Fisher & Paykel RS2484S Installation Manual
Integrated column, wine cabinet
Hide thumbs
Also See for RS2484S:
- Installation manual (64 pages) ,
- User manual (36 pages) ,
- Manual (65 pages)
Related Manuals for Fisher & Paykel RS2484S
Summary of Contents for Fisher & Paykel RS2484S
- Page 1 INTEGRATED COLUMN REFRIGERATOR & FREEZER RS2484S, RS2484SH, RS3084S, RS3084SH RS1884F, RS2484F & RS3084F REFRIGERATOR-FREEZER RS3084W & RS3084W WINE CABINET RS2484V INSTALLATION GUIDE US CA...
-
Page 3: Table Of Contents
CONTENTS Safety and warnings Appliance preparation Integrated refrigerator & freezer Door panel preparation — Stainless steel panel Integrated refrigerator-freezer Door panel preparation — Custom panel Integrated wine cabinet Door panel preparation — Wine cabinet only Supplied parts Power and water supply connection Required parts Install water filter Door panel kit... -
Page 4: Safety And Warnings
SAFETY AND WARNINGS READ AND SAVE THIS GUIDE WARNING! Electric Shock Hazard WARNING! To avoid hazard, follow these instructions carefully before Installing or using this appliance. Failure to follow this advice may result in Please make this information available to the persons installing the appliance. electrical shock or death. -
Page 5: Integrated Refrigerator & Freezer
SAFETY AND WARNINGS INTEGRATED REFRIGERATOR & FREEZER INSTALLATION The anti-tip bracket and fittings supplied must be fitted to the wall of the finished enclosure to withstand a 220lbs (100kg) load. Ensure that the anti-tip bracket is installed correctly to prevent the possibility of the appliance tipping forward when the door is open. -
Page 6: Integrated Refrigerator-Freezer
INTEGRATED REFRIGERATOR-FREEZER INTEGRATED WINE CABINET 24" Wine Cabinet 24" Refrigerator-Freezer RS2484VL2K1 & RS2484VR2K1 RS2484WLU1, RS2484WLUK1, RS2484WRU1 & RS2484WRUK1 30" Refrigerator-Freezer RS3084WLU1, RS3084WLUK1, RS3084WRU1 & RS3084WRUK1 Left or Right hinged door available for each model. -
Page 7: Supplied Parts
SUPPLIED PARTS INSTALLATION KIT (INTERNAL BOX) TRIMS INSTALL KIT (EXTERNAL BOX) Door panel attachment kit Refrigerator or Freezer Side bracket (7x) Bracket slider (7x) Side spacer M5x12 Cross-head Cabinet side trim (2x) Door panel side cover (2x) bracket (7x) screw (35x) Anti-tip bracket assembly #8 x 16 Wine Cabinet... -
Page 8: Required Parts
INTEGRATED COLUMN REFRIGERATOR & FREEZER stainless steel door panel. REFRIGERATOR & FREEZER INTEGRATED REFRIGERATOR RS2484S, RS2484SH, RS3084S, RS3084SH RS2484S, RS2484SH, RS3084SH & RS3084S RS1884F, RS2484F & RS3084F SERVICE & WARRANTY INTEGRATED FREEZER REFRIGERATOR-FREEZER SERVICE ET GARANTIE RS1884F, RS2484F & RS3084F RS3084W &... -
Page 9: Door Panel Kit
DOOR PANEL KIT REFRIGERATOR OR FREEZER REFRIGERATOR-FREEZER WINE CABINET Stainless steel door panel kit Stainless steel door panel kit Stainless steel door panel kit RS18 RD1884R4D RD1884L4D RS24 RD2484WRD RD2484WLD RS24 RD2484VR4 RD2484VL4 RS24 RD2484R4D RD2484L4D RS30 RD3084WRD RD3084WLD RS30 RD3084R4D RD3084L4D 8Gx16 Mush washer screw (32x) -
Page 10: Handle Kit
HANDLE KIT CONTEMPORARY PROFESSIONAL Aluminium/Black square handle set Stainless steel square handle set MODEL CODES MODEL CODES REFRIGERATOR/FREEZER AHD3-RD84 REFRIGERATOR/FREEZER AHV2-RD84 WINE CABINET WINE CABINET 24" REFRIGERATOR-FREEZER AHD3-RD2484W 24" REFRIGERATOR-FREEZER AHV2-RD2484W 30" REFRIGERATOR-FREEZER AHD3-RD3084W 30" REFRIGERATOR-FREEZER AHV2-RD3084W Square handle (1x) M5x25 Hex screw (4x) Square handle (1x) M5x25 Hex screw (4x) -
Page 11: Hinge Change Kit
