Decorative Heat Lamps
This manual contains important safety information
concerning the maintenance, use and operation of this
product. Failure to follow the instructions contained in this
manual may result in serious injury. If you're unable to
understand the contents of this manual, please bring it to
the attention of your supervisor. Do not operate this
equipment unless you have read and understood the
contents of this manual.
DL Series
Installation &
Operating Manual
I&W #07.05.147.00
Este manual contiene importante información sobre
seguridad concerniente al mantenimiento, uso y
operación de este producto. Cualquier falla en el
seguimiento de las instrucciones contenidas en este
manual puede resultar en un serio daño. Si usted no
puede entender el contenido de este manual por
favor pregunte a su supervisor. No opere este
equipo al menos que haya leído y comprendido el
contenido de este manual.
Advertisement
Table of Contents
Related Manuals for Hatco DL-400
Summary of Contents for Hatco DL-400
- Page 1 Decorative Heat Lamps Operating Manual This manual contains important safety information concerning the maintenance, use and operation of this product. Failure to follow the instructions contained in this manual may result in serious injury. If you’re unable to understand the contents of this manual, please bring it to the attention of your supervisor.
-
Page 2: Table Of Contents
Serial No. ________________________________ Voltage __________________________________ Date of Purchase __________________________ INTRODUCTION Hatco Decorative Heat Lamps are designed to hold your food at serving temperatures and enhance restaurant decor. Hatco Decorative Heat Lamps heat is focused directly below, providing effective insulation for prolonged serving times. -
Page 3: Important Safety Information
Some aftermarket or generic replacement parts do not have the characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to... - Page 4 Hatco warranty. Contact the manufacturer of the countertop material for application information. Hatco DL lamp warmers are built to fit HALO brand L651, L652 and L653 Power Trac, track lighting systems only. Do not attempt to use on any other track lighting system.
-
Page 5: Specifications
8-1/2" (279 mm) (216 mm) NOTE: The height dimension of the shade increases by 2" (51 mm) when utilizing the “L” lower switch location. ELECTRICAL RATING CHART Voltage Model DL-400 Model DL-725 Model DL-760 Figure 1. Lamp Dimensions SPECIFICATIONS Watts... -
Page 6: Model Designation
MODEL DESIGNATION Form No. DHLM-1207 Figure 2. Model Designations TS Mount Lamp mounts with threaded stem to fixture (supplied by others). Threaded stem is only available as a UL recognized component (UR). -
Page 7: Model Descriptions
(REM) switch or with no switch. CAUTION For safe and proper operation on units not equipped with Hatco supplied switch (N-no switch), a qualified electrician must choose an appropriate switch for the application based on amperage and inrush rating of the switch. -
Page 8: Assembly
1920 watts per any length track. CAUTION For safe and proper operation on units not equipped with Hatco supplied switch (N-no switch), a qualified electrician must choose an appropriate switch for the application based on amperage and inrush rating of the switch. -
Page 9: Installing Non-Track Mount
INSTALLING NON-TRACK MOUNT (A, C, P, S AND R) (See Figure 6) WARNING To avoid any injury, turn the power supply OFF to the electrical junction box before mounting. 1. Mount the top bracket to the 4" (102 mm) octagon junction box using the two screws provided with the junction box. -
Page 10: Installing Track Mount
INSTALLATION INSTALLING TRACK MOUNT (CT, ST AND RT) NOTICE Hatco DL lamp warmers are built to fit HALO brand L651, L652 and L653 Power Trac, track lighting systems only. Do not attempt to use on any other track lighting system. - Page 11 Field Cutting Trac To Special Lengths (See Figure 7) NOTE: Cutting should be done from the dead end of the Trac. 1. Remove dead end fitting and put copper buss bars and insulators flush with the live end of the Trac.
- Page 12 INSTALLATION Installing the Trac (See Figure 8) WARNING To avoid any injury, turn the power supply OFF to the mounting location before installing. 1. Punch out proper knockout holes in the ceiling plate. CAUTION For safe and proper operation do not damage the special, smooth plastic finish piece on metal ceiling plate when determining location of proper knock out holes.
-
Page 13: Operation
OPERATION WARNING Decorative Heat Lamps are not waterproof. To avoid electrical shock or personal injury DO NOT submerge in water. Do not operate if it has been submerged in water. CAUTION Some exterior surfaces on the unit will get hot. Use caution when touching these areas to avoid injury. -
Page 14: Maintenance
Some aftermarket or generic replacement characteristics that will allow them to operate safely in Hatco equipment. It is essential to use Hatco Replacement Parts when repairing Hatco equipment. Failure to use Hatco Replacement Parts may subject operators of the equipment to hazardous electrical voltage, resulting in electrical shock or burn. -
Page 15: Accessories
TRACK BAR MOUNT Track Bar Mount specify 4' (1219 mm), 8' (2438 mm), or 12' (3658 mm) track length and color option of black or white. Track bar can be cut down in the field. WARNING To avoid any injury or damage the Decorative Heat Lamps must only be serviced by qualified personnel. - Page 16 Form No. DHLM-1207 PROBABLE CAUSE Unit mounted too close to target area. Voltage supply too high. Switches used are not Hatco supplied. CORRECTIVE ACTION Check to see that installation is within specifications for type/model. Increase mounting height if too close.
-
Page 17: Hatco Limited Warranty
Hatco reserves the right to accept or reject any such claim in whole or in part. Hatco will not accept the return of any Product without prior written approval from Hatco, and all such approved returns shall be made at Buyer’s sole expense. - Page 18 NOTES Form No. DHLM-1207...
- Page 19 NOTES Form No. DHLM-1207...
-
Page 20: Authorized Parts Distributors
Flanders GCS Service Indianapolis 317-545-9655 P.O. Box 340500, Milwaukee, WI 53234-0500 U.S.A. Parts & Service Fax (800) 690-2966 Printed in U.S.A. December 2007 HATCO AUTHORIZED PARTS DISTRIBUTORS NEW YORK Acme American Repairs, Inc. 319-323-1823 Brooklyn Alpro Service Co. 515-262-9308 Brooklyn...
