- Page 1 HOSHIZAKI CRESCENT CUBER KM-101BAH MODEL PARTS LIST...
-
Page 2: Material Abbreviations
MATERIAL ABBREVIATIONS ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitritrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene... - Page 3 FASTENER ABBREVIATION LIST Phillips Truss Head Machine Screw Phillips Pan Head Machine Screw Phillips Flat Head Machine Screw Phillips Pan Head Machine Screw with Split Lock Washer Phillips Pan Head Machine Screw with Split Lock Washer and Flat Washer Phillips Truss Head Tapping Screw (Correspond to Type A) Phillips Truss Head Tapping Screw (Correspond to Type B) Phillips Truss Head Tapping Screw (Correspond to Type C) Phillips Truss Head Tapping Screw (Special)
- Page 5 : KM-101BAH MODEL INDEX DESCRIPTION ICE MAKING MECHANISM ASSY MECHANICAL BIN SWITCH WATER CIRCUIT ASSY REFRIGERATION CIRCUIT CONTROL BOX ASSY LABEL LOCATION ACCESSORIES BODY ASSY FRONT FRAME RAIL (L) RAIL (R) AIR GUARD GROMMET-PIPE (C) GROMMET-PIPE (B) GROMMET-PIPE (A) FRONT PANEL...
- Page 6 : KM-101BAH MODEL : A. ICE CUBER ASSY TITLE REQ'D NUMBER INDEX MATERIAL OR PART DESCRIPTION MODEL NUMBER NUMBER S-1,S-2S-3,T-0 T-1 GUIDE - DRAIN 4Y0191-01...
- Page 8 : KM-101BAH MODEL INDEX DESCRIPTION WATER TANK FLOAT SWITCH PUMP MOTOR ELBOW CUBE GUIDE (A) CUBE GUIDE (B) BRACKET - ICE MAKING INSULATION - MECHANISM (A) INSULATION - MECHANISM (B) SOLENOID VALVE WATER SUPPLY PIPE (A) ELBOW BYPASS PIPE WATER SUPPLY PIPE (B)
- Page 9 : KM-101BAH MODEL INDEX DESCRIPTION INSULATION/MECHANISM (D) PIPE/OVERFLOW SILICONE HOSE INSULATION - PUMP : B. ICE MAKING MECHANISM ASSY TITLE MATERIAL OR PART MODEL NUMBER NUMBER S-1,S-2S-3,T-0 T-1 3Y2433Z01 369038P02 H11418150 L=150 14 DIA x 18 DIA (CLEAR) 472395Z01 REQ'D NUMBER...
- Page 11 : KM-101BAH MODEL INDEX DESCRIPTION MECHANICAL SWITCH CASE DETECTOR : C. MECHANICAL BIN SWITCH TITLE MATERIAL OR PART MODEL NUMBER NUMBER S-1,S-2S-3,T-0 T-1 369019G01 371153G01 369020G01 371152G01 REQ'D NUMBER...
- Page 13 : KM-101BAH MODEL INDEX DESCRIPTION WATER SUPPLY PIPE WATER VALVE RUBBER GASKET SOLENOID VALVE DRAIN HOSE HOSE - VALVE DRAIN FITTING CABLE TIE INSULATION/DRAIN HOSE CLAMP HOSE CLAMP : D. WATER CIRCUIT ASSY TITLE MATERIAL OR PART MODEL NUMBER NUMBER...
- Page 15 : KM-101BAH MODEL INDEX DESCRIPTION BASE COMPRESSOR RUBBER GROMMET BOLT CONDENSER SHROUD BRACKET - FM FAN MOTOR FAN BLADE COPPER TUBE - H-1 COPPER TUBE - H-2 COPPER TUBE - H-4 INSULATION - CAPILLARY GROMMET SLEEVE STRAINER COPPER TUBE - H-3...
- Page 16 : KM-101BAH MODEL INDEX DESCRIPTION CABLE TIE ACCUMULATOR ACCUMULATOR COVER DRIER PUSH MOUNT TIE HEAT EXCHANGER COPPER TUBE - PROCESS(A) SEPARATOR CABLE TIE STARTING RELAY MOTOR PROTECTOR PROTECTOR COVER CLAMP CLIP INSULATION TUBE : E. REFRIGERATION CIRCUIT TITLE MATERIAL OR...
- Page 18 : KM-101BAH MODEL INDEX DESCRIPTION CONTROL BOX TOGGLE SWITCH FUSE HOLDER POWER RELAY TRANSFORMER CONTROLLER BOARD START CAPACITOR CABLE TIE FUSE : F. CONTROL BOX ASSY TITLE MATERIAL OR PART MODEL NUMBER NUMBER S-1,S-2S-3,T-0 T-1 117624-01 KND-203 P00033-01 BF115 P00014-01...
- Page 20 : KM-101BAH MODEL INDEX DESCRIPTION LOGO LABEL - PENGUIN CONTROL LABEL WIRING LABEL CAUTION LABEL LABEL - R134a LABEL - FUSE MAINTENANCE LABEL LABEL - AIR FILTER CAUTION LABEL - SERVICE LABEL - ALARM LABEL /CONTROL BOARD : G. LABEL LOCATION...
- Page 22 : KM-101BAH MODEL INDEX DESCRIPTION SCOOP INSTRUCTION MANUAL WARRANTY CERTIFICATE REGISTRATION CARD JOINT PIPE INLET HOSE INSTALLATION SHEET - DRAIN PUMP : K. ACCESSORIES TITLE MATERIAL OR PART MODEL NUMBER NUMBER S-1,S-2S-3,T-0 T-1 2H0361-01 4A2525-01 L1M006100 2A4016-01 2A2894-01 472483P01 472482R01...
