- Page 1 Owner’s manual Mode d’emploi Manual de instrucciones DFZ675MC 2-DIN CD/SD/MP3/WMA RECIEVER/ CeNET CONTROL/MUSIC CATCHER II RÉCEPTEUR CD/SD/MP3/WMA 2 DIN/ COMMANDE CeNET/MUSIC CATCHER II RECEPTOR DE CD/SD/MP3/WMA 2-DIN/ CONTROL CeNET/MUSIC CATCHER II...
-
Page 2: Table Of Contents
Thank you for purchasing this Clarion product. * Please read this owner’s manual in its entirety before operating this equipment. * After reading this manual, be sure to keep it in a handy place (e.g., glove compartment). * Check the contents of the enclosed warranty card and keep it carefully with this manual. -
Page 3: Precautions
Press and hold the button for 1 second or longer to perform disc scan play. [BND] button • Move the next disc in increasing order. DFZ675MC 2. PRECAUTIONS 1. When the inside of the car is very cold and the If this equipment does cause harmful... -
Page 4: Controls / Les Commandes / Controles
[DIRECT] [DIRECT] [A-M] [ROTARY] [ISR] DFZ675MC 4. NOMENCLATURE Notes: • Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold). • MC is the abbreviation of MUSIC CATCHER II. • SD is the abbreviation of SD memory card. -
Page 5: Display Items
: Disc number indication : Preset channel indication : Mute indication : Digital Z-Enhancer indication : MAGNA BASS EXTEND indication : Record indication : LP indication : STD indication : HQ indication : SHQ indication : MUSIC CATCHER II indication Source indication DFZ675MC... -
Page 6: Remote Control
Always follow these safety precautions: • Use only the designated battery. • When replacing the battery, insert properly, with +/- polarities oriented correctly. DFZ675MC [SRC] [ ],[ ] [MUTE] [ISR] [SCN] •... -
Page 7: Functions Of Remote Control Unit Buttons
MP3/WMA disc, MC, SD mode Switch reception band Move preset channels up and down No function Preset scan Press and hold the button for 2 seconds or longer to perform Auto store No function Switch between TV and VTR DFZ675MC... -
Page 8: Operations
➜ (DVD changer mode) ➜ (TV mode) ➜ AUX mode ➜ Radio mode... * External equipment not connected with CeNET is not displayed. DFZ675MC Notes: Be sure to read this chapter referring to the front diagrams of chapter “3. CONTROLS” on page 5 (unfold). Adjusting the volume 1. -
Page 9: Basic Operations
“B<Q 1.00>”. Turning the [ROTARY] knob and select the Q- curve. * The factory default setting is “B<Q 1.00>” (Adjustment options: 1.00/1.25/1.50/2.00). 5. When the adjustment is complete, press the [A-M] button several times until the function mode is reached. DFZ675MC... -
Page 10: Adjusting The Balance
(Adjustment range: F12 to R12). 3. When the adjustment is complete, press the [A-M] button several times until the function mode is reached. DFZ675MC Setting the button illumination 1. Press the [COLOR] button to select a color type. 2. Each time you press the [COLOR] button, the type changes in the following order: “COLOR SCAN”... -
Page 11: Radio Operations
[h] button again to continue receiving that station. Notes: • Be careful not to press and hold the [ 2 seconds or longer, otherwise the auto store function is engaged and the unit starts storing stations. ] button for DFZ675MC... - Page 12 ●Recalling a station with ISR In any mode, the [ISR] button turns on the radio function and tune the selected radio station. “ISR” appears in the display. Press the [ISR] button again to return to the previous mode. DFZ675MC...
-
Page 13: Features
• SD memory card maximum path length is 126 bytes. Notes: • This equipment does not support SD audio player. • This equipment does not support miniSD card and MMC (Multi Media Card) formats. DFZ675MC... - Page 14 DFZ675MC Loading a CD or a SD memory card 1. Insert a CD or a SD memory card into the center of the CD SLOT or the SD MEMORY CARD SLOT with the label side facing up.