HINGE CHANGE KIT WINE DISPLAY ACCESSORIES Not supplied and must be purchased separately through an authorised Fisher and Paykel dealer. Accessories are not supplied with the appliance. A wine display kit and a label kit are sold Visit fisherpaykel.com for more information. Select among the hinge change kit options below: separately and can be purchased online at fisherpaykel.com. -
Page 12: Tools
TOOLS Required tools Supplied tools Not supplied and must be provided by the installer. Powered driver Flathead screwdriver Ruler M4 hex key Spanner Cross-head Cutter (1) T20 star-head screwdriver screwdriver (Used for changing hinge) 1/2" (13mm) socket Hacksaw Hand truck wrench (For cutting air flow divider to length) -
Page 13: Product Dimensions
PRODUCT DIMENSIONS REFRIGERATOR OR FREEZER REFRIGERATOR-FREEZER WINE CABINET FRONT PROFILE FRONT PROFILE FRONT PROFILE 18" 24" 30" PRODUCT DIMENSIONS Overall height 2134 2134 2134 Overall width 17 3/4 23 3/4 29 3/4 Overall depth (excluding door panel) Depth of toe kick (measured from back of door panel) 2 7/8 – 4 73 – 102 2 7/8 – 4... -
Page 14: Cabinetry Dimensions - Single Installation
CABINETRY DIMENSIONS — SINGLE INSTALLATION Flush with front of cabinetry PLAN UNFRAMED FRAMED Aligns appliance with cabinetry Aligns appliance with frame of cabinetry ISOMETRIC 18" 24" 30" CAVITY DIMENSIONS Overall height of cavity 2134 2134 2134 Overall width of cavity Minimum overall depth of cavity* Minimum gap from edge of door panel to cabinetry Minimum required finished return... -
Page 15: Cabinetry Dimensions - Multiple Installation
CABINETRY DIMENSIONS — MULTIPLE INSTALLATION DUAL INSTALL TRIPLE INSTALL DUAL INSTALL 42" 48" 54" 60" CAVITY DIMENSIONS 2134 2134 2134 2134 Overall height of cavity 1067 1220 1372 1524 Overall width of cavity Minimum overall depth of cavity* TRIPLE INSTALL 66"... -
Page 16: Stainless Steel Door Panel Dimensions - Single Installation
STAINLESS STEEL DOOR PANEL DIMENSIONS — SINGLE INSTALLATION REFRIGERATOR OR FREEZER / WINE CABINET REFRIGERATOR-FREEZER 18" 24" 30" 24" 30" DOOR PANEL DIMENSIONS DOOR PANEL DIMENSIONS Height of door panel 79 7/8 2029 79 7/8 2029 79 7/8 2029 Height of top door panel 49 3/8 1254 49 3/8... -
Page 17: Custom Door Panel Dimensions - Single Installation
CUSTOM DOOR PANEL DIMENSIONS — SINGLE INSTALLATION REFRIGERATOR OR FREEZER / WINE CABINET REFRIGERATOR-FREEZER 18" 24" 30" 24" 30" DOOR PANEL DIMENSIONS DOOR PANEL DIMENSIONS 77 7/8 1978 77 7/8 1978 77 7/8 1978 Height of top door panel 49 3/8 1254 49 3/8 1254... -
Page 18: Custom Door Panel Dimensions - Multiple Installation
CUSTOM DOOR PANEL DIMENSIONS — MULTIPLE INSTALLATION DUAL INSTALL TRIPLE INSTALL The illustrations below are examples of custom door panels of different combinations for dual The illustrations below are examples of custom door panels of different combinations for triple installation. Minimum gaps of 1/8" (3mm) must be retained between door panel side edges and installation. -
Page 19: Toe Kick Dimensions
TOE KICK DIMENSIONS Custom toe kick options 2 7/8” (73mm) – 4” (102mm) 2” (51mm) toe kick height (with extra lower grille attached) toe kick clearance measured from rear of door panel SINGLE INSTALL DUAL INSTALL TRIPLE INSTALL 6” (152mm) toe kick height 4”... -
Page 20: Installation Options
INSTALLATION OPTIONS SINGLE INSTALL MULTIPLE INSTALL WALL WALL WALL WALL WALL WALL 4" (100mm) WALL WALL WALL WALL WALL WALL 2 3/8" (60mm) WALL WALL WALL WALL WALL WALL The illustrations above show acceptable installation options with reference to the door opening range and partition (optional). Be aware of clashing (circled) of doors or handles when opening at the same time. If installing a partition between the appliances, ensure there is enough clearance to avoid doors/handles from interfering with each other when opening or closing. -
