Toa F-1300WTWP EB-Q Manual

Specifications
Sensitivity (1 W, 1 m)
Frequency response
Connection
Crossover frequency
Rated input (high impedance)
Tappings
Speaker component
Finish
Operating temperature
We supply sound, not equipment.
www.toa.eu.
90 dB
80 Hz - 20 kHz (-10 dB)
Screw terminals
2000 Hz
30 W
100 V : 330 Ω (30 W) / 1 kΩ (10 W) / 3.3 kΩ (3 W) / 10 kΩ (1 W)
70 V : 170 Ω (30 W) / 330 Ω (15 W) / 1 kΩ (5 W) / 3.3 kΩ (1.5 W) / 10 kΩ (0.5 W)
Woofer: 13 cm (5'') cone-typeTweeter: 25 mm (1'') dome tweeter
HIPS resin, Steel plate, off-white (RAL 9010 or equivalent),
-10°C to + 50°C
EN 54 Certified Speakers
F-1300WTWP EB-Q
Article number:F-1300WTWPEB-Q
Alternative products: F-1300BTWP EB-
Q, F-1300WTWP, F-2000WTWP EB-Q,
F-1000BTWP EB-Q, F-1000WTWP EB-Q
©TOA Electronics Europe GmbH | Data subject to change without notice.
SPEAKER
EN, 2022/08/18
