Chapter 1 — Description
General Information
The cutter is a factory-installed or field-installable option for the
EasyCoder PF4i and PF4i Compact Industrial printers. The cutter auto-
matically cuts off the media after printing according to instructions in
the controlling firmware. The cut off portions of media are presented at
the front of the cutter and can be collected on a removable tray.
The cutter can be tilted forward to facilitate media load. As a safety mea-
sure, the cutter can only operate when being completely closed.
The cutter prevents an optional label taken sensor from working, even if
it not necessary to remove it before fitting the cutter.
Cutter unit
Tray
