- Page 1 USER MANUAL Gas Built-in Cooking Appliances COOKING Models: GOP474, GOP476, GGP475, GXP650 WMAN_541_Jun10.indd 1 4/6/10 10:18:28 AM...
-
Page 2: Table Of Contents
GOP476 . . . . . . . . . . . . . . . . . . . . - Page 3 SAFEtY IMPORtANt SAFEtY INStRUCtIONS GRILL • The grill door must be left fully open whilst grilling in a separate grill wall oven (GXP650 model) . • The grill drawer must be left approximately two finger widths Please read the user manual carefully and store in a handy ajar whilst grilling in a separate grill underbench oven place for later reference .
-
Page 4: Description Of Your Appliance
FEAtURES GOP474 Oven indicator light Oven/Grill temperature selector Function selector 2 hour ‘Auto-off’ timer GOP476 Function indicator light Function selector Oven/Grill temperature selector Oven indicator light Electronic clock GGP475 Oven indicator light Function selector Electronic clock Grill indicator light Oven temperature selector... -
Page 5: Before Operating Your Appliance For The First Time
OPERAtION BEFORE OPERAtING YOUR APPLIANCE FOR tHE FIRSt tIME SEttING tHE tIME PREPARING YOUR APPLIANCE FOR tHE FIRSt tIME If you have purchased a model fitted with an electronic Installing your oven accessories clock, you must set the time of day before you can operate 1. - Page 6 OPERAtION BEFORE OPERAtING YOUR APPLIANCE FOR tHE FIRSt tIME 2. Shelves and trays • With the front edge raised, begin to slide the shelf into the oven . The shelves are designed so that they have maximum • Once the detents have passed the front edge of the side travel but cannot be accidentally pulled right out .
-
Page 7: Using Your Oven
. It will cook at a lower temperature and be faster than baking . Please note that some variation in browning is normal . Fan Grill (grill in oven GoP474, GoP476 models only) “Fan grill” offers you the benefits of both “bake” and traditional “grill”... -
Page 8: Cooling/Venting Fan
OPERAtION USING YOUR OvEN Cooling/Venting fan Pre-heating your appliance Your built-in appliance is fitted with a cooling fan . This For best results when baking you must preheat your oven for prevents your kitchen cabinet from overheating and reduces 30 minutes . Preheat grill for 3 minutes to obtain best results . the condensation inside the oven . -
Page 9: Cooking With Your Timer
OPERAtION COOKING wItH YOUR tIMER 2-hour “Auto off” timer Setting the time of day The 2-hour timer features an automatic oven “cut off” . This You must set the time of day before you can operate your means that a cooking period of up to 120 minutes can be appliance . -
Page 10: Cooking Guide
OPERAtION OPERAtING tHE ELECtRONIC CLOCK (CONt.) COOKING GUIDE Setting the delayed start cooking time • Select the correct shelf location for food being cooked. 1 . Program the “cook time“ and “end time“ as described • Make sure dishes will fit into the oven before you switch in the relevant sections . -
Page 11: Oven Shelf Location
OPERAtION COOKING GUIDE Choosing the best oven settings The following table is intended as a guide and experience may show some variation in cooking times necessary to meet individual requirements . For best results when baking you must preheat your oven for 30 minutes . -
Page 12: Roasting Meat
OPERAtION COOKING GUIDE GRILLING GUIDE Roasting Meat Grilling hints 1 . Place the meat in the oven and set the temperature between 180°C and 200°C . (It is recommended to WARNING wrap your meats in an oven roasting bag or foil to prevent fats and oils from splattering, making it easier to Always clean the grill / oven dish after every use. -
Page 13: Guide To Better Grilling
OPERAtION GRILLING GUIDE Guide to better grilling No definite times can be given for grilling because this depends on your own tastes and the size of the food . These times should only be used as a guide and remember to turn the food over half way through the cooking process . -
Page 14: Dealing With Cooking Problems
tROUBLESHOOtING DEALING wItH COOKING PROBLEMS (SEE ALSO P.18) PROBLEM CAUSES REMEDY Incorerct shelf position Select shelf that places food in the centre of the oven Oven tray too large Experiment with other trays or dishes Uneven cooking Trays not centralised Centre trays Air flow in oven uneven Rotate food during cooking... -
Page 15: Cleaning Your Appliance
CLEANING CLEANING YOUR APPLIANCE Separate Grill (GGP475, GXP650 models only) WARNING • Always keep the grill dish and grill dish insert clean, as any • Always make sure that the oven is electrically isolated fat deposits may catch fire . before cleaning . -
