Select Readouts
Default Sonar View
To Select Readouts:
1. Make sure you are in Advanced User Mode, then highlight Select Readouts on the Setup
main menu.
2. Use the RIGHT 4-WAY Cursor Control key to initiate this procedure.
3. The Select Readouts submenu will appear, showing a list of all Readouts. Use the UP or
DOWN Cursor keys to select a particular Readout position, then use the RIGHT or LEFT
Cursor keys to change what will be displayed at that position. (Heading, Navigation,
Position, Off, Speed, Temperature, Time+Date, Triplog, Voltage)
Select Readouts
(Advanced, Sonar View Only)
Select Readouts sets individual digital readouts on the Sonar
View. This Advanced feature allows you to select what data will
be displayed in each of 6 fixed-position data windows arranged
around the left and bottom edges of the Sonar View screen, or
whether a particular window will be turned off, displaying
nothing in that area; you can access this menu choice only when
in Advanced User Mode (see Setup Menu Tab: User Mode.)
Data windows can display readouts from supported accessories
such as Temp/Speed. Each data window can either be empty or
contain one of the following:
• Heading
• Navigation
• Position
• Speed
• Temperature
• Time + Date
• Triplog
• Voltage.
Customized Sonar View
69
