Important Information
Specifi cation of
Hardware and
Operative System
Software Used
2
The operating system (fi rmware) of the printer is:
EasyCoder F2 and F4:
EasyCoder E4:
Printing is direct thermal or thermal transfer. With a 4-inch
printhead, a maximum of 104 signs per row with signs height
2 mm. With a 2-inch printhead, a maximum of 52 signs per row
with signs height 2 mm.
Conditional parts:
The printer may be equipped with the following protective
interface:
RS-232 serial communication
The only allowed printing command to be used in the printer is
the Direct Protocol command LAYOUT RUN and LAYOUT INPUT
associated commands.
The printer is connected to the Scale through a RS-232 connection.
With a protected command in the scale, the scale can be ordered
to send a command sequence for each label through the RS-232
interface.
The command sequence sent from the scale for every label is
as follows:
LAYOUT RUN "LAY1"
<STX>
Value1
Value2
...
ValueN
<EOT>
PF1
The layout recalled is stored in the printer memory. The layout can
be programmed through the printer's serial or parallel interface from
a PC and is stored in non-volatile memory (fl ash, memory card) and
recalled with the LAYOUT RUN "xxxx" command.
Intermec Scale-Connected Printers – Important Information Ed. 1
Intermec Fingerprint v7.32 or higher.
Intermec EasyCoder E4 Direct Protocol
v2.01 or higher.
Retrieve already stored format and
Start fi lling in the data fi elds of the label
where N is the same number of vari-
ables as in stored layout
read values
Print one label