Page 21: Door Clearance
DOOR CLEARANCE DRAWER CLEARANCE These dimensions apply to Refrigerator-Freezer models only. Wall LIMITED INTERNAL ACCESS FULL INTERNAL ACCESS Insert hinge limiting pin Before pushing the appliance into the cabinetry, insert the supplied hinge limiting pin into the borehole of the top and bottom/middle door hinges. -
Page 22: Electrical And Plumbing
ELECTRICAL AND PLUMBING Electrical connection must be within this space if located behind the appliance and must not protrude from the back wall. Recommended locations for connection at rear of cabinetry 18" 24" 30" SUPPLY AREA DIMENSIONS POWER CORD Overall height of supply area Total length exiting from left side 54 1/2 1385... -
Page 23: Custom Door Panel Install Dimensions
CUSTOM DOOR PANEL INSTALL DIMENSIONS Dimensions apply for the preparation and installation of Custom door panels. For Dwg and Dxf files of the below panel preparation, download the folder from http://thekitchentools.fisherpaykel.com. The thickness of the custom door panel can vary provided that the screws do not penetrate beyond the full depth of the door panel. 8 7/8”... - Page 24 CUSTOM DOOR PANEL INSTALL DIMENSIONS 14 7/8” (378mm) 11 7/8” (302mm) 8” (203mm) 8” (203mm) 2” (51mm) 2” (51mm) Ø1/16” (Ø2mm) REF Ø1/16” (Ø2mm) REF 22x Pilot holes recommended 22x Pilot holes recommended for bracket attachment. for bracket attachment. (Do not penetrate front surface). (Do not penetrate front surface).
- Page 25 CUSTOM DOOR PANEL INSTALL DIMENSIONS For Wine cabinet, the Custom door panel must leave the glass pane visible. A full custom panel sheathing over the glass pane does not meet the specifications of this appliance. 11 7/8” (302mm) 8” (203mm) 2” (51mm) Ø1/16”...
- Page 26 CUSTOM DOOR PANEL INSTALL DIMENSIONS Dimensions apply for the preparation and installation of Custom door panels. For Dwg and Dxf files of the below panel preparation download the folder on thekitchentools.fisherpaykel.com. The thickness of the custom door panel can vary provided that the screws do not penetrate beyond the full depth of the door panel. 11 7/8"...
- Page 27 CUSTOM DOOR PANEL INSTALL DIMENSIONS Dimensions apply for the preparation and installation of Custom door panels. For Dwg and Dxf files of the below panel preparation download the folder on thekitchentools.fisherpaykel.com. The thickness of the custom door panel can vary provided that the screws do not penetrate beyond the full depth of the door panel. 14 7/8"...
-
Page 28: Before Installation
BEFORE INSTALLATION Checking your cabinetry Check the dimensions of the cabinetry: height, width, depth, floor level, finished alcove returns. Refer to 'Cavity Dimensions' for the correct measurements. Check the power supply and water connections Ensure that there is a separate power socket for each appliance. Avoid sharing the power point with other appliances to prevent accidental switching off of the appliance. - Page 29 BEFORE INSTALLATION Removing pre-installed parts Moving your appliance Be careful when tilting the appliance forward/backward. Tape the door shut to prevent opening while moving the appliance. You need at least two persons to move this appliance. Top trim Disengage one end of the top trim from dual lock strips on the non-hinge side of the appliance.
