- Page 1 Hoshizaki America, Inc. “A Superior Degree of Reliability” www.hoshizaki.com Self-Contained Cuber Models AM-50BAE AM-50BAE-DS AM-50BAE-AD AM-50BAE-ADDS INSTRUCTION MANUAL Issued: 3-10-2006 Revised: 7-1-2011...
- Page 2 Should the reader have any questions or concerns which have not been satisfactorily addressed, please call, write, or send an e-mail message to the Hoshizaki Technical Support Department for assistance. HOSHIZAKI AMERICA, INC.
-
Page 3: Table Of Contents
B. Location ...11 1. General ...11 2. Built-In Installation Site ... 12 C. Door ... 13 1. AM-50BAE, AM-50BAE-AD ... 13 a) Hinge Reversal ... 13 2. AM-50BAE-DS, AM-50BAE-ADDS ... 15 a) Overlay Panel Fabrication and Attachment ... 15 D. Setup ... 23 E. -
Page 4: Important Safety Information
Important Safety Information Throughout this manual, notices appear to bring your attention to situations which could result in death, serious injury, or damage to the unit. WARNING Indicates a hazardous situation which could result in death or serious injury. CAUTION Indicates a situation which could result in damage to the unit. -
Page 5: Specifications
I. Specifications A. Construction Top Panel Ice Making Mechanism Scoop Holder Slope Front Panel Control Switch Power Cord Louver Bin Control Thermostat Bulb Magnet Catch Door... -
Page 6: Electrical Data
B. Electrical Data HOSHIZAKI ICE MAKER MODEL NUMBER SERIAL NUMBER AC SUPPLY VOLTAGE AMPERES DESIGN PRESSURE REFRIGERANT MOTOR-COMPRESSOR THERMALLY PROTECTED For certification marks, see the nameplate Note: Only the "MODEL NUMBER" is replaced for AM-50BAE-DS, AM-50BAE-AD, and AM-50BAE-ADDS. The nameplate provides electrical and refrigerant data. The nameplate is located in the storage bin. -
Page 7: Dimensions/Connections
C. Dimensions/Connections 1. AM-50BAE... -
Page 8: Am-50Bae-Ds
2. AM-50BAE-DS... -
Page 9: Am-50Bae-Ad
3. AM-50BAE-AD... -
Page 10: Am-50Bae-Adds
4. AM-50BAE-ADDS... -
Page 11: Installation And Operating Instructions
II. Installation and Operating Instructions 1. This icemaker must be installed in accordance with applicable national, state, and local codes and regulations. 2. CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the storage bin. -
Page 12: Built-In Installation Site
2. Do not install the icemaker in a corner where the door will interfere with other equipment or where the icemaker cannot be pulled out for service. Model AM-50BAE 34" (864 mm) minimum AM-50BAE-DS AM-50BAE-AD 32" (814 mm) minimum AM-50BAE-ADDS Between Two Cabinets AM-50BAE AM-50BAE-DS Min. 15"... -
Page 13: Door
C. Door 1. AM-50BAE, AM-50BAE-AD a) Hinge Reversal If you would like to reverse the door hinges, follow the steps below. Otherwise, skip to section "II.D. Setup." 1) While maintaining a hold on the door, remove the hinge stop pin from hinge (B). Pull out the bottom of the door slightly and gently remove the door from hinge (A). - Page 14 4) Remove hinge (B) from the right side of the unit and the 2 filler screws from the left side. Attach the 2 filler screws to the right side and attach hinge (B) to the left side. See Fig. 4. 5) Rotate the top panel 180°...
-
Page 15: Am-50Bae-Ds, Am-50Bae-Adds
2. AM-50BAE-DS, AM-50BAE-ADDS a) Overlay Panel Fabrication and Attachment The overlay panel must be crafted by a professional cabinet maker to ensure quality results. (1) Parts Ensure that all parts required for the overlay panel assembly are contained in the accessories bag. - Page 16 (2) Overlay Panel Specification Use the specification that applies to your icemaker (AM-50BAE-DS or AM-50BAE-ADDS) and the directions that follow to prepare your overlay panel. (a) AM-50BAE-DS AM-50BAE-DS Overlay Panel Specification Overlay Panel Height Overlay Panel Width Overlay Panel Thickness Overlay Panel and Door Weight (total) 29 17/32" (750 mm) 14 13/16" (376 mm)
- Page 17 (b) AM-50BAE-ADDS AM-50BAE-ADDS Overlay Panel Specification Overlay Panel Height Overlay Panel Width Overlay Panel Thickness Overlay Panel and Door Weight (total) 27 9/16" (700 mm) 14 13/16" (376 mm) 5/8" (16 mm) minimum; 3/4" (19 mm) maximum 20 lb. (9 kg) maximum...
- Page 18 Otherwise, the overlay panel cannot be properly fastened to the door. 4) Mount the door handle hardware. Hoshizaki recommends that the door handle hardware be mounted on the edge opposite of the door hinge side (optional hinge reversal is covered in step 6).
- Page 19 6) If you would like to reverse the door hinges, do the following: a) Contact your local distributor to purchase Hoshizaki Kit HS-0229. The kit contains "hinge (A)-left." b) Remove the 2 screws securing the top panel, then lift it off. See Fig. 11.
