OVEN AND ACCESSORIES

6
1
4
5 3
12
14
Hub (inside)
15. Turntable
(glass)
17. Coupling
NOTES:
• The waveguide cover is fragile. Care should be taken when cleaning inside the oven to
ensure that it is not damaged.
• Always operate the oven with the turntable and turntable support fitted correctly. This
promotes thorough, even cooking. A badly fitted turntable may rattle, may not rotate
properly and could cause damage to the oven.
• Place all food and containers of food on the turntable for cooking.
• The turntable rotates clockwise or anti-clockwise. The rotary direction may change each
time you start the oven. This does not affect cooking performance.
2
9 10
7 8 4
13
16. Turntable
support
18. Rack
OVEN
1. Door handle
2. Oven lamp
3. Door hinges
9
4. Door safety latches
5. Door
6. Door seals and sealing surfaces
7. Turntable motor shaft
8. Oven cavity
9. Control panel
10. Grill heating element
11. Waveguide cover (DO NOT REMOVE)
12. Power supply cord
13. Ventilation openings
14. Outer cabinet
ACCESSORIES:
Check to make sure the following accesso-
ries are provided:
(15) Turntable (16) Turntable support
(17) Coupling (18) Rack
• Place the coupling into the turntable
motor shaft. Then place the turntable on
to the turntable motor shaft; ensuring it is
located firmly.
• To avoid turntable damage, ensure dish-
es and containers are lifted clear of the
turntable rim when removing them from
the oven.
• For use of the rack, refer to the grilling
sections on page GB-18-19.
Never touch the grill when it is hot.
NOTE: When you order accessories, please
mention two items: part name and model
name to your dealer or SHARP authorised
service agent.
