Hoshizaki AM-50BAE Parts List

Self-contained cuber
Hide thumbs Also See for AM-50BAE:
Table of Contents

Advertisement

Quick Links

See also: Service Manual , Instruction Manual
Hoshizaki
Hoshizaki America, Inc.
"A Superior Degree
of Reliability"
www.hoshizaki.com
Self-Contained Cuber
Models
AM-50BAE
AM-50BAE-DS
AM-50BAE-AD
AM-50BAE-ADDS
PARTS LIST
Number: 71211
Issued: 9-23-2002
Revised: 1-25-2007

Advertisement

Table of Contents
loading

Related Manuals for Hoshizaki AM-50BAE

Summary of Contents for Hoshizaki AM-50BAE

  • Page 1 Hoshizaki America, Inc. “A Superior Degree of Reliability” www.hoshizaki.com Self-Contained Cuber Models AM-50BAE AM-50BAE-DS AM-50BAE-AD AM-50BAE-ADDS PARTS LIST Number: 71211 Issued: 9-23-2002 Revised: 1-25-2007...

  • Page 2: Table Of Contents

    Note About Ordering Parts ... 3 Material Abbreviations ... 4 A. Ice Cuber Assembly ... 5 AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS ... 5 B. Refrigeration Assembly ... 9 AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS ... 9 C. Ice Making Mechanism Assembly ... 1 AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS ...

  • Page 3: Auxiliary Codes

    Auxiliary Codes AM-50BAE AM-50BAE-DS AM-50BAE-AD AM-50BAE-ADDS Auxiliary Code Breakdown Designates the year. "K" indicates the year 000. Years progress or regress in alphabetical order. "J" is 1999, "L" is 001, "M" is 00, and so on. The letters "I" and "O" were skipped.

  • Page 4: Material Abbreviations

    Material Abbreviations ALUMINUM Aluminum COPPER Copper PLASTIC Acrylonitrile -butadiene - styrene Polyacetal Ethylene vinyl acetate Polyamide = Nylon Polycarbonate Polyethylene Polyester PETP Polyethylene terephthalate = Tetlon Polypropylene Polystyrene PTFE Polytetrafluoroethylene = Teflon Polyurethane Polyvinyl chloride RUBBER Vinyl Nitrile EPDM EP rubber Nitrile butadiene rubber Natural rubber Neoprene...

  • Page 5: Ice Cuber Assembly

    A. Ice Cuber Assembly AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- N-1 to P-0 P-1 and later 30 30a 31 31a...
  • Page 6 Title: A. Ice Cuber Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Refrigeration Assembly Ice Making Mechanism Assembly T Screw Control Box Assembly Hex Bolt Sw Door Assembly Water Circuit Assembly Thermostat Assembly T Screw Label Location Body Hex T Screw...
  • Page 7 Title: A. Ice Cuber Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Hinge (B) Flat Head Screw Hinge - Stop Pin Louver Truss Head Screw Rear Panel T Screw Cover – Pipe T Screw Drain Pan T Screw Drain Tube Drain Pipe Holder –...
  • Page 8 Title: A. Ice Cuber Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Fitting – Drain T Screw Bracket – Drain T Screw Hinge (C) Assembly (UR, LL) Includes Bushing 417486-01 Flat Head Screw Hinge (C) Assembly (LR, UL) Includes Bushing...

  • Page 9: Refrigeration Assembly

    B. Refrigeration Assembly AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- 14 14a FAN MOTOR ASSEMBLY (FAN MOTOR ASSEMBLY)
  • Page 10 Title: B. Refrigeration Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Compressor Rubber Grommet Bolt PTC Relay Motor Protector Protector Cover Clamp Clip Copper Tube (H) Copper Tube (J) Condenser – Air Cooled T Screw Plate – Cond T Screw Guide –...
  • Page 11 Title: B. Refrigeration Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Joint – 4 Way Copper Tube Copper Tube (E) Copper Tube (F) Copper Tube (G) Material or Model Number Part Number T30 RSF 436156-01 4A11-01 4Y01G01 4Y009-01 3X6439G01 4Y010-01...

  • Page 12: Ice Making Mechanism Assembly

    C. Ice Making Mechanism Assembly AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- (these screws secure 14 14a evaporator to bracket) (these screws secure evaporator to bracket) 13 13a...
  • Page 13 Water Tank Pump Motor Cross-Recessed Hex Bolt Holder – Thermistor T Screw Joint Reducing Pipe T Screw T Screw Gasket (B1) Gasket (B) Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Material or Model Number Part Number 1H637-01 1H636G01 1H636-01 3X386-01 3X3861-01 4X7933-01 4X8068-01...

  • Page 14: Control Box Assembly

    D. Control Box Assembly AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- Title: D. Control Box Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Control Box Control Box Cover T Screw Controller Board Board Support...

  • Page 15: Door Assembly

    E. Door Assembly AM-50BAE, AM-50BAE-AD M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- Title: E. Door Assembly Model: AM-50BAE, AM-50BAE-AD Index Description Door Gasket (A) Handle Truss Head Screw Holder – Magnet Truss Head Screw Magnet Bushing Material or Model...

  • Page 16: Am-50Bae-Ds, Am-50Bae-Adds

    E. Door Assembly AM-50BAE-DS, AM-50BAE-ADDS Title: E. Door Assembly Model: AM-50BAE-DS, AM-50BAE-ADDS Index Description Door Gasket (A) Holder – Magnet Truss Head Screw Magnet Material or Model Number Part Number AM-50BAE-DS A3578G01 AM-50BAE-ADDS A3578G0 A3017-01 4Y003-01 4×8, SS 7C3-0408 RARE EARTH...

  • Page 17: Water Circuit Assembly

    F. Water Circuit Assembly AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- Title: F. Water Circuit Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Water Valve Cross – Recessed Hex Bolt Hex Bolt Assy (LF) Tube –...

  • Page 18: Thermostat Assembly

    G. Thermostat Assembly AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- Silicone Tube Title: G. Thermostat Assembly Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Thermostat Heater Material or Model Number Part Number 43766-01 437409-01 Required Number...

  • Page 19: Label Location

    H. Label Location AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- Title: H. Label Location Model: AM-50BAE, AM-50BAE-DS, AM-50BAE-AD, AM-50BAE-ADDS Index Description Nameplate Wiring Label Maintenance Label Emblem Label – Penguin (R) Label – R134a...

  • Page 20: Am-50Bae, Am-50Bae-Ad

    J. Accessories AM-50BAE, AM-50BAE-AD M-0, N-1, N-, P-0, P-1, Q-0, R-0, R-1, R- Title: J. Accessories Model: AM-50BAE, AM-50BAE-AD Index Description Scoop Instruction Manual Material or Model Number Part Number 04336-01 PAPER 91A1VG10B Required Number...

  • Page 21: Am-50Bae-Ds, Am-50Bae-Adds

    J. Accessories AM-50BAE-DS, AM-50BAE-ADDS Title: J. Accessories Model: AM-50BAE-DS, AM-50BAE-ADDS Index Description Scoop Instruction Manual Canoe Clip Bracket Threaded Wood Insert Pan Head Screw Truss Head Screw T Screw Material or Model Number Part Number 04336-01 PAPER 91A1VG10B 4A069-0 4A3998-01 4A4004-01 4×5 SS...