- Page 20 7) Remove the bushings from hinge (C1) and hinge (C2) (the hinges attached to the door). See Fig. 16. 8) Remove the gasket from the door. See Fig. 17. Hinge Fig. 16 9) Temporarily fasten the overlay panel to the door using 2 of the M4×25 pan head screws provided.
- Page 21 (4) Attachment of Overlay Panel to Door 1) Fasten the sheet metal bracket to the overlay panel using the two M4×8 truss head screws provided. Snug the screws, but do not tighten. See Fig. 20. 2) Temporarily fasten the overlay panel to the door using 2 of the M4×25 pan head screws provided.
- Page 22 7) Tighten the four M4×25 pan head screws installed in step 5. See Fig. 26. 8) Replace the door gasket in its proper orientation. Reinsert the bushings into hinge (C1) and hinge (C2) (the hinges attached to the door). See Fig. 27. Tighten the screws.
-
Page 23: Setup
D. Setup 1) Position the icemaker in the selected permanent location. 2) Level the icemaker from side-to-side and front-to-rear by adjusting the feet. E. Electrical Connection 1. Electrical connection must meet national, state, and local electrical code requirements. Failure to meet these code requirements could result in death, electric shock, serious injury, fire, or severe damage to equipment. -
Page 24: Water Supply And Drain Connections
10 PSIG. Do not run the icemaker until the proper water pressure is reached. • A plumbing permit and services of a licensed plumber may be required in some areas. • External filters, strainers, or softeners may be required depending on water quality. Contact your local Hoshizaki distributor for recommendations. • Water supply inlet is 1/2" female pipe thread (FPT). A minimum of 1/4" nominal ID copper water tubing or equivalent is required for the water supply line. • A water supply line shut-off valve and drain valve should be installed. -
Page 25: Final Checklist
G. Final Checklist CHOKING HAZARD: Ensure all components, fasteners, and thumbscrews are securely in place after installation. Make sure that none have fallen into the storage bin. 1) Is the icemaker level? 2) Is the icemaker in a site where the ambient temperature is within 45°F to 100°F (7°C to 38°C) and the water temperature within 45°F to 95°F (7°C to 35°C) all year around? 3) Have the shipping carton, tape, and packing material been removed from the icemaker? 4) Have all electrical and water connections been made? Do electrical and water... -
Page 26: Startup
H. Startup 1. All parts are factory-adjusted. Improper adjustments may adversely affect safety, performance, component life, and warranty coverage. 2. If the icemaker is turned off, wait for at least 3 minutes before restarting the icemaker to prevent damage to the compressor. 3. -
Page 27: Cleaning And Maintenance
A. Cleaning and Sanitizing Instructions Hoshizaki recommends cleaning and sanitizing this unit at least once a year. More frequent cleaning and sanitizing, however, may be required in some existing water conditions. - Page 28 3) Inside the storage bin, disconnect the suction tube by squeezing the tabs and pulling the tube clear. See Fig. 33. Allow the water tank to drain. 4) Reconnect the suction tube as illustrated. See Fig. 34. Make sure the tabs lock into place;...
-
Page 29: Sanitizing Solution
3. Sanitizing Solution For safety and maximum effectiveness, use the solution immediately after dilution. Dilute 0.5 fl. oz. (14.8 ml or 1 tbs) of a 5.25% sodium hypochlorite solution (chlorine bleach) with 1 gallon (3.8 l) of warm water. This is a minimum amount. Make more solution if necessary. - Page 30 7) Disconnect the discharge tube from the spray assembly, then slide out the spray assembly. See Fig. 39. 8) Remove the two caps. See Fig. 40. Discharge Tube Spray Assembly Fig. 39 9) Soak all of the removed parts and the scoop in the sanitizing solution for 10 minutes. If the spray assembly nozzles are clogged, clean them with a wire or a suitable brush.
- Page 31 15) Reconnect the suction tube. 16) Hook each separator onto the rail, then pull it hard towards you until it locks into place. See Fig. 45. 17) Replace the slope in its correct position. See Fig. 46. Separator Fig. 45 18) Discard the sanitizing solution.
-
Page 32: Maintenance
B. Maintenance This icemaker must be maintained individually, referring to the instruction manual and labels provided with the icemaker. 1. Stainless Steel Exterior To prevent corrosion, wipe the exterior occasionally with a clean and soft cloth. Use a damp cloth containing a neutral cleaner to wipe off oil or dirt build up. 2. -
Page 33: Preparing The Icemaker For Long Storage
C. Preparing the Icemaker for Long Storage When storing the icemaker for an extended time or in sub-freezing temperatures, follow the instructions below to prevent damage. When the icemaker is not used for two or three days under normal conditions, it is sufficient to move the control switch to the "OFF" position. When storing the icemaker for an extended time or in sub-freezing temperatures, follow the instructions below. - Page 34 HOSHIZAKI AMERICA, INC. 618 Hwy. 74 S., Peachtree City, GA 30269 USA TEL (770) 487-2331 FAX (770) 487-3360 www.hoshizaki.com 91A1VG10E...