Page 16: Removing & Replacing Oven Light
MAINtENANCE MAINtAINING YOUR APPLIANCE GEt tO KNOw YOUR OvEN Releasing the grill element – grill in oven and Get to know your new oven with this ‘Simple separate grill models test Cake’ We have designed the upper element with a hanger clip Although we strive for a perfect performing oven, it’s possible to help you reach your cavity roof for cleaning . -
Page 17: Electronic Burner Control
SAFEtY ELECtRONIC BURNER CONtROL Your gas oven is fitted with an electronic controller which Recognising a Safety Shut-down Condition manages the operation of the burner and monitors the During normal cooking the Thermostat indicator light is on flame . This controller includes features which ensure the safe when the burner flame is igniting or on, and the Thermostat operation of your appliance and will prevent the build up of indicator light is off when the flame is off . -
Page 18: Solving Problems
tROUBLESHOOtING SOLvING PROBLEMS Faults PROBLEM POSSIBLE CAUSE If there is a problem with the oven and/or grill, please: • Check the points listed below before calling for service . - Time of day not set . It may be possible to avoid a call by fixing the problem - Power not turned on . -
Page 19: Installation
INStALLAtION INStALLING YOUR APPLIANCE CAUTION WARNING Use an authorised person. to avoid any potential hazard, you must follow our instructions below when you install your appliance. Failure to install the appliance correctly As stated in the local municipal building codes and other could invalidate any warranty or liability claims and lead to prosecution. -
Page 20: Gas Installation Information
INStALLAtION GAS INStALLAtION INFORMAtION Gas Connection Connecting flexible hose Before commencing installation, check to ensure the type • Place a spanner on the flats provided on the gas inlet of gas to which the appliance is intended to be connected to brace the inlet against the action of wrenching when matches the gas type given on the appliance data plate . -
Page 21: Operating Pressures
INStALLAtION GAS INStALLAtION INFORMAtION For NG Cookers: The outlet pressure should not vary operating Pressures from the nominal outlet pressure of 1 .00kPa by more Supply and operating pressures for various gases and than ±0 .20kPa . corresponding injector sizes for each burner . If the regulator apppears to not be performing satisfactorily, then check the following points . -
Page 22: Underbench Ovens
INStALLAtION GAS INStALLAtION INFORMAtION Underbench ovens Your underbench oven looks best when the control panel is directly under the benchtop . An upper infill panel may have to be added if the cooktop placed above the benchtop is too deep . Refer to cooktop installation instructions for required clearance between cooktop and oven . -
Page 23: Separate Grill Underbench
INStALLAtION GAS INStALLAtION INFORMAtION Separate grill underbench ovens GAS tYPE Flush fit 581min Proud fit 560min 1.7m flexible gas hose (supplied unfitted) 1.5m electrical D: Gas connection – 150mm from right hand side service cord – 220mm from bottom E: Electrical connection – 50mm from right hand side –... -
Page 24: Separate Grill Walloven
INStALLAtION GAS INStALLAtION INFORMAtION Separate grill walloven mounting holes Use 15mm long black installation screws supplied carry handle 8mm min clearance 1.7m flexible gas hose (supplied unfitted) 1.5m electrical service cord D: Gas connection – 150mm from right hand side –... -
Page 25: Door Removal
MAINtENANCE MAINtENANCE Door Removal Removing the door from your appliance • Open door fully. • Rotate the two stirrups forwards so that they are engaged together onto the hooks on the hinge arms . • Hold both stirrups in place and lightly close the door. The stirrups will now remain engaged . -
Page 26: Notes
NOtES WMAN_541_Jun10.indd 26 4/6/10 10:18:34 AM... -
Page 27: Warranty
Warranty FOR SALES IN AUSTRALIA AND NEW ZEALAND APPLIANCE: WESTINGHOUSE GAS BUILT-IN COOKER. This document sets out the terms and conditions of product warranties for (iii) normal wear and tear Electrolux branded appliances. It is an important document. Please keep it... - Page 28 The Electrolux Group to consumers including delivery, home service and spare parts . westinghouse. we are part of the Electrolux family. Share more of our thinking at www.electrolux.com © 2010 Electrolux Home Products Pty Ltd ABN 51 004 762 341...