-
Page 30: Cavity Preparation
CAVITY PREPARATION Anti-tip bracket Attaching the anti-tip bracket assembly kit For solid wall installation back wall Drill holes suitable to the size of the masonry plugs. Hammer 10x30mm masonry plugs into wall until flush. Fix bracket to wall with Anti-tip bracket (1x) overhead #10x40mm cross head screws, and screw cabinetry... -
Page 31: Appliance Preparation
APPLIANCE PREPARATION Removing the hanging brackets Tools M8 hex key M8 washer M8 nut Loosen the M8 screws by 1/8" (3mm). 1/2" (13mm) spanner Remove the M8 nut and M8 washer from the M8 screw at 1/2" (13mm) socket the top of the door using the wrench M8 screw supplied hex key and spanner. - Page 32 APPLIANCE PREPARATION Install fasteners Attaching the barbed plugs Before rolling into the cavity, insert a barbed plug into the large holes at the top right and left sides of the appliance. Barbed plugs (2x) Cabinet depth The plugs protect the inside surface of cabinetry from alignment gauge being damaged by screws when pushing in the appliance.
-
Page 33: Door Panel Preparation - Stainless Steel Panel
DOOR PANEL PREPARATION — STAINLESS STEEL PANEL Door handle kit Attaching the handle Attaching the brackets Remove the protective film around the handle attachment area before installing the handle. Protect the finish of the door panel to avoid damage or scratches to the surface. -
Page 34: Door Panel Preparation - Custom Panel
DOOR PANEL PREPARATION — CUSTOM PANEL Door handle kit Attaching the handle Attaching the brackets Refer to 'Custom door panel installation dimensions' page for correct screw hole Refer to 'Custom door panel installation dimensions' page for correct screw hole positions on the door panel. positions on the door panel. -
Page 35: Door Panel Preparation - Wine Cabinet Only
DOOR PANEL PREPARATION — WINE CABINET ONLY Attaching the long glass trims Installation kit Glass trims are attached to cover the gap between the door panel and glass panel. hanging bracket Do not exceed pass this line Long trim (2x) long trim long trim Attach the peeled portion of the trim... - Page 36 DOOR PANEL PREPARATION — WINE CABINET ONLY Attaching the short glass trims Installation kit Attach the peeled portion Place the short trim along the starting from one end of flange length of the top of door panel perpendicular to top end of Short trim (2x) cutout across the top ends of the short trim...
-
Page 37: Power And Water Supply Connection
POWER AND WATER SUPPLY CONNECTION Water fittings kit Connecting to water supply Ensure the door of the appliance is closed before rolling into the cabinetry. Push the appliance carefully towards the front of the cabinetry close enough to allow access at the back for power and water connection. Ensure an isolating tap is available if water supply is not easily accessible. Connect one end of a braided water braided hose Collet locking... -
Page 38: Install Water Filter
INSTALL WATER FILTER Freezer and Refrigerator with Ice & Water function Refrigerator-Freezer Keep the door closed and ensure the Keep the door closed and ensure the appliance is stable before installing the appliance is stable before installing the water filter to avoid risk of appliance water filter to avoid risk of appliance tipping over. -
Page 39: Single Installation - Align Appliance Into Cabinetry
SINGLE INSTALLATION — ALIGN APPLIANCE INTO CABINETRY Pushing into the cabinetry Tools Cross-head screwdriver Roll the appliance carefully into the cabinetry until the anti-tip bracket overlaps the 7 1/16" (180mm) back edge of the appliance. Ensure the bracket overlaps the appliance by a minimum 7 1/16" (180mm) for a secure hold. - Page 40 SINGLE INSTALLATION — ALIGN APPLIANCE INTO CABINETRY Tools Adjusting the alignment in the cabinetry Cross-head screwdriver Powered driver (optional) Clockwise turn of the front and rear adjustment screws raise the height of the appliance. Front foot Rear foot adjustment adjustment Counter-clockwise turn of the adjustment screws lower the height of screw screw...
