping, #10 x 5/8 00998328 Screws (2), M3 x 12 Phillips pan head 00998294 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 42: Evaporator Assembly

    Evaporator Assembly 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 43 Seal kit (includes front auger seal, reservoir lid o-ring, compression nozzle 01348093 o-rings, end bushing cap with o-ring and (2) screws, rear flange jacket, vent tube retainer, and 1 ft of 1/4" tubing) Insulation Kit (5 pieces) 01442557 Front Flange Jacket 00947721 Rear Flange Jacket 00947739 7CI100A/7FS100A, 15CI100A/15FS100A...

  • Page 44: Base Stand

    Base Stand 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 45 Not Shown SafeCLEAN Plus liquid, 6 pack 01149954 Not Shown SafeCLEAN Plus liquid, case of 24 01149962 Not Shown 6" Legs for base stand, set of 4 00956318 Not Shown 4" Legs for countertop dispenser, set of 4 00956300 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 46 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 47 7CI100A/7FS100A, 15CI100A/15FS100A...
  • Page 48 Please visit www.follettice.com/support to complete the Warranty Registration form. Should you have any questions, please contact Follett's technical support group at (877) 612-5086 or (610) 252-7301 and we will be happy to assist you.