-
Page 15: Pausing Play
Return to the first track (track No.1) of the disc or the folder currently being played back, and start playing. 1. Press the [BND] button. * In case of MP3/WMA files, return to the first track of a folder currently being played back. DFZ675MC... -
Page 16: Scan Play
SD memory card) in a random order. 1. Press the [RDM] button. 2. To cancel random play, press the [RDM] button again. DFZ675MC Folder random play This function allows you to play all tracks of all the folders recorded on an MP3/WMA disc or a SD memory card in a random order. -
Page 17: Music Catcher Ii (Recording/Erasing) Operations
Refer to the subsection “Setting a recording mode” (page 25) in the section “Adjust Mode”. • “SHQ” : about 248 minutes • “HQ” : about 331 minutes • “STD” : about 497 minutes • “LP” : about 663 minutes DFZ675MC... - Page 18 • When recording is canceled, the file that has been recorded incompletely is deleted. DFZ675MC Erasing operation (ERASE function) Erasing recordings made using MUSIC CATCHER II is performed in the M.CATCHER mode and the following 3 erasing modes are available.
-
Page 19: Common Operations
Common Operations CATS function (Clarion Anti- Theft System) This unit can deter theft by checking registered optional PIN (Personal Identification Number). How to register/delete PIN Refer to the subsection “How to register/delete PIN” (page 26) in the section “Adjust Mode”. -
Page 20: Setting The Clock
“ ” “ 4. Press the [D] button to return to the previous mode. DFZ675MC Entering MESSAGE INFORMATION When the use of the message is selected for the screen saver setting, you can change the contents of the message. * Up to 30 characters can be entered. -
Page 21: Adjust Mode
1. Press the [A] button to switch to the adjust mode. 2. Press the [R] or [F] button to select “BLINK LED”. 3. Turn the [ROTARY] knob and select “LED ON” or “LED OFF”. 4. Press the [A] button to return to the previous mode. DFZ675MC... - Page 22 This unit requires special wiring to mute the audio signal automatically when a cellular telephone rings in the car. * This function is not compatible with all cellular telephones. Contact your local authorized Clarion dealer for information on proper installation and compatibility. AUX function...
-
Page 23: Operations Of Accessories
2. To cancel disc scan play, press the [SCN] button again. Repeat play Repeat play continuously plays the current track. This function continues automatically until it is cancelled. 1. Press the [RPT] button. 2. To cancel repeat play, press the [RPT] button again. DFZ675MC... - Page 24 This function continues automatically until it is cancelled. 1. Press and hold the [RDM] button for 1 second or longer. 2. To cancel disc random play, press the [RDM] button again. DFZ675MC...
-
Page 25: Tv Operations
Manual memory 1. Select the desired station with seek tuning, manual tuning or preset tuning. 2. Press and hold one of [DIRECT] buttons for 2 seconds or longer to store the current station into preset memory. DFZ675MC... -
Page 26: Preset Scan
2 seconds or longer, otherwise the auto store function is engaged and the unit starts storing stations. Setting the TV diver Refer to the subsection “Setting the TV diver” (page 26) in the section “Adjust Mode”. DFZ675MC ] button for... -
Page 27: Ipod Operations
“Music” ➜ “Songs” from the menu of the iPod. 1. Press and hold the [BND] button for 1 second or longer. It changes to the ALL PLAY mode, and all the tracks stored in the iPod are played back sequentially. DFZ675MC... - Page 28 1. Press and hold the [RDM] button for 1 second or longer. 2. To cancel the All random playback, press the [RDM] button again. DFZ675MC Selecting tracks in the iPod MENU mode In the iPod mode, you can select tracks by the...
-
Page 29: Trouble Shooting
Press and hold the [RESET] button for 2 seconds or longer with a thin rod If the situation is not improved, contact your local authorized Clarion dealer Press and hold the [CDo] button for 3 seconds or longer The foreign matter is forcibly ejected... - Page 30 Erasing tracks like short length ones may not be able to increase the approximate recordable time DFZ675MC Cause Let dry for about 1 hour with the power on Use ISO9660 level 1, 2 or JOLIET or Romeo file system...
-
Page 31: Error Displays
This is a failure of DVD mechanism and consult your store of purchase Retry or replace with a non-scratched, non-warped-disc Eject the disc then reload it properly Set the correct Parental level Eject the disc and replace correct region code disc Measure DFZ675MC... -
Page 32: Specifications
STD: Approximately 497 minutes Approximately 663 minutes Notes: • Specifications and design are subject to change without notice for further improvement. DFZ675MC Audio Maximum Power Output: 200 W (50 W x 4 ch) Bass Control Action (50 Hz/80 Hz/120 Hz):... - Page 33 Clarion Co., Ltd. PE-2820B All Rights Reserved. Copyright © 2006: Clarion Co., Ltd. 280-8421-00 2006/6 Printed in China / Imprimé en China / Impreso en China...
