- Page 1 Please read the manual carefully before using the unit PD11A USER MANUAL www.fehom.com...
-
Page 2: For Customers
To Access Customer Support Faster If there is any problem of the product, please contact Fehom Customer Service at support@fehom.com with your purchase Order ID to help us... -
Page 3: Before First Use
BEFORE FIRST USE: To prevent any internal damage, it is very important to keep refrigeration units (like this one) upright throughout their journey. Please leave it standing upright and outside the box for 24 HOURS before plugging it in. - Page 4 CATALOG Statement The graphics and functions provided in this manual may not be the same as the actual product. Please always refer to the actual product. The model of the machine on the manual is for reference only. Please operate the machine based on the actual product. The right to interpret the relevant terms belongs to the company.
-
Page 5: Precautions For Use
PRECAUTIONS FOR USE Safety notes: Please do not place the machine near heat or flammable dangerous goods. Do not insert your fingers or sticks into the air inlet or outlet. Always keep the machine on even surfaces, avoid placing the machine on uneven or sloping ground. -
Page 6: Parts Description
Parts Description Front Control Panel Air Outlet Water Tank Back Handle Air Intake Drain Hose Outlet - 2 -... -
Page 7: Control Interface
CONTROL INTERFACE 1. Control Panel DISPLAY PANEL LOCK SPEED TIMER POWER MODE DEHUMIDIFY HIGH DEHU CONT LOCK SPEED TIMER HUMI MODE POWER - 3 -... - Page 8 OPERATION INSTRUCTION 2.Setting Mode Setting There are Dry Clothes Mode, Dehumidify Mode, Continuous Dehumidify Mode. When Power On, press the [Mode] button, the device will cycle through the drying, dehumidifying, and continuous dehumidify modes. Each time you press the mode button, the working mode will switch accordingly.
- Page 9 OPERATION INSTRUCTION LOCK(2S) When the unite is turned on , press "LOCK" and hold for 2 seconds, the control panel will be locked together with the other buttons. To uncklock the control panel, press and hold the "LOCK" button again for 2 seconds. Speed Button Power Off Memory Function 1.The device automatically restores the working state after power on.
- Page 10 OPERATION INSTRUCTION Auto Defrost Function When the dehumidifier is running at a lower temperature, the system will automatically determine whether there is a presence of frost. If the machine determines there is a presence of a frost, it will defrost automatically. Defrost Action The fan runs at high wind speed when the compressor stops.
- Page 11 OPERATION INSTRUCTION 4. Instructions for Drying Clothes The dehumidifier can be used for drying clothes in rainy weather. Step 1. Hang the washed clothes in a small space such as cloakroom, bathroom, or storage room. Note: Keep away the unit from the water drip from the washed clothes. Step 2.
- Page 12 Error Code Humidity sensor error Defrost temperature sensor error Temperature sensor error Attention: Fehom Fehom Note: Before starting the machine, please ensure that the air outlet has been opened, otherwise the machine will overheat. Do not pull out the power cord directly to stop the machine.
- Page 13 OPERATION INSTRUCTION 6. Empty the Tank or Bucket There are two ways to remove collected water. Use the Bucket When the water tank is already full, the Full Tank Alert indicator will light up, the dehumidifier will automatically shut down until the tank has been emptied and placed back to the unit.
- Page 14 OPERATION INSTRUCTION Note: Do not remove the float from the water tank. If the float in the water tank is removed, the sensor may not be able to determine the water level stored in the tank properly that may lead to water overflow leak from the water tank. If the water tank is dirty, just use cold water or warm water to clean it.
-
Page 15: Continuous Drainage
OPERATION INSTRUCTION 7. Continuous Drainage Insert the water pipe into Open the drain cover the continuous drain port Continuous Drain Port... -
Page 16: Cleaning And Maintenance
CLEANING AND MAINTENANCE Turn the dehumidifier off and remove the plug from the wall outlet before cleaning. A- Cleaning the dehumidifier body Please use only a soft and a bit wet textile or cloth to clean it. B- Cleaning filter C-Dehumidifier storage When you want to store the dehumidifier because you don't use it for a long time. -
Page 17: Troubleshooting
TROUBLESHOOTING Fehom Problem Cause Solution Make sure that the unit's plug is inserted properly into the The power cord is unplugged. power outlet. Is the TankFull indicator Empty the water in the water blinking? (The tank is full or in tank and then reposition the a wrong position.) - Page 18 TROUBLESHOOTING There is prevent frequent Please wait for more than 3 start function in the machine. minutes. Dose the machine stop working just now? The dehumidifier is designed to work in the humidity rane of Room humidity is low. 30%-80%.Above or below the work humidity range, it will not work.
- Page 19 If the dehumifier is still not working properly as expected and the troubleshooting steps or solutions above may not resolve the issue. Please unplug the power and shut down the dehumidifier then contact Fehom customer service support@fehom.com - 15 -...
- Page 20 SAFETY NOTE When using, please do not put When using, please keep the machine away from heating the machine at the soft and uneven ground, avoid vibration furnace, electric kettle and other heat sources. and movement. If do not use the product for a Please do not put objects around When using, make sure doors long time, please unplug the...
- Page 21 Model PD11A Power Source 120V～60Hz Rated Power(95°F,90%RH) 350W Rated Current(95°F,90%RH) 3.2A 13.5 Pints/Day MOISTURE REMOVAL CAPACITY(65°F,60%RH) 22 Pints/Day MOISTURE REMOVAL (80°F,60%RH) 40 Pints/Day MOISTURE REMOVAL (86°F,80%RH) 50 Pints/Day Moisture Removal(95°F,90%RH) Input Power(65°F,60%RH) 200W Input Current(65°F,60%RH) 1.7A Noise Level(Low Fan) 43dB(A)
-
Page 22: Customer Support
Fehom offers a 12-month warranty to all of our products, newly purchased and unused, from Fehom or through an authorized reseller, together with the original proof of purchase when a defect occurred, wholly or substantially, or as a result of faulty manufacturing, parts or workmanship during the Warranty Period. - Page 24 @Fehom @Fehom For FAQs and more information please visit: @Fehom www.fehom.com @Fehom (Scan the QR Code for Live Chat) We would love to see our product being used and how it makes your day!! Your support means the world, Please tag us if you share a snap on your social media.
