Fujitsu UTY-RHRYT Operation Manual

REMOTE CONTROLLER (WIRED TYPE)
OPERATION MANUAL
PART No. 9373329787
Keep this manual for future reference.
SAFETY PRECAUTIONS
• To prevent personal injury or property damage, read this section carefully before you use
this product, and be sure to comply with the following safety precautions.
This mark indicates procedures which, if improperly performed, might lead
WARNING
to the death or serious injury of the user.
• In the event of a malfunction (burning
smell, etc.), immediately stop operation,
turn off the electrical breaker, and consult
authorized service personnel.
• Do not repair or modify any damaged cable
by yourself. Ask the authorized service
personnel to do it. Improper work will cause
an electric shock or a fire.
• When moving, consult authorized service
personnel for uninstallation and installation
of this product.
• Do not touch with wet hands. It may cause
an electric shock.
• If children may approach this product, take
preventive measures so that they cannot reach
this product.
This mark indicates procedures which, if improperly performed, might
CAUTION
possibly result in personal harm to the user, or damage to property.
• Do not set vessels containing a liquid on
this product. Doing so will cause heating,
fire, or electric shock.
• Do not expose this product directly to water.
Doing so will cause trouble, electric shock,
or heating.
• Dispose of the packing materials safely.
Tear and dispose of the plastic packing
bags so that children cannot play with them.
There is the danger of suffocation if children
play with the original plastic bags.
[Original instructions]
UTY-RHRYT
• Do not repair or modify by yourself. It may
cause a fault or accident.
• Do not use flammable gases near this
product. It may cause a fire from leaking
gas.
• This product is not intended for use by
persons (including children) with reduced
physical, sensory, or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of this product
by a person responsible for their safety.
Children should be supervised to ensure
that they do not play with this product.
• Do not place electrical devices within 1
m (40 in) of this product. It may cause
malfunction or failure.
• Do not use fire near this product or place
a heating appliance nearby. It may cause
malfunction.
• Do not touch the switches with sharp
objects.
Doing so will cause injury, trouble, or
electric shock.
OPERATING TIPS
Cooling/heating priority
(Heat pump model only)
• If another indoor unit in the same system is already operating in the cooling mode or
dry mode, heating mode settings cannot be performed.
• An indoor unit that is set up as a primary indoor unit can operate in the AUTO
mode.
• Primary indoor unit:
The primary indoor unit has priority for cooling and heating configurations.
Airflow direction setting
• When using this product together with a wireless remote controller, the airflow
direction of the indoor unit may not match the direction shown on this product.
• When the airflow direction is set with combination use of wireless remote controller
and this product, airflow direction setting shown on this product may differ from
actual louver position of the indoor unit.
• When the airflow direction is set with combination use of wireless remote controller
and this product in the same remote controller group, airflow direction setting
shown on this product may differ from actual louver position of the indoor unit.
TROUBLE SHOOTING
Before requesting service, perform the following checks:
Symptom
Does not oper- • Has there been a power failure?
ate at all. • Has a fuse blown out, or a circuit breaker been tripped?
• It is being controlled centralized?
If the problem persists after performing these checks, or if you notice burning smells or
blinking of the indicator lamps, immediately stop operation, turn off the electrical breaker
and consult authorized service personnel.
SPECIFICATIONS
Model Name
Input voltage
Dimensions & Weight
Problem
UTY-RHRYT
DC12V
Height 120 mm (4-3/4 in)
Width 75 mm (2-15/16 in)
Depth 19 mm (3/4 in)
Weight 120 g (4 oz)
MADE IN P.R.C.
En-1