-
Page 41: Single Installation - Secure Appliance Into Cabinetry
SINGLE INSTALLATION — SECURE APPLIANCE INTO CABINETRY Install fasteners Securing the top brackets 8Gx16 Countersunk screw (6x) Fix the top brackets to the ceiling surface of the cabinetry with 8Gx16 countersunk screws. Tools Cross-head screwdriver Powered driver (optional) Securing the side brackets Fix the side brackets (2x) to the lower right and left sides of the cabinetry with 8Gx16 countersunk screws. -
Page 42: Door Panel Installation
DOOR PANEL INSTALLATION Tools Hanging the door panel Cross-head screwdriver M4 hex key (1x) Hold the door panel at an angle from Screw the M8 washer and nut to the the top of the door and lower the screw adjustment screw and loosely tighten. holes of the hanging bracket onto the 1/2"... - Page 43 DOOR PANEL INSTALLATION Tools Adjusting the height of door the panel Re-adjusing the door panel Ensure the side brackets are loosely screwed when adjusting the height of the door panel. Do not adjust the door panel height when the side brackets are screwed tight.
-
Page 44: Toe Kick Installation
DOOR PANEL INSTALLATION TOE KICK INSTALLATION Installing locking bracket Adjusting mounting plate brackets Tools Cross-head screwdriver Cutter M4 hex key (1x) REFRIGERATOR—FREEZER REFRIGERATOR OR FREEZER / WINE CABINET Loosen the screw at the bottom Loosen the cap screws of the 13mm spanner (1x) of the door, and slide the locking adjustment brackets on both... - Page 45 TOE KICK INSTALLATION Miscellaneous Attaching the mounting plate components mounting plate Re-attach the toe kick mounting plate to the plinth using same screws that were set aside previously. Air toe kick seal (1x) Toe kick install kit air toe kick seal If toe kick depth is less than 3 5/8"...
-
Page 46: Grilles Installation
GRILLES INSTALLATION Tools Attaching the top grille Cutter Refrigerator or Freezer/ Refrigerator-Freezer Wine Cabinet Reattach the top grille with Open the door, and secure #8x16 screws. both ends of the grille and behind the water filter hatch with #8x16 screws. top grille top grille Cross-head... -
Page 47: Carbon Filter Installation
CARBON FILTER INSTALLATION AIR FLOW DIVIDER INSTALLATION The carbon filter is used for Wine Cabinet models only. Ensure the cover is completely closed The air flow divider blocks the air flow from bypassing the front of the bottom grille. to prevent hatch or filter from being damaged. Replacement filters (862755) can be purchased online from fisherpaykel.com or by calling Fisher &... -
Page 48: Cabinet Trims Installation
CABINET TRIMS INSTALLATION Trims install kit Installing cabinet side trims door hinge Dual adhesive strips are pre-attached at adhesive strip trim four locations along the side trims. Ensure the adhesive strips are pressed firmly to the cabinet side trims. Cabinet side trim (2x) Peel off the liners from the dual adhesive Position the trim at an angle on strips. - Page 49 DOOR COVERS & TRIMS INSTALLATION Re-installing the top cover (for all models) Trims install kit Remove the backing film of dual adhesive strips pre-attached to the top of the door. Ensure the magnet is in place before installing the top cover. trim cap top cover Door panel side...
-
Page 50: Top Trim & Hinge Pocket Covers Installation
TOP TRIM & HINGE POCKET COVERS INSTALLATION installing the top trim (for all models) Slide one end of the top trim into the hinge pocket of the appliance. Press the other end to engage the dual lock strips on the non-hinge side of the appliance. top trim installing the hinge pocket covers (for all models) Follow the steps below to install the covers for the top, bottom or middle hinge pockets. -
Page 51: Multiple Installation - Appliance Preparation
MULTIPLE INSTALLATION — APPLIANCE PREPARATION Install fasteners Attaching the central spacer to cabinetry Attaching barbed plugs and depth alignment gauges barbed plugs Barbed plugs (2) depth gauges locations Before rolling into the cavity, insert the barbed plugs into large holes on the top right and left sides of both Cabinet depth appliances. -
Page 52: Multiple Installation - Align First Appliance Into Cabinetry
MULTIPLE INSTALLATION — ALIGN FIRST APPLIANCE INTO CABINETRY Pushing first appliance into the cabinetry Tools min 7 1/16" (180mm) Ruler Roll the first appliance slowly into one side of the cabinetry until the anti-tip bracket overlaps the back edge of the appliance. Ensure the bracket overlaps the appliance by a minimum 7 1/16"... -
