F SERIES SPEAKER SYSTEM
TABLE OF CONTENTS
1. SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
2. DIMENSIONAL DIAGRAM AND NOMENCLATURE . . . . . .
4. FEATURES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
6. IMPEDANCE CHANGE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
8. LOGO BADGE REORIENTATION . . . . . . . . . . . . . . . . . . . . .
10. SPECIFICATIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
11. CHARACTERISTIC DIAGRAM . . . . . . . . . . . . . . . . . . . . . . .
Thank you for buying the TOA speaker system.
Please read this manual carefully to get the best performance from this speaker.
F-160G/F-160W
F-160GM/F-160WM
F-160WP (High impedance/outdoor use)
F-240G/F-240W
F-240GM/F-240WM
. . . . . . . . . . . . . . . . . . . . . . . . . .
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
TOA Corporation
INSTRUCTION MANUAL
(Low impedance)
(High impedance)
(Low impedance)
(High impedance)
2
3
4
4
4
5
5
6
. . . . . . . . . . . . . . . . . . . .
6
7
8
