Page 40: No Ice Production
2. NO ICE PRODUCTION PROBLEM POSSIBLE CAUSE REMEDY [1] The icemaker a) Power Supply 1. OFF position. 1. Move to ON position. will not start. 2. Loose connections. 2. Tighten. 3. Bad contacts. 3. Check for continuity and replace. 4. Voltage too high. 4. - Page 41 PROBLEM POSSIBLE CAUSE REMEDY [2] Water a) Float Switch 1. Connector 1. Reconnect. continues to disconnected. be supplied, 2. Leads opened or 2. Check and replace. and the defective switch. icemaker will 3. Float does not move 3. Clean or replace. not start.
- Page 42 PROBLEM POSSIBLE CAUSE REMEDY [5] No water a) Water Supply Line 1. Water pressure too low 1. Check and get comes from and water level in Water recommended pressure. Spray Tubes. Tank too low. Water Pump b) Inlet Water Valve 1.
-
Page 43: Evaporator Is Frozen Up
3. EVAPORATOR IS FROZEN UP PROBLEM POSSIBLE CAUSE REMEDY [1] Freeze cycle a) Float Switch 1. Leads shorted or 1. Check and replace. time is too defective switch. long. 2. Float does not move 2. Clean or replace. freely. b) Inlet Water Valve 1. -
Page 44: Low Ice Production
4. LOW ICE PRODUCTION PROBLEM POSSIBLE CAUSE REMEDY [1] Freeze cycle a) See chart 2 - [3] and check dirty Air Filter or Condenser, ambient or water time is long. temperature, water pressure, Condenser Water Regulating Valve (KM-151BWH) and refrigerant charge. b) See chart 3 - [1] and check Float Switch, Inlet Water Valve, and Control Board. - Page 45 6. OTHER PROBLEM POSSIBLE CAUSE REMEDY [1] Icemaker will a) Bin Control Switch 1. Completely 1. Place in position. not stop when disconnected and bin is filled with dropped inside bin. ice. 2. Detector broken. 2. Replace. 3. Detector out of position. 3.
