  • Page 1 FortiCam FD50 QuickStart Guide...
  • Page 2 Fortinet. For absolute clarity, any such warranty will be limited to performance in the same ideal conditions as in Fortinet’s internal lab tests. Fortinet disclaims in full any covenants, representations, and guarantees pursuant hereto, whether express or implied.

  • Page 3: Table Of Contents

    Table of Contents Package Contents Hardware Installation Camera Connection Technical Specifications Register for Support Cautions and Warnings Regulatory Notices...

  • Page 4: Package Contents

    Package Contents • 1x FortiCam camera • 4x mounting screws and 4x anchors • 1x waterproof connector assembly • 1x spare dry pack • 1x alignment sticker Page 4...

  • Page 5: Hardware Installation

    Hardware Installation • Before installing surveillance cameras, design your system carefully and test the location and coverage of each camera by temporarily connecting the camera to the FortiRecorder NVR. Additionally, decide whether to run the cables through the wall/ceiling (drilling required) or along the wall/ceiling through the cable notch on the base.
  • Page 6 To install the camera Remove the dome cover by loosening the T10 anti-tamper screws. Use caution with the electronic parts. Open the MicroSD card socket lid by sliding it backwards. This step and step 3 are only required if onboard storage is preferred. Page 6...
  • Page 7 Insert a MicroSD card into the socket, close the lid, and then slide the lid until you hear a click. Place the alignment sticker on the wall or ceiling to drill mounting holes. Drill a cable routing hole larger than 25mm if desired. Page 7...
  • Page 8 Assemble the waterproof connector onto the Ethernet cable. Attach the camera to the wall or ceiling. Page 8...
  • Page 9 Adjust the 3-axis mechanism horizontally, vertically, and circularly to your desired angle. Replace the desiccant from the inside of the dome cover. Install the dome cover. Page 9...

  • Page 10: Camera Connection

    Go to the FortiRecorder web UI to configure the discovered camera. For details, see the FortiRecorder Administration Guide on http://docs.fortinet.com. To reset the camera to factory default Remove the top cover with an allen key to expose the Reset button (see the picture on page 6).

  • Page 11: Technical Specifications

    Technical Specifications Camera Format Fixed dome, day/night, indoor/outdoor, vandal Sensor Type 5 mega-pixel, 1/2.7” low light CMOS Iris F1.4 (W), F2.8 (T), fixed Focal Length f=2.8mm-12mm motorized View Angle H:90°-30°/V:65°-23°/D:115°-38° Minimum Illumination 0.035 Lux (color) @ F1.4 0.005 Lux (B/W) @ F1.4 Shutter WDR (>120dB) Network Interface RJ-45 Ethernet 10/100Mbps...
  • Page 12 Audio Two-way, built-in mic, line out Image Resolution 5MP at 20fps, 4:3, WDR off, or 4MP at 30fps +D1 at 30fps Mounting Wall, ceiling, 3-axis, accessories Dimensions Height x Width x 4.08 x 5.3 x 5.3in (104 x 133 x 133mm) Length Weight 1.80lbs (819g)

  • Page 13: Register For Support

    Register for Support Register your Fortinet product to receive: • Technical support • New product features • Protection from new threats Vous devez enregistrer le produit pour recevoir: • Support technique • Nouvelles fonctionnalitées du produit • Protection contre de nouvelles menaces La reistrazione ti permette di usufruire di: •...

  • Page 14: Cautions And Warnings

    Cautions and Warnings Environmental Specifications Refer to specific Product Model Data Sheet for Environmental Specifications (Operating Temperature, Storage Temperature, Humidity, and Altitude). Référez à la Fiche Technique de ce produit pour les caractéristiques environnementales (Température de fonctionnement, température de stockage, humidité et l’altitude). Safety Caution: This equipment is to be used in a Network Environment 0 per IECTR 62101.

  • Page 15: Regulatory Notices

    Regulatory Notices Federal Communication Commission (FCC) – USA This device complies with Part 15 of FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received; including interference that may cause undesired operation. This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules.
  • Page 16 (except as provided in section 5 (“Transfer”) and section 15 (“Open Source Software”) below), non-exclusive, revocable (in the event of your failure to comply with these terms or in the event Fortinet is not properly paid for the applicable Product) license to use the Software...
  • Page 17 If you are a Fortinet contracted and authorized reseller or distributor of Products, you may transfer (not rent or lease unless specifically agreed to in writing by Fortinet) the Software to one end user on a permanent basis, provided that: (i) you ensure that your customer and the end user receives a copy of...
  • Page 18 Fortinet’s functional specifications. Except as otherwise agreed by Fortinet in writing, the replacement Software is provided only to the original licensee, and is subject to the terms and conditions of the license granted by Fortinet for the Software. The Software War- ranty Period shall extend for an additional ninety (90) days after any replacement software is delivered.
  • Page 19 For any Open Source Software covered under the GPL, the source code is made available on this CD or download package. If any Open Source Software licenses require that Fortinet provide rights to use, copy or modify a Open Source Software program that are broader than the rights granted in this agreement, then such rights shall take precedence over the rights and re- strictions herein.
  • Page 20 To obtain a complete machine-readable copy, please send your written request, along with a check in the amount of US $25.00, to General Public License Source Code Request, Fortinet, Inc., 899 Kifer Rd, Sunnyvale, CA 94086 USA. In order to receive the modified software modules, you must also include the following information: (a) Name, (b) Address, (c) Telephone number, (d) E-mail Address, (e) Product purchased (if applicable), (f) Product Serial Number (if applicable).
  • Page 21 a) Accompany it with the complete corresponding machine-readable source code, which must be distributed under the terms of Sections1 and 2 above on a medium customarily used for software interchange; or, b) Accompany it with a written offer, valid for at least three years, to give any third party, for a charge no more than your cost of physically performing source distribution, a complete machine-readable copy of the corresponding source code, to be distributed under the terms of Sections 1 and 2 above on a medium customarily used for software interchange;...
  • Page 22 permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this. Our decision will be guided by the two goals of preserving the free status of all derivatives of our free software and of promoting the sharing and reuse of software generally.
  • Page 23 considered independent and separate works in themselves, then this License, and its terms, do not apply to those sections when you distribute them as separate works. But when you distribute the same sections as part of a whole which is a work based on the Library, the distribution of the whole must be on the terms of this License, whose permissions for other licensees extend to the entire whole, and thus to each and every part regardless of who wrote it.
  • Page 24 no more than the cost of performing this distribution. d) If distribution of the work is made by offering access to copy from a designated place, offer equivalent access to copy the above specified materials from the same place. e) Verify that the user has already received a copy of these materials or that you have already sent this user a copy. For an executable, the required form of the “work that uses the Library”...
  • Page 25 you may choose any version ever published by the Free Software Foundation. 14. If you wish to incorporate parts of the Library into other free programs whose distribution conditions are incompatible with these, write to the author to ask for permission. For software which is copyrighted by the Free Software Foundation, write to the Free Software Foundation; we sometimes make exceptions for this.
