Related Manuals for Fehom PDGT701BE
Summary of Contents for Fehom PDGT701BE
- Page 1 Commercial Dehumidifier Please read the manual carefully before using the unit PDGT701BE USER MANUAL www.fehom.com...
- Page 3 Thank you for purchasing our dehumidifier. Fehom wishes our products and services can bring convenience to your work and life. We highly recommend you to keep the manual for reference, in case you encounter unexpected issues using this unit. Please read the manual carefully to ensure proper use of the dehumidifier.
-
Page 4: Common Faults And Solutions
Common Faults and Solutions Warranty & Contact Information The graphics and functions provided in this manual may not be the same as the actual product. Please always refer to the actual product. The model of the machine on the manual is for reference only. Please operate the machine based on the actual product. - Page 5 Safety Notes: For your safety, please read the manual carefully and keep the manual before you use the product for reference. Please use this product according to the installation and operation instructions of this manual.
- Page 7 Understand the Control panel...
- Page 8 The humidity level can be set within a range of 10%RH to 98%RH in 1% increments. When it starts work, it will first automatically detect and show the room's humidity. Press the "UP" button to change the humidity selection in 1% increments.Press "DOWN"...
- Page 10 When the fan delays to start, running indicator will be flashing; it will RUNNING light up when the fan is running. 1. Digital number will be flashing when the target humidity is setting or the room humidity is lower than the set humidity. 2.
- Page 11 1.Turn off the dehumidifier and unplug it; 2. Find the gravity drain outlet at the bottom of the dehumidifier and connect the emergency hose to drain; 3.After emptying the reser- voir, close the gravity drain outlet; 4.Connect the pump drain hose;...
- Page 12 When one of above malfunctions occurs, the buzzer will alarm for a few seconds, press any key during the alarm to release the alarm sound. Fehom support@fehom.com...
- Page 13 1. Take out 4 screws and a handle from the accessories, and put the handle into the groove at the back of the humidifier, making the screws correspond to the screw holes. 2. Tighten all the four screws on the hands respectively, the installation is finished.
- Page 14 This dehumidifier has an internal pump that will automatically drain the condensate out via the long drain hose. Before turning on the dehumidifier, make sure the hose has been connected to the drain outlet properly. 1. Uncoil the entire hose; 2.
- Page 15 In power-disconnected status, tilt the dehumidifier as the figure shown, pull out the rubber plug and put the dehumifier straight to drain the sewage in the water tank. Rubber plug Inclination≥45°...
- Page 17 Check the information below for troubleshooting steps that will save you time to resolve issues that may happen with the unit. The list includes most issues but not the results of defective unit, crafts or materials in the unit. If all the troubleshooting steps have been exhausted and isse is stilling occuring, feel free to get in touch with Waykar Customer Service to get further assistance.
- Page 18 Clean the pump reservoir dirty If the dehumidifier is still not working properly as expected and the troubleshooting steps or solutions above may not resolve the issues, please unplug the power and shut down the dehumidifier, then contact Fehom customer service via support@fehom.com.
- Page 19 Please clean the filter every two weeks (do not use hot water above 104℉， gasoline or toluene).
- Page 20 MODEL NO. PDDT701BE P0WER SOURCE 120V 60Hz ～ RATED POWER(95°F,90%RH) 1150W 10.3A RATED CURRENT(95°F,90%RH) 50 Pints/Day MOISTURE REMOVAL(65°F,60%RH) MOISTURE REMOVAL(80℉,60%RH) 90 Pints/Day MOISTURE REMOVAL(86℉,80%RH) 150 Pints/Day 180 Pints/Day MOISTURE REMOVAL(95℉,90%RH) INPUT POWER(65°F,60%RH) 610W INPUT CURRENT( 65°F ,60%RH) 5.5A R410a(20.11oz.) (570g) REFRIGERANT 6.2MPa MAXIMUM ALLOWABLE PRESSURE...
- Page 21 Fehom offers a 12-month warranty to all of our products together with the original proof of purchase when a defect occured, including those newly purchased and unused, from Fehom or through an authorized reseller, wholly or substantially, or as a result of faulty manufacturing parts, or workmanship during the Warranty Period.
- Page 22 @Fehom @Fehom @Fehom For FAQs and more information please visit: w w w.fe h o m .c o m @Fehom （Scan the QR Code for Live Chat） We are expecting to see our products fulfill your life and hear your voice.
