Register Online! (see page 2) Glo-Ray ® Infrared Strip Heaters 长条形红外线保温灯 GR Series • GR 系列 Installation and Operating Manual 安装及操作手册 WARNING Do not operate this equipment unless you have read 请在认真阅读并理解本手册的内容后再操作本设 and understood the contents of this manual! Failure 备!不按照本手册中的说明操作可能会导致严重...
Hours: Monday through Friday label located on the underside of the unit). Please have this Telephone: (0512) 6732-5091 information available when calling Hatco for service assistance. E-mail: infocn@hatcocorp.com Model No. ________________________________________ Additional information can be found by visiting our web sites: Serial No.
This unit has no “user-serviceable” parts. If service is required on this unit, contact an Authorized Hatco • DO NOT submerge or saturate with water. Unit is not Service Agent or contact the Hatco Service Department at waterproof.
MODEL DESCRIPTION English All Models Hatco Glo-Ray Infrared Strip Heaters keep hot foods at ® optimum serving temperatures longer. Foods do not dry out or become discolored; even the most delicate dishes hold that “just- prepared” look. The Glo-Ray pre-focused heat pattern directs heat from a tubular element to bathe the entire holding surface.
SPECIFICATIONS English Dimensions Width (A) Height (B) Depth (C) Depth (D) Height (E) Model 457–1829 mm 63 mm 152 mm GR and GRH (18″–72″) (2-1/2″) (6″) 457–1829 mm 63 mm 152 mm 584 mm 102 mm GRA and GRAH (18″–72″) (2-1/2″) (6″) (23″)
Excessive heat can cause unit failure. Damage to any countertop material caused by heat generated from Hatco equipment is not covered under the Hatco warranty. Contact the manufacturer of the countertop material for application information. NOTE: Contact the manufacturer of the countertop base material for application information and surface temperature limits before installing the unit.
INSTALLATION English Recommended Mounting Heights Minimum Clearance Requirements for Combustible Surroundings Add 76 mm (3″) for 102–152 mm units with lights. (4″–6″) Models Standard Wattage High Wattage Height Height GRA and 254 mm 76 mm 25 mm GRAL (10″) (3″) (1″) 343 mm 76 mm...
Page 12
INSTALLATION English Minimum Clearance Requirements for Non-Combustible Surroundings Hardwired Units with Built-In Switches (B)* Models Shelf GRA and 203 mm 25 mm GRAL (8″) (1″) GRAH and GRAHL 254 mm 25 mm with Infinite (10″) (1″) Control or Indicator Light GRAH and Counter 203 mm...
INSTALLATION English Installing Units 3. Secure the conduit-side stand to the unit using the screws supplied. Strip heaters can be mounted with tubular stands or angle brackets. Refer to the proper mounting section for the 4. Align the opposite-side stand with the mounting holes at installation procedure.
Page 14
5. Fasten the angle brackets to the underside of the shelf permanently attaches the unit to the underside of a shelf. Units using appropriate fasteners (not supplied by Hatco). can be mounted to a flat shelf or a shelf with rolled/flanged NOTE: Two pairs of brackets will be needed for dual units.
INSTALLATION English Electrical Information Power Supply Install supply wire and connectors suitable for at least 90°C Refer to the wiring diagram supplied with the unit and (194°F). specification label attached to the unit for specific electrical information. • Use a minimum of No. 14 AWG copper wire for individual circuits up to 15 amps.
Page 16
English Remote Control Enclosures Remote Mounted Control Switches Hatco remote control enclosures include switches, wire leads, Optional remote mounted control switches include ON/OFF and/or indicator lights and are shipped ready for installation. toggle switches and infinite control switches. These switches...
OPERATION English General Glo-Ray Infrared Strip Heaters are designed for ease of ® operation. Use the following information and procedures to operate the unit. WARNING Read all safety messages in the IMPORTANT SAFETY INFORMATION section before operating this equipment. CAUTION BURN HAZARD: Some exterior surfaces on unit will get hot.
2. Unscrew the light bulb from the unit and replace it with a new, specially-coated incandescent bulb. This unit has no “user-serviceable” parts. If service is required on this unit, contact an Authorized Hatco NOTE: Hatco shatter-resistant light bulbs meet NSF standards Service Agent or contact the Hatco Service Department at for food holding and display areas.
Troubleshooting Questions? If you continue to have problems resolving an issue, please contact the nearest Authorized Hatco Service Agency or Hatco for assistance. To locate the nearest Service Agency, log onto the Hatco website at www.hatcocorp.com, select the Support pull- down menu, and click on “Find A Service Agent”;...
OPTIONS AND ACCESSORIES English Remote Control Enclosures — RMB Series 5. Attach conduit connectors to the knockouts in the control enclosure. RMB Series remote control enclosures are available in various configurations for use with strip heaters. Remote control Infinite Control enclosures locate controls away from the heat of the unit, Indicator increasing the life span of the controls.
Page 21
Acorn Nut The infinite switch must be installed using the terminals and wires supplied with the switch. Failure to use the Support Bar supplied Genuine Hatco Replacement Parts will void all warranties and may damage the equipment. Installing Sneeze Guards 220-230V...
SERVICE INFORMATION English The warranty on this Hatco unit is for one year from date of The Hatco dealer will do the following: purchase or eighteen months from date of shipping from Hatco, • Provide replacement part(s) as required whichever occurs first.
Page 26
规格 中文 尺寸 宽度 (A) 高度 (B) 深度 (C) 深度 (D) 高度 (E) 型号 457–1829 mm 63 mm 152 mm GR and GRH (18″–72″) (2-1/2″) (6″) 457–1829 mm 63 mm 152 mm 584 mm 102 mm GRA and GRAH (18″–72″) (2-1/2″) (6″) (23″)
安装 中文 建议安装高度 可燃环境的最小间距要求 型号 102–152 mm (4″–6″) GRA 和 254 mm 76 mm 25 mm GRAL (10″) (3″) (1″) GRAH 和 343 mm 76 mm 25 mm (13-1/2″) (3″) (1″) GRAHL 203–279 mm 279–356 mm 注意: 双长条形保温灯不可安装在可燃环境中。 (8″–11″) (11″–14″) 305 mm (12″) 各种长度...
Page 33
安装 中文 不可燃环境的最小间距要求 具有内置开关的硬连线设备 (B)* 型号 GRA and 203 mm 25 mm GRAL (8″) (1″) 具有无限控制或指 254 mm 25 mm 示灯的 GRAH 和 (10″) (1″) GRAHL 具有开/关拨动开 203 mm 25 mm 关的 GRAH 和 (8″) (1″) GRAHL 不可燃间距要求 具有远程开关的硬连线设备 具有内置开关的双设备 型号...
Page 44
Register your unit online! See IMPORTANT OWNER INFORMATION section for details. HATCO CORPORATION HATCO CORP. FOODSERVICE P.O. Box 340500 EQUIPMENT (SUZHOU) CO. LTD. Unit A/No. 9 Weixin Road Milwaukee, WI 53234-0500 U.S.A. Suzhou Industrial Park, Jiangsu, China Telephone 414-671-6350 Telephone (0512) 6732-5091 support@hatcocorp.com...
