ATTACHMENT
OPERATOR'S
MANUAL
Triple Bag Grass Collector
1696462-00 Triple Bag Grass Collector for 46", 52" and 48" Fabricated Deck on Regent and NXT
1696462A-00 Triple Bag Grass Collector for 46", 52" and 48" Fabricated Deck on Regent and NXT
Note: 1696750 Turbo Kit or 1696672 Bagging Boot, Blade and Baffle Kit will be needed
Copyright © Briggs & Stratton Corporation
Milwaukee, WI, USA. All rights reserved.
for the 48" Fabricated Deck on a Regent.
and SPX Mowers
®
and SPX Mowers
®
1758438
Revision D
Advertisement
Related Manuals for Briggs & Stratton 1696462-00
Summary of Contents for Briggs & Stratton 1696462-00
- Page 1 OPERATOR’S MANUAL Triple Bag Grass Collector 1696462-00 Triple Bag Grass Collector for 46”, 52” and 48” Fabricated Deck on Regent and NXT and SPX Mowers ® 1696462A-00 Triple Bag Grass Collector for 46”, 52” and 48” Fabricated Deck on Regent and NXT and SPX...
-
Page 2: Table Of Contents
Manual Contents: Operator Safety Safety Alert Symbol and Signal Words Operator Safety ............2 The safety alert symbol is used to identify safety infor- Hardware and Parts Identification.......4 mation about hazards that can result in personal injury. A Assembly ..............5 signal word (DANGER, WARNING, or CAUTION) is used with the alert symbol to indicate the likelihood and potential Operation..............10 severity of injury. - Page 3 WARNING WARNING Thrown Objects Hazard Failure to read and follow the safety warnings and Do not open the cover while the blades are turning. instructions in this document and in the tractor operator’s • Check the collection system to make sure it is bolted manual could result in death, serious injury, and/or tightly to the unit.
-
Page 4: Hardware And Parts Identification
Hardware and Parts Identification • Upper case letters identify the hardware and parts in the kit. • Lower case letters identify the existing hardware and parts assembled before the start of the installation. - SPEED NUT - SHOULDER BOLT - UPRIGHT SUPPORT ASSEMBLY - BAFFLE, 46”... -
Page 5: Assembly
Assembly Install the Baffles For 46” Mower Decks WARNING 1. Put the deflector (a, Figure 3) in the vertical position. Disengage the electric clutch (PTO). Shut off the engine, 2. Put the baffle (D) into the discharge opening. Attach the remove the key, and wait for all moving parts to stop left side of the baffle with a carriage bolt (E), spacer (F) before attaching, adjusting, or disconnecting any part of... - Page 6 Install the Cover Support and Cover Assembly For 52” Mower Decks 1. Put the deflector (a, Figure 5) in the vertical position. 1. Attach the cross support (K, Figure 7) onto the hitch assembly (a) with the carriage bolts (L) and the whiz 2.
- Page 7 Install the Boot Mounting Hardware Frame Hung Mowers 1. Remove and discard the existing hardware from outside Note: It is not necessary to install the hardware onto the 48” of the right wheel bracket. mower deck. 2. On the inside of the deck, insert the carriage bolt (S, 46”...
- Page 8 Install the Bagging Boot Frame Hung Mowers 1. Rotate the latch (a, Figure 14) into the space between For 46” and 52” Mower Decks the spacer and the washer hardware (b). 1. Make sure the latch hardware on the bagging boot (X, Figure 12) is in the correct hole for the deck sizes.
- Page 9 2. Secure the hook (g, Figure 17) of the mounting strap 4. Slide the middle tube (Y, Figure 19) over the bagging onto the roller bar support bracket (h). boot (X). Attach the strap (c) over the pin (d). Figure 17 Assemble the Upper and Middle Tube Figure 19 For 46”...
-
Page 10: Operation
Operation WARNING When operating without the collector, the mower deflector WARNING MUST be installed in the down position and retained with the spring latch. Disengage the electric clutch (PTO). Shut off the engine, Remove the Collector remove the key, and wait for all moving parts to stop before attaching, adjusting, or disconnecting any part of For 46”, 52”... -
Page 11: Warranty
BRIGGS & STRATTON PRODUCTS WARRANTY POLICY LIMITED WARRANTY Briggs & Stratton warrants that, during the warranty period specified below, it will repair or replace, free of charge, any part that is defective in material or workmanship or both. Transportation charges on product submitted for repair or replacement under this warranty must be borne by purchaser. This warranty is effective for and is subject to the time periods and conditions stated below.