Page 53: Multiple Installation - Secure First Appliance Into Cabinetry
MULTIPLE INSTALLATION — SECURE FIRST APPLIANCE INTO CABINETRY Install fasteners kit Adjusting alignment of first appliance in cabinetry Securing the top brackets 8Gx16 Countersunk screw (6) Turn the front and rear adjustment screws clockwise to raise height of the appliance and counter-clockwise to lower the Rear foot Front foot... -
Page 54: Multiple Installation - Align Second Appliance Into Cabinetry
MULTIPLE INSTALLATION — ALIGN SECOND APPLIANCE INTO CABINETRY Pushing into the cabinetry Tools Push the second appliance to roll slowly into the min 7 1/16" (180mm) Ruler other side of the cabinetry side by side with the first appliance. Ensure the bracket overlaps the appliance by a minimum 7 1/16"... -
Page 55: Multiple Installation - Secure Second Appliance Into Cabinetry
MULTIPLE INSTALLATION — SECURE SECOND APPLIANCE INTO CABINETRY Top joiner Securing the top brackets fastener kit cap screw M5x20 Cap screw (1) washer M5x16x1 Plain washer Secure the top caps of both appliances to the central spacer with M5x20 cap screw and washer. Bottom joiner Secure the top brackets to the ceiling surface of the fastener kit... -
Page 56: Multiple Installation - Install Cabinet Trims
MULTIPLE INSTALLATION — INSTALL CABINET TRIMS Installing the center trim Tools The center trim is installed after the top trims and grilles to the appliances. Aluminium center trim (1x) Push and press the trim on Four dual adhesive strips the appliances/throat. are pre-attached along the Make sure the top end of the center trim. -
Page 57: Wine Display For Wine Cabinet (Optional)
WINE DISPLAY FOR WINE CABINET (OPTIONAL) Handle assembly Cradle assembly Retainer blocks are pre-assembled at the bottom of both ends of the handle. A retainer block is pre-assembled at the bottom of each cradle. Use a spacer to correctly position the cradle and avoid wine bottles being too upright resulting in bottles tipping over. Loosen the screws until the Insert retainer block at desired retainer blocks can be inserted... -
Page 58: Change The Door Hinges (Optional)
CHANGE THE DOOR HINGES (OPTIONAL) You have the option to switch the door hinge side of your appliance from right hand hinge to left hand hinge or vice versa. A hinge change kit is required for this installation, and must be purchased separately. - Page 59 CHANGE THE DOOR HINGES (OPTIONAL) Detaching the top door hinge 1 Rotate the top hinge (A) outwards and remove the top hinge pocket cover (B) using the flat head screwdriver in the slot of the cover. 2 Unscrew M6x16 countersunk screws (C) to remove top hinge, and set aside to use later.
- Page 60 CHANGE THE DOOR HINGES (OPTIONAL) Moving the sensor housing Move the sensor housing Reinstall the sensor housing Unclip the hall sensor to align the opposite hall using #8x16 screws (2x) from the housing. sensor clip with the centre into the pre-drilled holes in of the cabinet.
- Page 61 CHANGE THE DOOR HINGES (OPTIONAL) Re-attaching the top door hinge 1 Reinstall the hinge top bracket and bracket spacer with M5x12 countersunk screws (A) on the new hinge side at the other side of the appliance. 2 Install the new hinge pocket and alcove top bracket on the new hinge side using two (2x) M6x16 countersunk screws (B).
- Page 62 CHANGE THE DOOR HINGES (OPTIONAL) Changing the top door brackets Reinstalling the door 1 Unscrew the M5x10 screws (4x) to remove the top adapter bracket from M6x10 hex screws the top of the door (A). 1 Secure the door to the top hinge and Top hinge 2 Install the new top adapter bracket into bottom/middle hinge with M6x10...
-
Page 63: Final Checklist
FINAL CHECKLIST TO BE COMPLETED BY THE INSTALLER ALL MODELS Door opening sensor: Ensure the magnets at door are in place so door opening sensor Cabinet Level: Ensure the appliance is level and dimensions accurate. works properly. Refer to 'Install trims', page 47. Refer to 'Cabinetry Dimensions, pages 14-15'. - Page 64 FISHERPAYKEL.COM © Fisher & Paykel Appliances 2020. All rights reserved. The models shown in this guide may not be available in all markets and are subject to change at any time. The product specifications in this guide apply to the specific products and models described at the date of issue.
